SPECIFICATIONS
Model:
Drilling capacities
Concrete
Steel
Wood
Fastening capacities Wood screw
Machine screw
No load speed
High (2)
Low (1)
Blows per minute
High (2)
Low (1)
Overall length
Rated voltage
Net weight
•
Due to our continuing program of research and development, the specifications herein are subject to change
without notice.
•
Specifications and battery cartridge may differ from country to country.
•
Weight, with battery cartridge, according to EPTA-Procedure 01/2003
Symbols
The following show the symbols used for the equip-
ment. Be sure that you understand their meaning before
use.
Read instruction manual.
Only for EU countries
Cd
Do not dispose of electric equipment or
Ni-MH
Li-ion
battery pack together with household waste
material!
In observance of the European Directives,
on Waste Electric and Electronic
Equipment and Batteries and Accumulators
and Waste Batteries and Accumulators
and their implementation in accordance
with national laws, electric equipment and
batteries and battery pack(s) that have
reached the end of their life must be col-
lected separately and returned to an envi-
ronmentally compatible recycling facility.
Intended use
The tool is intended for impact drilling in brick, concrete
and stone. It is also suitable for screw driving and drill-
ing without impact in wood, metal, ceramic and plastic.
General power tool safety warnings
WARNING:
Read all safety warnings and
all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instruc-
tions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
M8301D
13 mm
13 mm
36 mm
6 mm x 75 mm
0 - 1,400 min
0 - 400 min
0 - 21,000 min
0 - 6,000 min
238 mm
D.C. 18 V
1.7 kg
Work area safety
1.
Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2.
Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3.
Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical Safety
1.
Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
2.
Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
3.
Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
4.
Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
6.
If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
Personal Safety
1.
Stay alert, watch what you are doing and use
common sense when operating a power tool.
2 ENGLISH
M6
-1
-1
-1
-1
