Timing Chart - NEC MultiSync VT540JK User Manual

Timing Chart

Resolution
Y / N Signal
( Dots )
Y NTSC 640
Y PAL 768
Y SECAM 768
Y VESA 640
Y IBM 640
Y MAC 640
Y MAC 640
Y MAC 640
Y VESA 640
Y VESA 640
Y IBM 640
Y VESA 640
Y IBM 720
Y VESA 720
Y IBM 720
Y IBM 720
Y VESA 800
Y VESA 800
Y VESA 800
Y VESA 800
Y VESA 800
#Y MAC 832
#Y VESA 1024
#Y VESA 1024
#Y VESA 1024
#Y IBM 1024
#Y MAC 1024
#Y VESA 1024
#Y VESA 1024
##Y VESA 1152
##Y MAC 1152
##Y SUN 1152
##Y SGI 1152
##Y VESA 1280
##Y SGI 1280
##Y VESA 1280
##Y MAC 1280
##Y MAC 1280
##Y HP 1280
##Y SUN 1280
##Y VESA 1280
##Y VESA 1280
##Y HDTV (1080i) 1920
##Y HDTV (720p) 1280
##Y SDTV (480p) 720
#Y: Images in above flagged with # and Y are compressed with Advanced AccuBlend on VT440.
##Y: Images in above flagged with ## and Y are compressed with Advanced AccuBlend on VT540.
NOTE1: Some composite sync signals may not be displayed correctly.
NOTE2: Signals other than those specified in the table above may not be displayed correctly. If this should happen, change the refresh
rate or resolution on your PC. Refer to Display Properties help section of your PC for procedures.
Refresh Rate
( Hz )
480 60 15.734
576 50 15.625
576 50 15.625
480 59.94 31.47
480 60 31.47
480 60 31.47
480 66.67 34.97
480 66.67 35
480 72.81 37.86
480 75 37.5
480 75 39.375
480 85.01 43.269
350 70.09 31.469
400 85.04 37.927
350 87.85 39.44
400 87.7 39.375
600 56.25 35.16
600 60.32 37.879
600 72.19 48.077
600 75 46.88
600 85.06 53.674
624 74.55 49.725
768 43 Interlaced 35.5
768 60 48.363
768 70.07 57.476
768 72.03 58.131
768 74.93 60.241
768 75.03 60.023
768 85 68.677
864 75 67.5
870 75.06 68.681
900 65.95 61.796
900 76.05 71.736
960 60 60
1024 60 63.9
1024 60.02 63.981
1024 60.38 64.31
1024 65.2 69.9
1024 72.01 78.125
1024 76.11 81.13
1024 75.03 79.976
1024 85.02 91.146
1080 60 Interlace 33.75
720 60 Progressive 45
483 59.94 Progressive 31.47
