Summary of Contents for Vizio BRAVO D1
-
Page 2: Table Of Contents
Troubleshooting ... 22 General Issues...22 Audio Issues...22 Video Issues ...23 Specifications ... 23 Media Format Specifications... 24 Digital TV (DTV) ...24 Divx Format Definition ...24 NOTE: Read this guide before installation and use BRAVO D1 User Guide Page i PAGE... -
Page 3: Warning
Turn the main power off when the Bravo D1 is not in use. Disconnect the power plug if you do not intend to use the Bravo D1 for a long period of time. Before moving the Bravo D1, first remove the disc from the unit's tray. -
Page 4: General Information
Do not apply thinner, alcohol or sprays to discs. DVD Regional Codes DVD discs and DVD players are manufactured under the DVD Regional Code System, a worldwide standard. DVD players only play discs possessing the same Regional Code as the player. -
Page 5: Dvd And Other Disc Features
DVD and Other Disc Features Some Bravo D1 features rely on DVD software. Make sure that desired software features are available and enabled on the disc, and follow the on-screen menu to access these features. Disc types Recording Digital MPEG-2... -
Page 6: Getting Started
3. Load batteries into the Remote Control. 4. Connect the Bravo D1 to your Audio/Video system. 5. Plug the Bravo D1 (and other connected A/V devices) into an electrical outlet and turn on all of the devices. 6. Verify that the settings of the Bravo D1, TV and Amplifier match. -
Page 7: Panel Descriptions
3. 4-Pin Din, S-Video Analog Video 4. 3x RCA, Component YPbPr/YCbCr Analog Video 5. Coaxial, Digital Audio 6. Optical, Digital Audio 7. 2x RCA, Analog Audio (1) 8. 2x RCA, Analog Audio (2) BRAVO D1 User Guide Page 5 VINC.COM... -
Page 8: Remote Control
Remote Control BRAVO D1 User Guide Setup Open/Close Disc Tray Number Keys Clear Menu Up/Down/Left/Right Keys Enter Return Title 10. Zoom 11. Search 12. Angle/Rotate 13. Mode 14. Power On/Off 15. A-B Selection 16. Repeat 17. Display Info 18. Select 19. -
Page 9: System Connections
There are a number of ways to connect the Bravo D1 to an AV system, depending on the type of TV and other components in the system. Whichever method you use, be sure to set the TV to the correct video input type and channel (if required). -
Page 10: S-Video
RCA plug to the Right Audio Out (red) connector and connect the white RCA plug to the Left Audio Out (white) connector of the Bravo D1. Connect the opposite end of the cable to the Right and Left (red and white) Audio In connectors on the TV. -
Page 11: Dvi (Digital Video)
Y (green) connector on the Bravo D1, one Pb RCA plug to the Pb (blue) connector on the Bravo D1 and one Pr RCA plug to the Pr (red) connector on the Bravo D1. Take the other end of the cable and connect the Y (green), Pb (blue) and Pr (red) plugs to the corresponding Progressive Scan inputs on the TV. -
Page 12: Audio System Connections
The digital multi-channel connection provides the best sound quality. It requires a multi-channel A/V receiver that supports one or more of the audio formats supported by the Bravo D1 (MPEG- 2, Dolby Digital and DTS). Check the receiver manual and the logos on the front of the receiver for compatibility with these formats. -
Page 13: Tv System Setup
TV System Setup Either a PAL or NTSC signal can be selected for the Bravo D1 output. Select the TV output option that matches the requirements of your TV If your TV is NOT a multi-system version the following symptoms may indicate that the incorrect output setting has been selected for the Bravo D1: Picture is distorted. -
Page 14: Sound Output Setup
AC-3/DTS digital output (optical and coaxial) Mix audio output – Left & Right For AC-3 surround output, connect the Bravo D1 digital output (optical or coaxial) to an amplifier with a built-in AC-3 decoder. For DTS surround output, connect the Bravo D1 digital output (optical or coaxial) to an amplifier... -
Page 15: Playing Discs
Playing Discs Power On Activate the Bravo D1 using the main power switch on the front panel, turn on the TV set and amplifier (if connected). DVD and System Settings Select the correct Bravo D1, TV, and amplifier settings (AV1, AV2, S video, etc.) to display the DVD output. -
Page 16: General Operation
BRAVO D1 User Guide General Operation If the Bravo D1 is correctly connected to your system and turned on, a menu appears on your TV. This menu controls important audio, video, and disc format, and initial setting options. Main Setup Menu... -
Page 17: Audio Setup Menu
Audio Setup Menu For analog audio output, choose the Analog/DPCM audio option, and make sure that a pair of the Bravo D1’s analog Audio Out connectors is connected to the analog Audio Input of your AV system. For digital audio output, choose the Encoded Digital option, and make sure the Bravo D1’s optical or coaxial Audio Out jack is connected to the Digital Audio input (optical or coaxial) of your AV system. -
Page 18: Video Setup Menu
BRAVO D1 User Guide Video Setup Menu For Component (YPbPr) analog video output, choose the appropriate/desired HD Component resolution option. For DVI digital video output, choose the appropriate/desired HD DVI resolution option. Page 16 VINC.COM... - Page 19 If you turn the HD Component/DVI On with the TV hooked up via S-Video or composite video connections, the on-screen menu will no longer be visible. If this happens, unplug the Bravo D1, plug it back in, turn it on, and enter the following Remote Control command sequence: 5.
-
Page 20: Initial Setup Menu
TV. To compensate for this, press the Bravo D1's Remote Control Zoom button once. The Bravo D1's internal scaler will zoom the video image to the correct proportions. -
Page 21: Parental Control (Dvd Only)
Under these circumstances, we cannot guarantee the function and reliability of the Parental Control system. Please take responsibility to make sure your disks respond to the Parental Control settings before allowing children access to the Bravo D1. Parental Controls are not a substitute for responsible supervision of minors. BRAVO D1 User Guide... -
Page 22: Tv Type (Screen Format)
TV Type (Screen Format) The Bravo D1 provides three possible TV output formats: 4:3 Letterbox 4:3 Pan and Scan 16:9 Widescreen The following image shows the effects of the TV screen format settings, depending on the actual type of video being delivered to the TV. -
Page 23: Change Password
BRAVO D1 User Guide Change Password 6. Press Setup to display the Setup menu. 7. Press twice for the Initial Settings option. 8. Press once and then five times for the Change Password option. 9. Press button go to the Set password. -
Page 24: Troubleshooting
Troubleshooting The following are a list of difficulties you may experience when using the Bravo D1. Attempt the most common solutions provided below before contacting for customer service. General Issues Symptom Possible solutions No power Verify that the power cord is firmly plugged into a working electrical outlet. -
Page 25: Video Issues
If the picture is completely distorted or if the picture rolls vertically, picture or no color make sure the Bravo D1’s NTSC/PAL setting matches the TV’s video with menu system. See TV System Setup for instructions on setting the NTSC/PAL option. -
Page 26: Media Format Specifications
DivX is a digital video compression technology based on MPEG-4 and developed by DivXNetworks,Inc.; do not confuse this acronym with DIVX (digital video express ),a DVD-ROM format endorsed by major movie studios that tracks and enforces strict copy protection standards. BRAVO D1 User Guide Pixel Frame Rate Format... - Page 27 V, Inc.’s Responsibility V, Inc. DVD Players purchased in the United States are warranted to be free from defects in materials or workmanship for a period of one (1) year from the date of their original retail purchase. If the unit fails to conform to this warranty, we will service the monitor using new or refurbished parts.
