REVOLUTION
T M
STORAGE MODULE
ASSEMBLY MANUAL
REVSTOGL / REVSTOMA
LIMITED 5-YEAR WARRANTY
Read and save the manual for future reference.
Assemble your barbecue immediately. Missing or damaged parts
should be claimed within 3 0 days of purchase.
For product inquiries, parts, warranty and troubleshooting support,
please call 1300 659 489.
www.colemanbbqs.com.au
Manual Revision #: 2023.09.15 EK
Advertisement
Summary of Contents for Coleman REVOLUTION REVSTOGL
- Page 1 REVOLUTION STORAGE MODULE ASSEMBLY MANUAL REVSTOGL / REVSTOMA LIMITED 5-YEAR WARRANTY Read and save the manual for future reference. Assemble your barbecue immediately. Missing or damaged parts should be claimed within 3 0 days of purchase. For product inquiries, parts, warranty and troubleshooting support, please call 1300 659 489.
- Page 2 HE AV Y A R T I C L E N E E D S 2 T O LIFT THIS MANUAL MUST REMAIN WITH THE PRODUCT AT ALL TIMES To ORDER non-warranty replacement parts or accessories, or to register your warranty, please visit us on the web at www.colemanbbqs.com.au CAUTION Sharp edges.
- Page 3 P A R T S L I S T F O R REVSTOGL / REVSTOMA...
- Page 4 P A R T S L I S T F O R REVSTOGL / REVSTOMA ASSEMBLY PARTS NO. DESCRIPTION IMAGE REVSTOGL REVSTOMA Top shelf REVSC01001AU REVSC01001AU LOGO Panel REVSC020012 REVFC03009 Drawer kit REVSC02001AU REVSC03001AU Guide rail REVSC01004 REVSC01004 Cross bar REVSC02002 REVSC03005 Upper magnet...
- Page 5 E X P L O D E D D I A G R A M F O R REVSTOGL / REVSTOMA Middle shelf REVSC010010 REVSC030010 Bottom shelf REVSI01010AU REVSI03008AU 14 Bottom magnet SRT2018002 SRT2018002 Magnet frame REVSI01009 REVSI03007 Wheel rack SRT2018003 SRT2018003 2.5"Wheels with...
- Page 6 Installation guide 1 DESCRIPTION IMAGE Bottom shelf Wheel rack 2.5"Wheels with brake 2.5"Wheels M6*12...
- Page 7 Installation guide 2 DESCRIPTION IMAGE Back panel M4*12...
- Page 8 Installation guide 3 DESCRIPTION IMAGE Left panel M4*12...
- Page 9 Installation guide 4 DESCRIPTION IMAGE Right panel M4*12...
- Page 10 Installation guide 5 DESCRIPTION IMAGE Guide rail M4*8 Install both the left and right rails following the same procedure.
- Page 11 Installation guide 6 DESCRIPTION IMAGE Cross bar M4*8...
- Page 12 Installation guide 7 DESCRIPTION IMAGE Top shelf LOGO Panel M4*8...
- Page 13 Installation guide 8 DESCRIPTION IMAGE M4*12...
- Page 14 Installation guide 9...
- Page 15 Installation guide 10 DESCRIPTION IMAGE M4*8...
- Page 16 Installation guide 11 DESCRIPTION IMAGE Middle shelf...
- Page 17 Installation guide 12 DESCRIPTION IMAGE Magnet frame M4*12...
- Page 18 Installation guide 13 DESCRIPTION IMAGE Upper magnet Bottom magnet...
- Page 19 Installation guide 14 DESCRIPTION IMAGE Left door Right door...
- Page 20 Installation guide 15 DESCRIPTION IMAGE Drawer kit...
- Page 21 To attach the right-side shelf provided with your Revolution BBQ, refer to the steps outlined below. If you've acquired a Coleman Revolution Sink Module, it's recommended to utilise part G532Y20002 or G532Y10003 (front panel of the side shelf) included with the sink and storage with no drawer...
- Page 22 Installation guide 17 Connecting to the Coleman Revolution Dual Fuel BBQ - left side. DESCRIPTION IMAGE M6*16 M6 Nut φ6*16 Washer Clip Insert the fastening clips from the bottom upwards, applying some force. This may require a bit of effort, but it ensures the units are securely connected as intended.
- Page 23 Installation guide 18 Connecting to the Coleman Revolution Dual Fuel BBQ - left side. DESCRIPTION IMAGE 1/4”-20UNCx16 φ6*16 Washer...
- Page 24 Installation guide 19 Connecting to the other Coleman Revolution Modules DESCRIPTION IMAGE Clip Connecting Screws were put only in Sink or Storage with no drawer modules package Insert the fastening clips from the bottom upwards, applying some force. This may...
- Page 25 © 2 0 2 3 The Coleman Company, Inc. Coleman are registered trademarks of ® The Coleman Company, Inc. used under license. www.colemanbbqs.com.au...
