Camera Power -

1.
Power-up the camera using the either the AC adapter or place four
AA batteries in the battery-bay of camera.
2.
To use the AC adapter, plug the adapter into a household AC outlet,
open the side compartment door of camera, and connect the adapter
terminal to lower jack, labeled "DC 6V"
3.
To use batteries, slide the battery door in the direction of the arrow,
and insert the batteries noting the proper polarity.
Note: Your ViviCam 2800 has a power management feature designed to extend battery life. The camera
will shut-off automatically if it is left idle for one minute. To "wake-up" the camera, press the shutter
button.
Compartment
door
Taking an Image (A digital picture) -
1. Open the side compartment door and check to see that a Compact Flash (CF) memory card is in the memory card slot.
2. Slide the mode switch to the CAM position.
3. You will hear the camera start-up and the Green LED will illuminate. The Information LCD will indicate "- - -",
battery status, and the current Flash Mode.
4. To turn on the image LCD, press the "DISP." Button. (The image LCD is not required to take an image.)
5. Center your subject in the optical viewfinder, or in the image LCD.
6. Press the shutter button to capture an image. It takes about 10 seconds for the image to be processed and stored.
Note: To use digital zoom, turn on the image LCD and zoom in and out using the T (telephoto) and W (wide) buttons.
Reviewing Your Images -
1. Open the side compartment door and check to see that a Compact Flash (CF) memory card is in
the memory card slot.
2. Slide the mode switch to PLAY.
3. You can review the images on the memory card by pressing the "+", and "-" keys.
Note: To view an image without all the image information, press "DISP."

Setting Flash Mode -

The V2800 has four flash modes, including red-eye reduction. Press the Flash button to
change flash modes. For additional detail, please refer to the User's Manual.

Using the Macro Mode -

The V2800 has a Macro (close focus) feature. It allows you to take an image of an
object as close as five or six inches. Press Macro button select this feature. Refer to the
User's Manual for more detail.
ViviCam 2800 Digital Camera Quick Start –
Information
LCD
LCD
Mode Switch
Green LED
DISP. (Display) Button
Battery
Door
Shutter
CF Card
1

Advertisement

loading

Summary of Contents for Vivitar Vivicam 2800

  • Page 1: Camera Power

    Note: Your ViviCam 2800 has a power management feature designed to extend battery life. The camera will shut-off automatically if it is left idle for one minute. To “wake-up” the camera, press the shutter button.
  • Page 2: Inserting A Cf Card

    Setting Resolution and Image Quality - The ViviCam 2800 provides two resolution modes: Large (1024x768), and Small (640x480); and three quality modes (Good, Better, and Best). You can change resolution and quality at any time. Refer to the User’s Manual for detail.
