- Page 1 Viking Installation Guide Built-In Electric Induction Cooktop Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA...
-
Page 2: General Information
Combustible items may ignite, metallic items may become hot and cause burns. If a cabinet storage is to provided the risk can be reduced by installing a range hood that projects horizontally a minimum of 5 in. beyond the bottom of the cabinets. - Page 3 SPECIFICATIONS - INDUCTION/RADIANT COOKTOP Description Cutout Width Cutout Depth Overall Width Overall Height from Bottom Overall Depth from Rear Electrical Requirements Maximum Amp Usage Surface Element Rating Approximate Shipping Weight 52 lb. (23.4 kg) SPECIFICATIONS - ALL INDUCTION COOKTOP Description Cutout Width Cutout Depth Overall Width...
- Page 4 PROXIMITY TO SIDE CABINET INSTALLATION 1. The cooktop may be installed directly to existing base cabinets. 2. The cooktop CANNOT be installed directly adjacent to sidewalls, tall cabinets, tall appliances, or other side vertical surfaces above 36” (91.4 cm) high. There must be a minimum of 6” (15.2 cm) side clearance from the cooktop to such combustible surfaces above the 36”...
- Page 5 INTERIOR CABINET CLEARANCES I I M M P P O O R R T T A A N N T T : : The electronic components for the induction elements in the cooktop need some air circulation. To ensure long life of electronic components, it is required that a minimum of 8”...
- Page 6 DIMENSIONS INDUCTION/RADIANT COOKTOP 30” W. TOP 30” W. BURNER BOX 30” W. HEIGHT 5 1/4” 6 7/16” (13.3 cm) (16.4 cm) After installation of cooktop, locate the four hold down brackets on each side of the burner box. Screw the sheet metal screw into bracket and tighten firmly against bottom of countertop.
- Page 7 36” W. TOP 36” W. BURNER 18 31/32” (48.2 cm) There are two types of hold down brackets on the 36” w. cooktop. After installing cooktop, locate the hold down brackets around the burner box. Brackets #1 are located on the left side of the burner box and brackets #2 are located on the right side of the burner box.
- Page 8 DIMENSIONS ALL INDUCTION COOKTOP 30” W. TOP 30 3/4” (78.1 cm) 21” (53.3 cm) 30” W. BURNER BOX 18 3/4” (47.6 cm) 30” W. HEIGHT 7 1/2” 4 1/16” 5 1/8” (19.1 cm) (10.3 cm) (13.0 cm) 28 1/2” (72.4 cm) After installation of cooktop, locate the four hold down brackets on each side of the burner box.
- Page 9 36” W. TOP 36 3/4” (93.3 cm) 21” (53.3 cm) 36” W. BURNER BOX 18 3/4” (47.6 cm) 36” W. HEIGHT 7 1/2” 4 1/32” 5 3/16” (10.2 cm) (19.1 cm) (13.2 cm) After installation of cooktop, locate the four hold down brackets on each side of the burner box.
- Page 10 30” W. CUTOUT 30” W. CUTOUT w/ DOWNDRAFT Min. 28 9/16” (72.6 cm) Max. 29 5/8” (75.2 cm) 7/8” (2.2 cm) 28 3/4” (73.0 cm) Min. 19 1/8” (48.6 cm) Max. 19 7/8” (50.5 cm) 27” (68.6 cm) 7/8” (2.2 cm) 2 1/4”...
-
Page 11: Final Preparation
36” W. CUTOUT 36” W. CUTOUT w/ DOWNDRAFT FINAL PREPARATION 1. Some stainless steel parts may have a plastic protective wrap which must be peeled off. 2. All stainless steel body parts should be wiped with hot, soapy water and with a liquid cleaner designed for this material. - Page 12 W W A A R R N N I I N N G G - - T T H H I I S S U U N N I I T T M M U U S S T T B B E E G G R R O O U U N N D D E E D D .
-
Page 13: Wiring Diagram
BLACK POWER BOARD JOUT1 BLACK JOUT2 TEMP CONTROL EMI BOARD BLACK TEMP CONTROL BLACK JOUT3 JOUT4 LEFT SECTION F F O O R R C C O O N N N N E E C C T T I I O O N N T T O O F F A A C C T T O O R R Y Y I I N N S S T T A A L L L L E E D D T T E E R R M M I I N N A A L L B B L L O O C C K K - - U U S S E E C C O O P P P P E E R R O O R R A A L L U U M M I I N N U U M M C C O O N N D D U U C C T T O O R R S S W W A A R R N N I I N N G G - - T T H H I I S S U U N N I I T T M M U U S S T T B B E E G G R R O O U U N N D D E E D D . - Page 16 Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For more product information call 1-888-VIKING1 (845-4641) or visit the Viking Web site at vikingrange.com (PS0506VR) F20112E...
