- Page 1 VG151 ViewPanel ® User Guide Guide de l’utilisateur Bedienungsanleitung Guía del usuario Guida dell’utente Guia do usuário Användarhandbok Käyttöopas Руководство пользователя Podręcznik użytkownika With Plug & Play Full 15.0" Diagonal Viewable Screen...
-
Page 2: Table Of Contents
Setting the Timing Mode ...5 OSD and Power Button Lock Modes...5 Adjusting the Screen Image ...6 Other Information Specifications ...13 Troubleshooting...14 Customer Support ...15 Cleaning the ViewPanel ...16 Limited Warranty ...17 Appendix Safety Guidelines ...18 Compliance Information ...19 CE Conformity ...19 ViewSonic VG151... -
Page 3: Product Registration
® guidelines for energy efficiency. NERGY Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use this product. -
Page 4: Getting Started
• Standard VGA video cable • DVI video cable (to be used with computers with DVI video cards) • AC/DC Adapter • ViewSonic Wizard CD-ROM (including user guide PDF file and INF/ICM display optimization files) The supplied INF file assures compatibility with Windows... -
Page 5: Quick Installation
NOTE: Windows 95, 98 or 2000 users may receive a message asking them to install the VG151 INF file. 4 Install display optimization files (INF and ICM files) (1) Insert the ViewSonic Wizard CD-ROM into your computer’s CD-ROM drive. Remove two back covers ViewSonic... -
Page 6: Using The Viewpanel
• To unlock this mode, press and hold both the [1] button and the again for 10 seconds. ® controls (pages 6 – 10) to adjust the screen image. VESA ® desktop > Properties > ViewSonic ® 1024 x 768 @ 60 Hz (up-arrow) (up- (down arrow) VG151... -
Page 7: Adjusting The Screen Image
Button [1] displays the Main Menu; also saves changes and exits the Main Menu. Scroll Up/Down menu options. ViewSonic VG151 ® controls which display on Main Menu with OnView controls. The status line at the bottom of the menu shows what to do next: Button [1] Exits the menu. - Page 8 The following tips may help you optimize your display: • Adjust your computer's graphic card so that it outputs a video signal 1024 x 768 @ 60Hz to the VG151. (Look for instructions on "changing the refresh rate" in your graphic card's user guide.) •...
- Page 9 Shortcut: From the Windows desktop, press button [2] to bypass the Main Menu and switch ports. On-screen display will show Input Analog or Input Digital, depending upon the currently selected input source. ViewSonic VG151 automatically sizes, centers, auto- Contrast adjusts the difference adjusts background black level of the Brightness...
- Page 10 [1] twice. INFORMATION coming from the graphics card in your computer, the LCD model number, the serial number, and the ViewSonic website URL. See your graphic card’s user guide for instructions on changing the resolution and refresh rate (vertical frequency).
- Page 11 FINE TUNE noise banding, out-of -phase, etc. Try the Auto Image Adjust (see page 8) before using the NOTE: Fine Tune control. adjusts the clarity and focus of the screen image. SHARPNESS ViewSonic VG151...
- Page 12 15 seconds, the display screen disappears. displays the following menu . The controls shown allows you to choose from among several displays the following menu which allows you to move the on-screen display sets the length of time an on-screen display ViewSonic VG151...
- Page 13 Windows desktop, while adjustments are made to the OnView ViewPanel controls. returns adjustments to the original factory MEMORY RECALL settings if the display is operating in a factory Preset Timing Mode listed in this user guide. ViewSonic VG151...
-
Page 14: Other Information
ViewPanel. ® , Macintosh adapter. To order an adapter, contact ViewSonic. 720 x 400 @ 70Hz 832 x 624 @ 75 Hz 640 x 400 @ 70 Hz... -
Page 15: Troubleshooting
Loose or broken pins in the cable connector could cause an improper connection. • Connect the ViewPanel to another computer. • If you have an older graphics card, contact ViewSonic adapter. Control buttons do not work •... -
Page 16: Customer Support
Singapore/Southeast T: 65-273-4018 Asia F: 65-273-1566 Other Asia/Pacific T: 886 2 2248 4072 countries and Indian F: 886 2 2249 1751 Peninsula South Africa T: 27-11-314-0002 F: 27-11-314-0002 Email vstech@viewsonic.com vstech@viewsonic.com ---------------------------- ----------------------------- service.au@viewsonic.com mbarlass@vistech.co.nz service.sg@viewsonic.com service.ap@viewsonic.com atscom@mweb.co.za ViewSonic VG151... -
Page 17: Cleaning The Viewpanel
® cleaners on the ViewPanel screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the ViewPanel. ViewSonic will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. ViewSonic VG151 IS TURNED OFF. -
Page 18: Limited Warranty
How long the warranty is effective: ViewSonic LCD ViewPanels are warranted for three (3) years for all parts including the light source and three (3) years for all labor from the date of the first consumer purchase. -
Page 19: Appendix
L or coloured RED. If you have any questions concerning which proper power cord to use, please consult with the dealer from whom you have purchased the product. ViewSonic VG151 Switzerland... SEV Britain... BASE/BS Japan... Electric Appliance Control Act... -
Page 20: Compliance Information
Install and use the equipment according to the instruction manual. CE Conformity The device complies with the requirements of the EEC directive 89/336/EEC as amended by 92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic compatibility," and 73/ 23/EEC as amended by 93/68/EEC Art.13 with regard to “Safety." ViewSonic VG151... - Page 21 NOTE ViewSonic VG151...
