Using the ViewPanel

Setting the Timing Mode

The timing mode consists of the resolution and refresh rate (vertical frequency).
After setting the timing mode, use the ViewSonic OnView
to make adjustments. The recommended timing mode for this ViewPanel
1280 x 1024 @ 60Hz.
E
N
To set the Timing Mode:
G
L
1 Set the resolution: Right-click on the Windows
I
Settings > Desktop Area > set the resolution (example 1280 x 1024 @
S
H
60Hz).
2 Set the refresh rate: See your graphic card's user guide for instructions.
NOTE: To minimize the adjustments required for an optimal screen image,
select a timing mode from the Preset Timing Modes table below.

Preset Timing Modes

VGA 640 x 350 @ 70Hz
VGA 640 x 400 @ 70Hz
VESA 640 x 480 @ 75Hz
VESA 800 x 600 @ 75Hz
VESA 1024 x 768 @ 75Hz
NOTE: For best image quality, activate AUTO TUNE from the IMAGE
ADJUST menu.
If necessary, from the IMAGE ADJUST menu, make small adjustments using
H POSITION and V POSITION, then PHASE, until the screen image is
completely visible. (The black border around the edge of the screen should
barely "touch" the illuminated "active area" of the ViewPanel.)

Maximum Refresh Rates

1280 x 1024 NI @ 75Hz
1024 x 768 NI @ 75 Hz
(NI= Non Interlaced)
WARNING: Do NOT set the graphics card in your computer to exceed the maximum
refresh rate for each resolution shown below in the Maximum Refresh Rates table.
Doing so may result in permanent damage to your ViewPanel.
Using the ViewPanel
6
®
®
controls in this section
®
desktop > Properties >
VESA 1280 x 1024 @ 60Hz & 75Hz
®
Macintosh 640 x 480 @ 67Hz
®
Macintosh 832 x 624 @ 75Hz
Macintosh ® 1024 x 768 @ 75Hz
800 x 600 NI @ 75Hz
640 x 480 NI @ 75 Hz
ViewSonic VE170/VE170b
®
is:
