- Page 1 Product Instructions Printed Matter No. 6159991160 Date: 2024-01 Issue No. 01 Nutrunner Model: CP8609-B CP8609-BT CP8609-C CP8609-CT CP8609-xC CP8609-xCT WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
General Instructions ...................... 8 Standalone Tools Menu ....................... 8 Maintenance Menu....................... 9 Tools Information Menu ..................... 10 Unit Selection Menu ...................... 10 Operating the tool....................... 10 Service.............................. 12 Preventing ESD Problems...................... 12 Daily Inspection .......................... 12 Maintenance Instruction ........................ 12 Troubleshooting .......................... 13 Troubleshooting.......................... 13 Error Codes ........................... 13 © Chicago Pneumatic - 6159991160... -
Page 3: Product Information
Pneumatic website. Please visit: www.cp.com. Overview Connected Version To unblock functionalities of CP86 connected versions C, CQ and TC, scan the below QR code and download CPLinQ to your device. Connect your tool to CPLinQ app. © Chicago Pneumatic - 6159991160... -
Page 4: Product Description
5) Reverse button 5) Reverse button 6) Principle trigger 6) Principle trigger 7) Cup (Optional accessory - see below) 7) Cup (Optional accessory - see below) Accessories Accessory Part Number Spring Loaded Cup 8940164622 Japanese Cup 8940167401 © Chicago Pneumatic - 6159991160... -
Page 5: Technical Data
W (") L (mm) L (") 14.96 14.96 14.96 14.96 19.5 19.5 L1 (mm) L1 (") 17.2 17.2 19.33 19.33 23.82 23.82 H (mm) H (") H1 (mm) H1 (") 11.22 11.22 11.22 11.22 11.22 11.22 © Chicago Pneumatic - 6159991160... -
Page 6: Service Overview
Product Information Nutrunner Service Overview Disposal • The disposal of this equipment must follow the legislation of the respective country. • All damaged, badly worn or improperly functioning devices MUST BE TAKEN OUT OF OPERATION. © Chicago Pneumatic - 6159991160... -
Page 7: Installation
Remove the white protective sticker and plug the battery to the recommended charger. Battery Installation Attach the battery pack to the tool. Press it until a locking sound can be clearly heard. To remove the battery pack press the button on the battery and push it out. © Chicago Pneumatic - 6159991160... -
Page 8: Operation
2) Battery level/Bluetooth connection (C, CQ, TC version) 3) Button for menu navigation an 3) Action for button 4) Action for button 4) Button for menu navigation an 5) Application Information 5) Action for button 6) Tool 6) Application Information 7) Tool © Chicago Pneumatic - 6159991160... -
Page 9: Maintenance Menu
Press the menu button. Access following menus by pressing navigation buttons. • Maintenance • Tool Infos • Select unit • Calibration When screen shows "Back" on display, press menu button to return on the main menu. Maintenance Menu © Chicago Pneumatic - 6159991160... -
Page 10: Tools Information Menu
Operation Nutrunner Tools Information Menu Unit Selection Menu Operating the tool © Chicago Pneumatic - 6159991160... - Page 11 Press and keep pressure on second trigger. Press and keep pressure on principal trigger. Keep the triggers pressed till the end of the operation. 10. Check the operation status on reporting LEDs. • Green - OK • Red - Not OK © Chicago Pneumatic - 6159991160...
-
Page 12: Service
• Use clean clothes to remove dirt, dust, oil, grease, etc. • After the cleaning, inspect all parts. Replaced damaged and worn parts immediately. © Chicago Pneumatic - 6159991160... -
Page 13: Troubleshooting
Torque higher than maximum autho- rized OR angle not achievable because of tool capacity exceeded The tool has detected a rehit. You are probably trying to tighten an already tightened bolt © Chicago Pneumatic - 6159991160... - Page 14 Replace battery by fully loaded battery as soon as possible. For battery wake up procedureInstallation Instruction Level of battery is under 5% Replace battery by fully loaded battery, tool will turn off (refer to battery wake up procedure if needed) © Chicago Pneumatic - 6159991160...
- Page 15 CP representative for support. The tool is out off functional tempera- 1. Wait the tool cool down ture range. 2. Reduce duty cycle 3. If the problem occurs again, contact your CP representative for support. © Chicago Pneumatic - 6159991160...
- Page 16 Original instructions ABOUT CHICAGO PNEUMATIC At Chicago Pneumatic, we have a passion for performance and long- lasting partnerships with our customers in industrial applications, construction, infrastructure and maintenance. Since 1901, we have been committed to reliability based on technology and trust.
