Chapter 2
c. Locate an available PCIE slot ( X1, X4, X8, or X16) and carefully insert the
adapter.
Tip:
If the bracket is not suitable for your computer, detach it from the adapter's board and replace it with the
low-profile bracket.
d. Locate an available F_USB connector and carefully plug the Bluetooth USB
cable into it.
Note:
If the Bluetooth USB cable is not correctly connected to the motherboard, Bluetooth function won't work
even after driver installation.
e. Install the antennas on the magnetized antenna base, then connect the base to
the adapter.
Tip:
• To maximize performance, make sure the path between the antenna and your router is clear.
• DO NOT connect one SMA male connector directly to another with wires or other conductors to prevent
short circuits or adapter damage.
Connect to a Computer
B
U S
B
U S
08
