Jensen XA4150 How To Install And Operate

Contents
JENSEN
How to Install and Operate
the XA4150 Amplifier
Welcome!
What you're holding in your hands is no ordinary
owner's manual. We've tried to make the instructions
in this book clear and easy to follow.
For your Jensen amplifier to work right, it must be
installed correctly. This manual will show you how to
install your new amplifier like a pro. It's a good idea to
read all of these instructions before you begin the
installation. Most installations are straightforward and
can be handled by a do-it-yourselfer with the right
tools, patience, and the ability to follow instructions.
But, do-it-yourself installation isn't for everyone. If you
still don't feel confident after reading this book,
consider turning the installation Job over to someone
better suited to it
Warranty Service
If your Jensen amplifier should ever require service,
you will need to have the original dated receipt If you
ever need to return the unit for any reason, always
include the receipt with the product
Technical Assistance
For technical assistance with the operation or installation
of the XA4150, call 1-800-323-0221.
Features.2
Installation.2
Before You Begin
Installation.2
Amplifier Location.2
Disconnect Battery.2
•
Amplifier Installation Kit
.
2
Supplies and Tools
Needed.3
Routing Wires.3
•
Bigger is Better
.
3
Wiring.4
Power and Outputs.4
Power Terminal (BATT +12V).4
Ground Terminal (GND).4
Remote Terminal (RMT +12V).4
Fuses.4
Inputs and Controls.5
Input Wiring.5
Pass Output.5
Power Light.5
Protect Light.5
Input Level Control.6
Bass Boost.6
Crossover.6
Speaker Wiring.7
Tasting.9
Reconnect Battery.9
Test Power Wiring.9
Test Speaker Connections.9
•
Dealing with Alternator
Noise
.
9
•
Installing in Trunk
.
10
•
Crimp Connections
.
10
•
Securing Wires
.
10
•
Speaker and
Power Wires
.
10
Troubleshooting.11
Specifications
and Warranty.12
