Instruction Sheet
Kit Number: 79614000
79614000 - ELECTRIC SNOW PLOW LIFT KIT
For use on Snow Plow Kits 796138 and 796139
For Gravely Models: 996120, 996140, 996141
For Treker Models: NT and ST
WARNING: FAILURE TO FOLLOW
INSTRUCTIONS could result in personal
injury and/or damage to unit.
Read, understand, and follow all safety
practices in Owner/Operator Manual before
beginning.
These instructions contain only information required to
assemble the kit to the unit. Read these instructions and
the Owner/Operator Manual thoroughly before beginning.
The Owner/Operator manual may include important
operation, adjustment, troubleshooting and maintenance
information for this and other accessories.
Parts and Owner/Operator Manuals can be downloaded
or ordered from www.gravely.com or by calling Ariens'
Technical Service at 888-927-4367. Model and serial
numbers are required to look up necessary manuals.
CAUTION: Read, understand, and follow all
instructions and safety precautions before
beginning.
Parts List
Check the contents of your kit for the parts listed
(figure 1). Contact your local authorized Gravely Treker
dealer for any missing hardware.
© Copyright 2009 • Ariens Company • Brillion, WI 54110-1072
79614000 Kit
Part Number
Item
1
EL100B
2
EL120
3
EL121A
4
EL003
5
EL122A
6
PUR1481
7
CC18
8
U605
9
EL123
10
EL124
11
05967100
12
05948700
13
ELRELAY
14
WNRSHOUSING 1
15
WNRSWITCH-3
16
CVC1316
17
SW10
18
06442700
19
06116900
20
800-112C
21
839-288C
22
SCOTCHLOCK
23
EL136
24
EL119
25
STS10-212
26
EL137
27
801-172C
28
06535800
29
06531000
30
0653600
Qty. Description
1
Gear Motor
1
Gear Pulley
1
Motor Mount Plate
4
1-1/4 in. Spacer
1
Bearing Plate
1
Lift Strap
1
1/8 in. Cable Clamp
1
3/16" Quick Link
1
36" Cable
1
O-Ring
2
1/4-20 x 2.00 Hex Bolt
2
3/8-16 x 1.00 Hex Bolt
1
Relay
Switch Housing
1
R-3 Switch
1
13/16 in. Cable Clamp
1
#10 Star Washer
1
.219 x .50 x .049 Flat
Washer
1
10-24 x 3/4 Hex
Washer Head Machine
Screw
6
Cable Tie .19 x 7.25
1.75D 50lb.
1
20 Amp Fuse (5 Pack)
1
TM
Scotchlok
Connector
1
O-Ring
1
Electrical Lift Pig Tail
2
#10 2-1/2" Self-Tapping
Screw
1
Wiring Harness
1
Hex Screw
2
3/8-16 Locking Nylon
Nut
2
1/4-20 Locking Nylon
Nut
1
10-24 Nylon Locking
Nut With Insert
03936900 6/09 Page 1 of 4
Advertisement
Summary of Contents for Ariens 79614000
- Page 1 #10 2-1/2" Self-Tapping Screw EL137 Wiring Harness 801-172C Hex Screw 06535800 3/8-16 Locking Nylon 06531000 1/4-20 Locking Nylon 0653600 10-24 Nylon Locking Nut With Insert © Copyright 2009 • Ariens Company • Brillion, WI 54110-1072 03936900 6/09 Page 1 of 4...
- Page 2 2. Attach the lift strap (item 6) to the front of the unit directly above the cable spool of the electric lift. Mount so that the end of the strap is approximately 20 in. above the ground. 3. Attach the 3/16 in. quick link (item 8) to the end of the strap (item 6).
- Page 3 Spool Figure 4 Figure 5 4. Route the red/white and black wires to the battery. 14. Run the spool in the direction needed to result in CAUTION: Ensure that all wires are routed one wrap of cable on the spool and the cable to the away from moving parts, hot components or front of the spool.
- Page 4 Figure 6 03936900 6/09 Page 4 of 4...
