Valid for the following tractor models:
For tractors with cab or with ROPS fra-
me, model:
MF2430 STD-GE
MF2435 STD-GE
MF2440 STD-GE
Operation and maintenance manual
CONTENTS
TRACTOR IDENTIFICATION
INTRODUCTION, WARRANTY AND SAFETY
NOTES
INSTRUMENTS AND CONTROLS
OPERATION
ROUTINE MAINTENANCE
SPECIFICATIONS
ALPHABETICAL INDEX
MF2400
CHAPTER
Publication N. 3676 146 M1
Printed 2004
1
2
3
4
5
6
7
1
Advertisement
Table of Contents
Related Manuals for MASSEY FERGUSON MF2400 Series
Summary of Contents for MASSEY FERGUSON MF2400 Series
- Page 1 MF2400 Operation and maintenance manual CHAPTER Valid for the following tractor models: CONTENTS For tractors with cab or with ROPS fra- TRACTOR IDENTIFICATION me, model: MF2430 STD-GE MF2435 STD-GE MF2440 STD-GE INTRODUCTION, WARRANTY AND SAFETY NOTES INSTRUMENTS AND CONTROLS OPERATION ROUTINE MAINTENANCE SPECIFICATIONS ALPHABETICAL INDEX...
- Page 2 MF2430 STD-GE MF2435 STD-GE MF2440 STD-GE CALIFORNIA Proposition 65 - Warning Diesel engine exhaust and some of its constituents are known to the Sta- te of California to cause cancer, birth defects, and other reproductive harm. Find manuals at https://best-manuals.com...
-
Page 3: Table Of Contents
Contents Page n. Chapter 1 Contents ....................3 Tractor identification ................6 Chapter 2 Introduction, warranty and safety notes ..........7 Introduction ..................... 8 Warranty, pre-delivery and installation ............8 Warranty procedure ................. 8 Parts warning ................... 9 Of you move .................... 9 Service after warranty ................ - Page 4 Contents Page n. Chapter 4 Operation ....................51 Starting and stopping the engine ............52 Starting the tractor ................. 53 Clutch ..................... 54 Standard gearbox .................. 54 Speedfive ....................55 Speedshift gearbox ................57 Speedfive - Speedshift: Ground speed tables ........58 Powershuttle gearbox ................
- Page 5 Contents Page n. Chapter 6 Tractor specifications ................151 Weights and dimensions ..............152 Engine ....................154 Transmission ..................155 Power take-off ..................156 Brakes ....................156 Track adjustment ................. 156 Steering components ................156 4WD front axle ..................157 Hydraulic system .................
-
Page 6: Tractor Identification
Tractor identification Tractor identification The tractor is identified by a serial number stamped on the rear part of the transmission housing and on the bonnet. Each engine has a serial number of its own, stamped on the engine block. Always state the chassis and engine serial numbers to ensure prompt and efficient service when ordering spare parts or when asking for technical explanations or other information. -
Page 7: Introduction, Warranty And Safety Notes
Introduction, warranty and safety notes Chapter 2 Introduction, warranty and safety notes Find manuals at https://best-manuals.com... -
Page 8: Introduction
Introduction and warranty INTRODUCTION Compliance with, and strict adherence to, the conditions of operation, service and repair as specified by the manufacturer also constitute essential elements for the NOTE: This book is published for worldwide distribution, intended use. and the availability of equipment shown either as basic or accessory may vary according to the territory in which the These tractors should be operated, serviced and repaired tractor is to be operated. -
Page 9: Warranty Procedure
Introduction and warranty WARRANTY PROCEDURE SERVICE AFTER WARRANTY Correct installation, coupled with regular maintenance, During the warranty period, you should have all your will do much to prevent breakdowns. If, however, repairs and maintenance performed by your Dealer. This operating trouble is experienced during the warranty ensures that a detailed check is kept on the progress and period, the following procedure must be adopted:- performance of your new tractor. -
Page 10: Safety Alert Symbols And Terms
Safety notes SAFETY ALERT SYMBOLS AND TERMS This safety alert symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! The safety alert symbol identifies important safety messages on machines, safety signs, in manuals or elsewhere. When you see this symbol, be alert to the possibility of personal injury or death. Follow the instructions in the safety message. -
Page 11: Safety - Danger, Warning And Caution
Safety notes Keep in mind that this safety section is written only for SAFETY - FOLLOW A SAFETY this type of machine. Practice all other usual and PROGRAM customary safe working precautions, and above all - For safe operation REMEMBER - SAFETY IS YOUR RESPONSIBILITY. YOU For safe operation of an agricultural tractor, you must be CAN PREVENT SERIOUS INJURY OR DEATH. -
Page 12: Safety Frame
Safety notes SAFETY FRAME A Safety Structure and seat belt is fitted as standard equipment to the platform tractor at the time of factory assembly. If the safety frame was deleted by the original purchaser or has been removed, it is recommended that you equip your tractor with a Safety Structure and a seat belt. -
Page 13: Precautions To Operate Safely
Safety notes SAFETY - PREPARE FOR SAFE OPERATION Protect yourself Wear all the protective clothing and personal safety devices issued to you or called for by job conditions. Don't take chances (Fig. 2-3). You may need: • A hard hat. •... -
Page 14: Check The Equipment
Safety notes Use all available protective devices Keep all protective devices in place and securely fastened. Make certain all guards, shields and safety signs are properly installed, as specified, and are in good condition. To help keep you and others around you safe, your To help keep you and others around you safe, your To help keep you and others around you safe, your To help keep you and others around you safe, your... -
Page 15: Clean The Tractor
Safety notes • Stop the engine and wait for it to cool before refuelling. • Check the engine oil level and add oil if required. • Perform all maintenance procedures outlined in the maintenance and adjustment section of this manual. •... -
Page 16: Protect The Environment
Safety notes Protect the environment SAFETY - SERVICING THE • It is illegal to pollute drains, water courses or soil. Use TRACTOR authorized waste disposal facilities, including civic • amenity sites and garages providing facilities for DO NOT service the tractor while the engine is running disposal of used oil. -
Page 17: Safety - Starting
Safety notes SAFETY - STARTING Warn bystanders before starting. Before starting, walk all around the tractor and any attached equipment. Make sure that no one is under it, on it, or close to it. Let other workers and bystanders know you are starting up and don't start until everyone is clear of the tractor, implements and towed equipment. - Page 18 Safety notes Follow recommended starting procedures Follow the starting procedures recommended in the Operation section of this Operator Instruction Book. This includes normal starting, cold starting, and the use of starting fluids. Test the controls. After starting, re-check all gauges and lights. Make sure everything is functioning correctly.
-
Page 19: Work Safely
Safety notes SAFETY - WORK SAFELY Do not start the tractor without ensuring a perfect command of speed and steering controls (Fig.2-14). WARNING: An unbalanced tractor could overturn and cause injury or death. Make sure front frame counterweights, wheel weights and wheel ballast are used as recommended by the manufacturer. -
Page 20: Watch Out For Others
Safety notes Watch out for others • Be aware of what is going on. Never allow an untrained or unqualified person to operate your tractor. They could injure themselves or someone else. WARNING: Your tractor is a one-person machine. DO NOT permit others to ride on the tractor or the implement (Fig. -
Page 21: Ris Of Overturning
