- Page 1 OWNER’S MANUAL Mini Hi-Fi Audio Please read this manual carefully before operating your set and retain it for future reference. MODEL OK99M www.lg.com 2308_Rev01 Copyright © 2023 LG Electronics Inc. All Rights Reserved.
- Page 2 Getting Started Safety Information CAUTION: Do not block any ventilation openings. Install in accordance with the manufacturer’ s instructions. Slots and openings in the cabinet are provided for CAUTION ventilation and to ensure reliable operation of the RISK OF ELECTRIC SHOCK product and to protect it from over heating.
- Page 3 Getting Started CAUTION concerning the Power Cord CAUTION: No naked flame sources, such as lighted candles, should be placed on the apparatus. The Power Plug is the disconnecting device. In case of an emergency, the Power Plug must remain readily Symbols accessible.
-
Page 4: Table Of Contents
– Listening to music stored on the Bluetooth – USB Connection devices Using the LG XBOOM App – About “LG XBOOM” App – Install “LG XBOOM” App onto Your Bluetooth Device – Activate Bluetooth with “LG XBOOM” App Sound adjustment – Setting the sound mode –... - Page 5 – LIGHTING – Sleep Timer Setting – Dimmer – AUTO POWER On – Auto function change Setting the Clock – Setting the Clock through “LG XBOOM” App WIRELESS PARTY LINK Connection Troubleshooting Troubleshooting – General – NOTES to release Demo mode...
-
Page 6: Getting Started
USB Direct Recording Records music to your USB device. LG XBOOM LG XBOOM is an app designed to let you take control of some of LG’ s latest audio devices. (Page 29-30) LG Sound Sync Controls volume level of this unit by the remote control of your LG TV that is compatible with LG Sound Sync. -
Page 7: Playable File Requirement
Getting Started Playable file Compatible USB Devices y MP3 Player: Flash type MP3 player. Requirement y USB Flash Drive: Devices that support USB2.0 or USB1.1. y The USB function of this unit does not support all Music file requirement USB devices. MP3/WMA file compatibility with this unit is limited as follows. -
Page 8: Remote Control
AUX 1 AUX input AUX 2 Bluetooth BLUETOOTH LG Sound Sync (Wireless) LG TV VOL (Volume) +/-: Adjusts speaker volume. J(Information) : - Sees information about your music. An MP3 file often come with ID3 tag. The tag gives the Title, Artist, Album or Time information. - Page 9 Getting Started • • • • • • • • • • • • • • b • • • • • • • • • • • • • • • • • • • • • • • • • • • c • • • • • • • • • • • • • REPEAT: Listens to your files repeatedly or randomly.
-
Page 10: Top Panel
AUX input AUX 2 - Skips backward or forward. Bluetooth BLUETOOTH - Searches for a section within a file. LG Sound Sync (Wireless) LG TV N (Play/Pause) Starts or pauses playback. d HEADPHONE IN jack USB 1 Port Sets cue point on DJ STAR mode. - Page 11 Selects a desired DJ EFFECT. (If you want to use USER, you have to register a DJ LOOP source with “LG XBOOM” app.) Selects DJ LOOP mode. 1, 2, 3 (DJ PAD) (DJ LOOP mode can use during USB playback.) Press a desired sound pad.
-
Page 12: Front Panel / Rear Panel
(Auto Music Play) Plays the audio currently playing by tagging the f AUX IN 2 (L/R): Connect an auxiliary device. mobile (with “LG XBOOM” App) to this unit. g AUX IN 1: Connect a portable device. (Android Only) h AC IN socket b MIC (Microphone) 1/2 jack >... -
Page 13: Carrying The Unit
Press and hold N on the remote control or Bluetooth device only on N on the side 1 of the unit for 5 seconds in (Page 28) BLUETOOTH and LG TV BLUETOOTH function. functions. Press and hold N on the remote control or... -
Page 14: Connecting
Connecting AC Power Cord Optional Equipment Connection Connection 1. Connect one end of the AC power cord (included) AUX IN 1 Connection to the AC IN socket. Connect an output (earphone or line out) of portable device (MP3 or PMP etc.) to the AUX IN 1 (3.5 mm) connector. -
Page 15: Aux In 2 Connection
Connecting AUX IN 2 Connection Listening to music from your portable player or external Connect an output of auxiliary device (Camcorder, TV, device Player, etc) to the AUX IN 2 (L/R) connector. If your device has only one output for audio (mono), connect The unit can be used to play the music from many it to the left (white) audio jack on the unit. -
Page 16: Lg Sound Sync
TV.) You can control some functions of this unit by your TV’ s remote control with LG Sound Sync. It is y If the connection fails, check the conditions of compatible with LG TV that supports LG Sound Sync. -
Page 17: Usb Connection
Connecting USB Connection Connect a USB device (or MP3 player, etc.) to the USB ports on the unit. USB device Note Removing the USB device from the unit: 1. Choose a different function/mode or press Z twice in a row. 2. -
Page 18: Operating
Operating Basic Operations Note y Repeat/Shuffle playback operates as follows. On Display Description USB Operations Plays songs in order, and stops 1. Connect the USB device to the USB port. the playback. 2. Select USB function by pressing 2. Plays a same song repeatedly. Plays songs in a folder FOLDER Do this... -
Page 19: Selecting A Folder And An Mp3/Wma File
Operating Selecting a folder and Note y USB Folders/Files are recognized as below. an MP3/WMA file On the unit 1. Press SEARCH and rotate REAL SCRATCHER / SEARCH & LEVEL CONTROL on the side 1 (or rotate REAL SCRATCHER / SEARCH & MULTI on the side 2) or C/V until a desired file appears. -
Page 20: Deleting A File/Folder Or Format
Operating Playback Effect Deleting a file/folder or format You can delete file, folder on your USB or format the The unit supports various sound and playback USB. effects: DJ EFFECT, DJ SCRATCHER, AUTO DJ, DJ PAD, 1. Select USB function by pressing 2. DJ LOOP, PARTY ACCELERATOR, MIX, TEMPO, AUTO 2. -
Page 21: Dj Scratcher
Operating Note On Display Description y The DJ EFFECT mode is displayed for 3 As an audio effect using phase seconds when a DJ EFFECT key on the unit FLANGER difference, it gives delay effect to is inputted. the sound signal. y The current gage level is displayed when As an audio effect using phase adjusting gage. -
Page 22: Auto Dj
On Display Description Note y If you want to use USER, you have to register a source with “LG XBOOM” app. If the The music is played randomly on source is not register to USER, “USER MODE SHUFFLE this mode. -
Page 23: Dj Loop
PARTY ACCEL CLIMAX Note If you want to use USER, you have to register a source with “LG XBOOM” app. If the source is not register to USER, “PARTY ACCEL EMPTY” or “PARTY ACCEL NO SOUND” appears on the display window. -
Page 24: Mix
Operating TEMPO You can mix audio sounds. You can adjust the Tempo for USB function from 50 (MIN) to 150 (MAX). 1. Press MIX on the unit. “MIXER ON” is displayed. Select a desired Rotate TEMPO A on the unit to adjust the tempo for function for side 1 and play it. -
Page 25: Dj Star
Operating DJ STAR REAL SCRATCHER DJ STAR mode combines various effect mode to You can control playback point to backward or experience professional DJ effect. forward in DJ STAR mode. 1. Press DJ STAR on the unit. Rotating REAL SCRATCHER / SEARCH & LEVEL CONTROL or REAL SCRATCHER / SEARCH &... -
Page 26: Using Bluetooth® Wireless Technology
Version: 4.0 found may appear in the Bluetooth device y Codec: SBC, AAC display depending on the type of Bluetooth device. Your unit appears as “LG OK99M (XX)” . Bluetooth Profiles Note In order to use Bluetooth wireless technology, y XX means the last two digits of devices must be able to interpret certain profiles. - Page 27 Bluetooth connection will be disconnected try pairing it again. when you change the Bluetooth function to some other function. In “LG XBOOM” app y Even if this unit is connected to up to 3 connection, only one device which you are Bluetooth devices in the Bluetooth mode, playing keeps Bluetooth connection.
- Page 28 Bluetooth connection lock (BT LOCK) You can limit Bluetooth connection to only BLUETOOTH and LG TV function to prevent unintended Bluetooth connections. To turn this function on, press and hold N on the remote control or N on the side 1 of the unit for about 5 seconds in BLUETOOTH function.
-
Page 29: Using The Lg Xboom App
Operating Using the LG XBOOM Install “LG XBOOM” App onto Your Bluetooth Device There are two ways to install “LG XBOOM” App onto Your Bluetooth Device. Note Install “LG XBOOM” App through QR y Only Android OS is available to use “LG XBOOM”... -
Page 30: Activate Bluetooth With "Lg Xboom" App
Store)” icon. Tap “LG XBOOM” app icon on the home screen to 2. In the search bar, type in the “LG XBOOM” and open “LG XBOOM” app, and go to the main menu. search it. Note 3. -
Page 31: Sound Adjustment
Operating Sound adjustment You can select a desired sound mode by using SPECIAL EQ on the remote control or the unit. On Display Region Description Setting the sound mode This system has a number of pre-set equalizers. The FUNK, REGUETON, displayed items for the equalizer may be different SAMBA, Latin... -
Page 32: Advanced Operations
Operating Advanced Operations To stop recording To stop recording, press USB REC on the remote control or USB REC / DEMO on the unit. Recording to USB To select recording bit rate You can record a various sound source to USB. 1. - Page 33 Multi card reader device or external HDD can y When function is set to BLUETOOTH or LG not be used for USB recording. TV, recording is available in MIXER ON mode. y A file is recorded by about 512 Mbyte when y VOICE CANCELLER or KEY CHANGER you record for a long term.
-
Page 34: Other Operations
Operating Other Operations Using Microphone 1. Connect your microphone to the MIC jack. 2. Play the music you want. Turn off the sound temporarily 3. Sing along with the accompaniment. Adjust the microphone volume by rotating MIC VOLUME Press [ on the remote control to mute your sound. clockwise or counterclockwise on the unit. - Page 35 Operating VOICE CANCELLER KEY CHANGER You can adjust the key to 9 steps (4 steps higher, 4 You can reduce the vocal tones during music steps lower and the original key). playback from various input sources. Press the VOICE CANCELLER and “VOICE y To make the key more sharp, one by one, press CANCELLER ON”...
-
Page 36: Using H/P Mode
Operating VOCAL EFFECTS ECHO When you connect your microphone to the MIC jack, When you connect your microphone to the MIC jack, you can enjoy karaoke function by changing voice in you can give an echo effect to the sound from the the various source. -
Page 37: Lighting
If you want to use MY STYLE, you have to Dimmer register a source with “LG XBOOM” app. Press SLEEP on the remote control once. y Do not look directly at the light emitting part The display window will be darkened by half. -
Page 38: Auto Power On
When you turn off this unit by pressing 1 on the y If you try to connect to the “LG XBOOM” app, unit for 5 seconds each time, you can turn on or off Bluetooth function of this unit is turned on. -
Page 39: Auto Function Change
When LG TV is connected When you turn on your LG TV connected by LG Sound Sync (Wireless connection), this unit changes the function to LG TV. You can hear the sound from your TV. Note y This function is not available during recording or deleting. -
Page 40: Setting The Clock
8. Press SET on the remote control. Setting the Clock through “LG XBOOM” App Install “LG XBOOM” app on your Android device. (Page 29-30) Your unit’ s clock will be automatically synchronized with your device by activating Bluetooth connection through “LG XBOOM”... -
Page 41: Wireless Party Link Connection
Operating WIRELESS PARTY LINK Note y If you are using the LG Sound Sync, this Connection function is not available. If you connect the LG TV function, “NOT SUPPORT” appears in the display window. You can enjoy the sound by using two speakers. -
Page 42: Troubleshooting
Replace the batteries with new ones. No speaker light. y Check the light effects by pressing LIGHTING. (Page 37) y Check whether your LG TV supports LG Sound Sync. LG Sound Sync does not y Check connection of LG Sound Sync. -
Page 43: Notes To Release Demo Mode
Troubleshooting NOTES to release Demo mode Problem Cause & Solution Can not change input source with ‘2’ key such as BLUETOOTH, USB etc. and only DEMO mode is y Press ‘DEMO’ Key on the unit for 15 seconds. showing in the display. Remote Control does not work properly. -
Page 44: Appendix
Appendix General specifications General Power requirements Refer to the main label on the unit. Power consumption Refer to the main label on the unit. Dimensions (W x H x D) Approx. 430.0 mm x 1,050.0 mm x 400.0 mm Operating temperature 5 °C to 35 °C Operating humidity 5 % to 60 % RH... -
Page 45: Trademarks And Licenses
Trademarks and licenses The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners... -
Page 46: Maintenance
Appendix Maintenance Handling the Unit When shipping the unit Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory. Keeping the exterior surfaces clean Do not use volatile liquids such as insecticide spray near the unit.
