Enterasys S-Series
®
S1 Chassis
Hardware Installation Guide
P/N 9034638-01

Advertisement

Table of Contents
loading

Related Manuals for Enterasys S Series

Summary of Contents for Enterasys S Series

  • Page 1 Enterasys S-Series ® S1 Chassis Hardware Installation Guide P/N 9034638-01...
  • Page 3 Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made.
  • Page 4 Regulatory Compliance Information Federal Communications Commission (FCC) Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 5 It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please go to www.enterasys.com/support/ or contact Enterasys Customer Support at 353 61 705586 (Ireland). Battery Notice This product contains a battery used to maintain product information.
  • Page 6 SJ/T 11363-2006 standard. This table shows where these substances may be found in the supply chain of Enterasys’ electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
  • Page 7 Safety Information Class 1 Laser Transceivers The single mode interface modules use Class 1 laser transceivers. Read the following safety information before installing or operating these modules. The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the need for maintenance checks or adjustments.
  • Page 8 EC Directive 2006/95/EC EN 60950-1:2006 A11:2009 A1:2010 EN 60825-1:2007 EN 60825-2:2004 A1:2007 Equipment Type/Environment: Information Technology Equipment, for use in a Commercial or Light Industrial Environment. Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives.
  • Page 9 CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc., on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware (including any accompanying documentation, hardware or media) (“Program”) in the package...
  • Page 10 Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to enforce a term upon Your breach of such term shall not be construed as a waiver of Your breach or prevent enforcement on any other occasion.
  • Page 11 14. TERMINATION. Enterasys may terminate this Agreement immediately upon Your breach of any of the terms and conditions of this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return...

  • Page 13: Table Of Contents

    Contents About This Guide Who Should Use This Guide ..........................xv How to Use This Guide .............................xv Related Documents ............................xvi Typographical Conventions ..........................xvi Getting Help ..............................xvii Chapter 1: Introduction Overview ................................. 1-1 AC Power Supplies ............................1-2 Fans ................................1-2 USB Port .................................
  • Page 14 Appendix B: Installing the S1-MOUNT-KIT Required Tools ...............................B-1 Contents of S1-MOUNT-KIT ...........................B-2 Removing the Mounting Brackets from the S1 Chassis .................B-2 S1-MOUNT-KIT Mounting Options .........................B-3 Front Mounting the S1 Chassis in a Four-post Rack ..................B-3 Mounting the S1 Chassis in a Two-Post Rack ....................B-5 Disassembling the Rails ...........................B-6 Front Mounting the S1 Chassis in a Two-post Rack ................B-7 Mid-Mounting the S1 Chassis in a Two-Post Rack ................B-10...
  • Page 15 Power Supply LED Status Definitions ....................3-3 Troubleshooting Checklist ........................3-3 Specifications .............................A-1 COM Port Pin Assignments ........................A-2 Compliance Standards ........................A-2 Contents of S1-MOUNT-KIT.......................B-2 Powered Device Classifications ......................C-1 Airborne Dust Specification for Enterasys Equipment — Airborne Dust Maximum Values....D-6 xiii...

  • Page 17: About This Guide

    A brief summary of each chapter • Definitions of the conventions used in this document • Instructions regarding how to obtain technical support from Enterasys Networks. To locate information about various subjects in this guide, refer to the following table. For... Refer to...

  • Page 18: Related Documents

    Related Documents Related Documents The Enterasys S-Series Configuration Guide and Enterasys S-Series CLI Reference Guide provide information on how to use the CLI to set up and manage the S1 chassis. These manuals can be obtained from the World Wide Web in Adobe Acrobat Portable Document Format (PDF) at the following site: https://extranet.enterasys.com/downloads...

  • Page 19: Getting Help

    Getting Help Getting Help For additional support related to the S1 chassis or this document, contact Enterasys Networks using one of the following methods: World Wide Web http://www.enterasys.com/support Phone 1-800-872-8440 (toll-free in U.S. and Canada) or 1-978-684-1888 For the Enterasys Networks Support toll-free number in your country: http://www.enterasys.com/support...
  • Page 20 Getting Help xviii About This Guide...

  • Page 21: Overview

    Introduction This chapter provides an overview of the capabilities of the Enterasys S-Series S1 chassis. For information about software features of the S1 chassis and how to configure them, refer to the Enterasys S-Series Configuration Guide. Overview The S1 chassis is a one-slot chassis in which you can install an S-Series I/O fabric module. The S1 chassis supports the S130, S150, and S155 classes of I/O fabric modules.

  • Page 22: Ac Power Supplies

    For information on connecting to the USB port, refer to the Enterasys S-Series CLI Reference Guide. Note: The USB port on the S1 chassis is not used for out-of-band management.

  • Page 23: Management

    (Communication) port on the front panel using a PC, a VT terminal, or a VT terminal emulator. For more information, see “Connecting to the COM Port for Local Management” on page 2-10. Enterasys S-Series S1 Chassis Hardware Installation Guide 1-3...
  • Page 24 Management 1-4 Introduction...

  • Page 25: Chapter 2: Installing The S1 Chassis

    Read the Release Notes specific to the firmware image running in the chassis to check for any exceptions to the supported features and operation documented in this guide. Required Tools • ESD wrist strap (included with the S1 chassis) • Phillips screwdriver Enterasys S-Series S1 Chassis Hardware Installation Guide 2-1...

  • Page 26: Unpacking The S1 Chassis

    S1 chassis in an equipment rack, you must supply at least eight rack screws. Inspect the S1 chassis for any signs of physical damage. If there are any signs of damage, DO NOT install the S1 chassis; instead, contact Enterasys Networks. Refer to “Getting...

  • Page 27: Installation Site Requirements

    Adhere the rubber feet to the round, recessed areas on the bottom of the S1 chassis. You can now unpack and install the S1 chassis power supplies. See “Unpacking the Power Supplies” on page 2-5 and “Installing the Power Supplies” on page 2-5. Enterasys S-Series S1 Chassis Hardware Installation Guide 2-3...

  • Page 28: Front Mounting The S1 Chassis In A Rack

    Mounting the S1 Chassis Front Mounting the S1 Chassis in a Rack You can front mount an S1 chassis in an equipment rack using the mounting brackets attached to the S1 chassis. Note: The S1 chassis does not ship with mounting screws. You must supply at least eight screws to install the S1 chassis in a rack (four screws in each mounting bracket).

  • Page 29: Unpacking The Power Supplies

    2-2. Remove the power supply from its protective plastic bag. Examine the power supply carefully, checking for damage. If there are any signs of damage, DO NOT install the power supply; instead, contact Enterasys Networks. Refer to “Getting Help”on page xvii for details.

  • Page 30: Installing A Power Supply

    Installing the Power Supplies Figure 2-2 Installing a Power Supply If you are installing a second power supply, remove the coverplate from the bottom power supply bay (labeled PS2) by unscrewing the screws that attach the coverplate to the S1 chassis, as shown in Figure 2-3.

  • Page 31: Powering Up The S1 Chassis

    The PWR LED, located on the front panel, turns ON (green). If you have an I/O fabric module installed, the CPU LED turns red until the S1 chassis completes its initialization. When the initialization process is successful, the CPU LED turns green. Enterasys S-Series S1 Chassis Hardware Installation Guide 2-7...

  • Page 32: Removing A Power Supply

    Removing a Power Supply Removing a Power Supply To remove a power supply from the S1 chassis: Note: Ensure that you use appropriate ESD protection when handling the power supplies. Unplug the associated power cord from the AC outlet. Remove the zip tie, if present, that secures the associated power cord to the S1 chassis. Unplug the associated power cord from the AC inlet.

  • Page 33: Removing And Installing A Fan Tray

    Loosen the captive screws located at the right of the fan tray. Slowly slide the fan tray out of its slot in the chassis. See Figure 2-5. Figure 2-5 Removing the Fan Tray Captive screw (2) Fan tray handle Enterasys S-Series S1 Chassis Hardware Installation Guide 2-9...

  • Page 34: Installing The Fan Tray

    S1 chassis in the equipment rack. For information on installing a fabric module and connecting a fabric module to the network, refer ® to the Enterasys S-Series I/O Module Hardware Installation Guide. Connecting to the COM Port for Local Management This section describes how to install a UTP cable with RJ45 connectors and adapters to connect a PC or VT series terminal to an S1 chassis to access Local Management.

  • Page 35: Connecting To A Pc Or Laptop

    8 Bits, No Parity Stop Bit 1 Stop Bit When these parameters are set, the Local Management password screen will display. Refer to “Completing the Installation” on page 2-12 for further information. Enterasys S-Series S1 Chassis Hardware Installation Guide 2-11...

  • Page 36: Adapter Wiring And Signal Assignments

    By default, the S1 chassis is configured with three user login accounts: ro for Read-Only access; rw for Read-Write access; and admin for super-user access to all modifiable parameters. The default password is set to blank (null). For information on changing these default passwords, refer to the Enterasys S-Series Configuration Guide 2-12 Installing the S1 Chassis...
  • Page 37 S1 chassis prompt appear as shown above. The S1 chassis is now ready to be configured. For information about setting the IP address and configuring Telnet settings for remote access to S1 chassis management, refer to the Enterasys S- Series Configuration Guide.
  • Page 38 Completing the Installation Pin Out Descriptions 2-14 Installing the S1 Chassis...

  • Page 39: Chapter 3: Troubleshooting

    Figure 3-1 shows the S1 chassis system LEDs. Figure 3-1 S1 Chassis System LEDs FAN LED PWR LED Table 3-1 describes the LED indications for the system LEDs and provides recommended actions. Enterasys S-Series S1 Chassis Hardware Installation Guide 3-1...

  • Page 40: System Leds

    The S1 chassis is not receiving power from the power Ensure the power cords are plugged in supplies. and power is available at the source. Contact Enterasys Networks for technical support. Green Functional. Indicates one of the following conditions: None.

  • Page 41: Power Supply Leds

    No link to device. Verify that all network connections between the network management station and the S1 chassis are valid and operating. If the problem continues, contact Enterasys Networks for technical support. Enterasys S-Series S1 Chassis Hardware Installation Guide 3-3...
  • Page 42 Troubleshooting Checklist 3-4 Troubleshooting...

  • Page 43: Appendix A: Specifications

    Pluggable Transceiver Specifications COM Port Pinout Assignments Regulatory Compliance Enterasys Networks reserves the right to change specifications at any time without notice. S1 Chassis and Power Supply Specifications Table A-1 describes physical, electrical, and environmental specifications for the S1 chassis and the power supplies.

  • Page 44: Pluggable Transceiver Specifications

    5% to 95% (non-condensing) Pluggable Transceiver Specifications For SFP and SFP+ transceiver specifications, refer to the datasheet at the following URL: http://www.enterasys.com/products/transceivers-ds.pdf COM Port Pinout Assignments The COM port is an RJ45 communications port for local access to local management. Refer to the table below for the COM port pin assignments.

  • Page 45: Appendix B: Installing The S1-Mount-Kit

    Mounting the S1 Chassis in a Two-Post Rack Securing the Rear of the S1 Chassis to the Rails B-13 Required Tools • ESD wrist strap (included with the S1 chassis) • Phillips screwdriver Enterasys S-Series S1 Chassis Hardware Installation Guide B-1...

  • Page 46: Contents Of S1-Mount-Kit

    Contents of S1-MOUNT-KIT Contents of S1-MOUNT-KIT Table B-1 lists the contents of the S1-MOUNT-KIT. Table B-1 Contents of S1-MOUNT-KIT Item Number Left and right rails with rail extensions installed Mounting brackets 10-32 pan head screws (black) 10-32 cage nuts 6-32 flat head screws 6-32 pan head screw Note: The S1-MOUNT-KIT does not include rack screws.

  • Page 47: S1-Mount-Kit Mounting Options

    Position the left and right rails, which are labeled on the inside of each rail, in the rack with the bottom lip of the rail facing into the rack. Enterasys S-Series S1 Chassis Hardware Installation Guide B-3...

  • Page 48: Attaching The Rails To A Four-Post Rack

    Front Mounting the S1 Chassis in a Four-post Rack Using eight customer-supplied rack screws, attach each rail to the rack posts with four screws (two screws in the front and two screws in the back). Insert the screws in the top and bottom screw holes.

  • Page 49: Mounting The S1 Chassis In A Two-Post Rack

    “Mid-Mounting the S1 Chassis in a Two-Post Rack” on page B-10. Before installing the S1 chassis in a two-post rack, you must disassemble the rails. See “Disassembling the Rails” on page B-6. Enterasys S-Series S1 Chassis Hardware Installation Guide B-5...

  • Page 50: Disassembling The Rails

    Mounting the S1 Chassis in a Two-Post Rack Disassembling the Rails To disassemble the rails for installing your S1 chassis in a two-post rack: Remove the rail extensions from the rails by unscrewing the rail clamps. See Figure B-4. Figure B-4 Removing the Rail Extensions from the Rails Rails Right rear rail clamp...

  • Page 51: Front Mounting The S1 Chassis In A Two-Post Rack

    Note: Do not tighten the screws. Leave them loose to position the mounting brackets properly against the rack posts. Figure B-5 Attaching Mounting Brackets to the Rails (for a Rack with 3-Inch Posts) Mounting bracket in front mounting orientation (for a rack with 3-inch posts) Enterasys S-Series S1 Chassis Hardware Installation Guide B-7...

  • Page 52: Attaching Mounting Brackets To The Rails (For A Rack With 7-Inch Posts

    Mounting the S1 Chassis in a Two-Post Rack Figure B-6 Attaching Mounting Brackets to the Rails (for a Rack with 7-Inch Posts) Mounting bracket in front mounting orientation (for a rack with 7-inch posts) Position the left and right rails, which are labeled on the inside of each rail, in the rack with the bottom lip of the rail facing into the rack.

  • Page 53: Installing The Rails In A Two-Post Rack (7-Inch Posts

    “Securing the Rear of the S1 Chassis to the Rails” on page B-13. Figure B-8 Attaching the Rear Rail Clamp to the Right Rail 6-32 screw inserted in the forward screw position Enterasys S-Series S1 Chassis Hardware Installation Guide B-9...

  • Page 54: Mid-Mounting The S1 Chassis In A Two-Post Rack

    Mounting the S1 Chassis in a Two-Post Rack Slide the S1 chassis onto the rails until the front of the S1 chassis is against the front of the rack posts. Secure the front of the S1 chassis to the rack by screwing four customer-supplied rack screws in the mounting ears on the left and right front of the S1 chassis.

  • Page 55: Installing The Rails In The Mid-Mount Position (Right Rail Shown

    See Figure B-11. Figure B-11 Installing the 10-32 Cage Nuts in the Rail Mounting Ears Install the 10-32 cage nuts in the square holes 2 10-32 cage nut Enterasys S-Series S1 Chassis Hardware Installation Guide B-11...

  • Page 56: Attaching The Rear Rail Clamp To The Right Rail

    Mounting the S1 Chassis in a Two-Post Rack (Optional) Attach the rear rail clamp to the rail labeled RIGHT if you plan to secure the rear of the S1 chassis to the rails. Use one of the additional 6-32 flat head screws that are included with the S1 rail kit. Insert the screw in the forward screw position of the rail extension clamp.

  • Page 57: Securing The Rear Of The S1 Chassis To The Rails

    Set the 6-32 screw aside for use later in this procedure. Remove the S1 fan tray from the chassis. Note: Ensure that you use appropriate ESD protection when handling the fan tray. Enterasys S-Series S1 Chassis Hardware Installation Guide B-13...

  • Page 58: Securing The Left Rear Corner Of The S1 Chassis Through The Fan Tray Slot

    Securing the Rear of the S1 Chassis to the Rails Locate the screw hole in the empty fan tray slot. See Figure B-14. Figure B-14 Securing the Left Rear Corner of the S1 Chassis Through the Fan Tray Slot Insert a 6-32 flat head screw, included with the S1 rail kit, in the screw hole in the empty fan tray slot.

  • Page 59: Appendix C: About Poe (Power Over Ethernet)

    12.95 to 25.50 watts Proprietary PD Detection S-Series devices support a subset of the currently deployed proprietary PoE methods. This includes support for Cisco PDs, including a proprietary capacitor based detection scheme. Enterasys S-Series S1 Chassis Hardware Installation Guide C-1...

  • Page 60: Poe Port Status Leds

    If the PoE power needed or requested exceeds the power available, the system will generate an SNMP trap to notify the system manager. For more information on configuring allocation mode, see the Enterasys S-Series CLI Reference Guide. Power Distribution Upon Power Supply Removal or Addition...

  • Page 61: Management Of Poe Power To Pds

    For more information on configuring power management mode, see the Enterasys S-Series CLI Reference Guide.
  • Page 62 Management of PoE Power to PDs C-4 About PoE (Power over Ethernet)

  • Page 63: Appendix D: Environmental Guidelines

    This is not necessarily the same air temperature throughout the room. Cooling Air Many Enterasys switches utilize a side to side airflow method for cooling. Careful consideration is needed when mounting this equipment. Proper inlet and exit spaces must be allowed to get fresh, cool air into the equipment and to allow hot exhaust air to exit away from the equipment.

  • Page 64: Airflow Concerns For Closed Racks

    Temperature and Humidity Guidelines Airflow Concerns for Closed Racks When placing Enterasys switches into enclosed racks, rack exhaust fans must be considered if the rack does not contain adequate inlet and exit venting. These fans may be needed to help exhaust hot air from the rack.

  • Page 65: Airflow Concerns For Open Racks

    D-4 below shows a non-ideal configuration for an open rack, where sub- systems with mixed flow directions (white arrows) are combined in one rack. Circular red arrows show potential for hot air recirculation. Enterasys S-Series S1 Chassis Hardware Installation Guide D-3...

  • Page 66: Non-Ideal Open Rack Configuration

    Temperature and Humidity Guidelines Figure D-3 Non-ideal Open Rack Configuration Non-ideal flows should be avoided or mitigated and confirmed through thermal testing. Figure D-4 below shows a non-ideal open rack configuration containing sub-systems with mixed flow directions (white arrows). This configuration shows mitigation of potential hot air recirculation by leaving a gap in the rack population.

  • Page 67: Dust Mitigation And Prevention

    Dust accumulation on inlet and exit venting is not uncommon after prolonged use. In dustier environments this accumulation can be much quicker. Enterasys strongly recommends routine maintenance to check for clean inlet and exit vents on this equipment. Over time, dust accumulation can create vent blockages, thereby decreasing airflow and increasing component temperatures, resulting in reduced reliability.

  • Page 68: Airborne Chemicals And Prevention

    Airborne Chemicals and Prevention Table D-1 Airborne Dust Specification for Enterasys Equipment — Airborne Dust Maximum Values Dust Guidelines All/Total Airborne Particles (TSP-Dichot 15): 20 µg/m PM10/Coarse Particles (2.5 to 15 microns): Preferred : <10 µg/m Maximum : 20 µg/m PM2.5/Fine particles (< 2.5 microns): 10 µg/m...
