Indesit YT M11 83K RX EU Quick Manual

Quick guide
THANK YOU FOR BUYING AN INDESIT PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.indesit.eu/register
PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.
CONTROL PANEL
ON/OFF button (hold for Reset)
1
Programme selection knob
2
Start/Pause
3
Push & Go
4
Options buttons*
Dryness level
5
Start delay
6
Timed drying
7
Cycle end
8
Light drying (hold for Key Lock)
9
Crease care ( hold for Mute)
10
INDICATORS
Dryness level:
Iron dry -
Cycle phase: Cool tumble - END End of cycle
Dry -
Empty water tank -
Refer to Troubleshooting section:
FIRST TIME USE
Make sure that the water tank is correctly inserted. Make sure
that the drain hose on the back of the dryer is properly fixed,
either to the dryers's water tank or to the domestic sewage
system.
The dryer must be installed in a room with a temperature
ranging between 5°C and 35°C to ensure proper operation.
Before you use your dryer ensure that it has been in a upright
position for at least 6 hours.
DAILY USE
Doing this will keep your machine working at its BEST:
- remember to empty your water tank after each drying
cycle.
- remember to clean your filters after each drying cycle.
Refer to the Care & Maintenance section.
1. Plug the dryer into the power supply socket.
2. Open the door and load garments; always refer to instructions
on clothing labels and the max loads indicated in the
programme section. Empty pockets. Make sure garments do not
get caught between the door and/or the door filter. Do not load
items that are dripping wet. Do not tumble dry large, very bulky
items. For optimal drying result, garments should be loaded one
by one.
3. Close the door.
4. Press the "On/Off" button.
5. Select the most suitable programme for the type of fabric in
that load.
6. Select the options, if necessary.
7. Press the "Start/Pause" button to begin drying.
8. At the end of the drying cycle, a buzzer will beep. An indicator
on the control panel signals the end of the cycle. Turn the
machine off by pressing the "On/Off" button, open the door and
pull the clothing immediately out to prevent the formation of
creases on laundry.
If the machine is not switched off manually, after about a quarter
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
of an hour from the end of the cycle , the appliance turns off
• Using QR code in your appliance
automatically to save energy.
• Visiting our website docs.indesit.eu and parts-selfservice.whirlpool.com
Note that some programme/option accords with "Crease Care"
contact our After-sales Service
• Alternatively,
system. This means that for some hours, after the end of the
Service, please state the codes provided on your product's identifi cation plate.
drying cycle, the drum rotates at regular intervals to prevent the
formation of creases.
Note that some models perform a final cool tumble phase, for this
reason the fabrics may not feel hot.
In case of power failure, it is necessary to press the "Start/Pause"
button to restart the cycle.
2
Hanger dry - Cupboard dry -
start delay
Clean door filter - Clean bottom filter
Failure call After-sales Service
(See phone number in the warranty booklet). When contacting our After-sales
Before using the appliance carefully Before using the appliance carefully
read the Safety Instruction. read the Safety Instruction.
DEMO
5
*Note: some models may have the wording in full instead of the icons.
+
Extra dry
PUSH & GO
This function serves to start a cycle, after machine switching on,
without enabling any further button an/or knob (the programme
PUSH & GO will be deactivated instead).
It is always necessary to follow the points 1, 2, and 3 concerning
the daily use.
To start the cycle PUSH & GO, keep the button pressed. The light on
signals that the cycle is started.
synthetic textiles. Max. load 4 kg. (Cycle duration 100').
If the door is opened during the cycle, to restart it, close the door and
press the button START/PAUSE. This programme does not allow to
set other options.
Opening the door during the cycle
The tumble dryer door can be opened at any time during the cycle
to check progress and remove any garments already dry.
However, since opening the door can extend the drying time, the
recommendation is to keep the door closed throughout the cycle
process to save time and energy.
After closing the door, press the "Start/Pause" button within 15
minutes to resume the machine operation.
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the fi rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
10
3''
9
3''
8
6 7
The cycle is suitable for cotton and
EN
1
4
3
