Toto EGO II TX118LECBR Manual

SPECIFICATIONS
100 100
Ø54
Ø54
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
INSTALLATION
1.
Minimum Mortar Level
Maximum Mortar Level
Hot Water
Supply
Cold Water Supply
S06310BS
2.
O-Ring *
Cover *
79
* Remove the cover & O-ring after the mortar dry
3.
G½
+5 0
158 55
Handle Base**
0 -5
Handle*
* The red handle for left position and the blue handle for
right position.
**Tighten the handle base by hand
4.
Spout
"EGO II" CROSS HANDLE COMBINATION
WALL TYPE LAVATORY FAUCET
Mortar
Use Seal Tape
(Not Include)
Cover
TX118LECBR
TROUBLESHOOTING
CHECK
PROBLEM
POINT
Flow rate unsatisfactory 1
2
Water leaks around the handle
1. AERATOR
ATTENTION
1.Don t use abrasive cleaners or solvents on faucets and
fittings.
2. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toilet cleaner etc. which could adversely affect the finish and
are not recommended for cleaning
SOLUTION
Remove and clean
Tighten
2. CERAMIC
HEAD WORK
R7
