1. Service Navigation............................................................2
1.2. Solder the Lead Wire.............................................................3
RP-HD6ME
Model No.
RP-HD6MGC
Colour
(K)............Black Type
Page
1.3. Stick the Manufacturer label.................................................4
2. Specifications....................................................................5
© Panasonic Corporation 2016 Unauthorized copying and
distribution is a violation of law.
Order No.AD1606013CE
Stereo Headphones
Page
Advertisement
Related Manuals for Panasonic RP-HD6ME
Summary of Contents for Panasonic RP-HD6ME
-
Page 1: Table Of Contents
Table of Contents Page Page 1. Service Navigation............2 1.3. Stick the Manufacturer label..........4 2. Specifications..............5 1.1. General Description About Lead Free Solder (PbF)...2 1.2. Solder the Lead Wire.............3 © Panasonic Corporation 2016 Unauthorized copying and distribution is a violation of law. -
Page 2: Service Navigation
1 Service Navigation 1.1 General Description About Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin (Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30°C (86°F) more than that of the normal solder. -
Page 3: Solder The Lead Wire
1.2 Solder the Lead Wire 1. There is a blue or red mark on speaker. Confirm mark color (blue or red) and use the same color mark speaker for repair. [Caution] If you use a speaker with different color mark, the sound balance will not match. 2. -
Page 4: Stick The Manufacturer Label
1.3 Stick the Manufacturer label - 4 -... -
Page 5: Specifications
2 Specifications Type: Dynamic Closed-type Driver units: 40mm diameter Impedance: 44Ω Sensitivity: 99dB / mW Power handling capacity: 1,000 mW( * IEC) Frequency response: 4 - 40,000Hz Cord: 1.2m Plug: 3.5mm Mass: 240g(net) 228g(without cord) * IEC:International Electrotechnical Commission Specifications are subject to change without notice. - 5 -...
