DIR-825/ACF

PC with Wi-Fi Adapter

1. To connect via USB modem: connect your USB modem to the USB port
located on the back panel of the router.
If you need to connect or change a USB modem to another one when
!
the router is powered on, power off the router, connect the modem to
the USB port, and power on the router.
2. To connect the device to a fiber optic line: connect your SFP transceiver
to the SFP port, then connect the fiber optic cable to the SFP transceiver.
3. To connect the device to an Ethernet line: in the web-based interface of
the router, select the router's LAN port that will be used as the WAN port
and create an Ethernet WAN connection. Then connect an Ethernet cable
between an available Ethernet port of the router and the Ethernet line.
!
Please connect the router to the ISP's Ethernet line only after setting the
WAN port and creating the Internet connection.
4. Connect the power cord to the power connector port on the back panel of
the router, then plug the power adapter into an electrical outlet or power
strip.
5. Turn on the router by pressing the ON/OFF button on its back panel.
6. Turn on your PC and wait until your operating system is completely
loaded.
7. Turn on your Wi-Fi adapter. As a rule, modern notebooks with built-in
wireless NICs are equipped with a button or switch that turns on/off the
wireless adapter (refer to your PC documents). If your PC is equipped
with a pluggable wireless NIC, install the software provided with your
Wi-Fi adapter.
Now you should configure your Wi-Fi adapter.
4 It is recommended to use a USB extension cable to connect a USB modem to the
router.
