2001 East Terra Lane • P.O. Box 970 • O'Fallon, Missouri 63366
(636)240-2400 • Fax (636)272-2408 • (800)325-6152 • Intl Fax# (001)636-272-7546
Parts Dept. (800)424-TRUE • Parts Dept. Fax# (636)272-9471 • www.truemfg.com
Model:
TDBD-72-4
Rough-In Data
Capacity
(Cu. Ft.)
Model
Doors
(liters)
TDBD-72-4
4
35
992
†
Depth does not include
1
/
"
2
T
R
RUE
EFRIGERATION
TM
MADE IN
U.S.A.
U.S.A.
SINCE 1945
5/07
TRUE FOOD SERVICE
EQUIPMENT, INC.
Display Case:
Double-Duty Deli Case
Chart dimensions rounded up to the nearest
Full Length
Cabinet Dimensions
Shelves
PVC
Stainless
Coated
L
1
3
72
1
1832
full length
(13 mm)
for threaded drain fitting.
ApprovAls:
R
Printed in U.S.A.
Project Name:
Location:
Item #:
Model #:
(inches)
(mm)
†
D
H
HP
/
35
1
/
55
1
/
8
8
2
893
1397
Qty:
TDBD-72-4
Double duty deli cases offer the
added advantage of two refrigerated
compartments. One for display to
provide a high profile area for ready
to serve deli products under the
industry's best lighting and a second
lower compartment for convenient bulk
storage.
Cabinet is NSF-7 certified to hold open
food product.
Oversized, factory balanced,
refrigeration system holds 38°F to
40°F (3.3°C to 4.4°C). Gravity coil
refrigeration system provides high
humidity environment for exceptional
preservation of meats and deli
products.
"Low-E", double pane thermal glass
front and rear self-closing doors provide
maximum insulation value for greater
efficiency and energy savings.
Exterior - stainless steel front, sides and
back.
White laminated rear panel and rear
louvered grill.
Interior - attractive, NSF approved, white
aluminum liner. 300 series stainless steel
floor with coved corners.
Entire cabinet structure is foamed-
in-place using high density, CFC free,
polyurethane insulation.
Case is equipped with three (3) light
sources for maximum product display;
two (2) cabinet mounted and one (1)
shelf mounted. Fluorescent lamps are
low UV emitting to enhance product
appearance and increase shelf life.
Automatic defrost system; time-initiated,
time-terminated.
Specifications subject to change without notice.
1
/
"
(millimeters rounded up to next whole
8
NEMA
Voltage
Amps
Config.
115/60/1
14.0
5-20P
AvAilAble At:
AIA #
SIS #
number).
Cord
Crated
Length
Weight
(total ft.)
(lbs.)
(total m)
(kg)
9
625
2.74
284
