Home Theater BD Player
Second Generation
Service
TABLE OF CONTENTS
Location of PCB Boards & version variation & repair scenario matrix..................... 1-2
Production Speci cations ...............................................................................................1-3
Safety Instruction, Warning & Notes................................................................................1-
D
Instruction................................................................................................................2-1
FU
Mechanical and Dismantling Instructions ........................................................................3-1
Software Upgrades........................................................................................................... -1
Trouble Shooting Chart .................................................................................................... -1
Wiring Diagrams ................................................................................................6-1
Electrical Diagrams and Print-layouts .................................................................7-1
Set Mechanical Exploded view ....................................................................................... -1
Revision List ................................................................................................................. ..
This service manual is for HTS3562 Second Generation model,
which is different from the previous generation HTS3562/98
model.
For Second Generation model the serial number begin with
KX2AXXXXXXXXXX.Refer to the rating lable illustration at right.
©
Copyright 2010 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without
the prior permission of Philips.
Published by Helen-RY 1207 Service Audio Printed in The Netherlands Subject to modification
Version 1. Version 0.0
Version 1.1
HTS3562/98
Page
6
4
5
8
9
-1
CLASS 1
LASER PRODUCT
©
313978536081
GB
GB

Advertisement

loading

Summary of Contents for Philips HTS3562/98

  • Page 1 Set Mechanical Exploded view ..................-1 Revision List ........................This service manual is for HTS3562 Second Generation model, which is different from the previous generation HTS3562/98 model. For Second Generation model the serial number begin with KX2AXXXXXXXXXX.Refer to the rating lable illustration at right.
  • Page 2 PCB BOARD LOCATION: AMPLIFIER BOARD MAIN BOARD POWER BOARD LOADER Version Variation Type/Versions HTS3562M2 Features Power supply rating:110-240V ,50~60Hz Power consumption:110W Repair Scenario Matrix Type/Versions HTS3562M2 Board in used Main Board Front Control Board Amplifier Board Power Board *Bd:Board Level Replacement *C:Component Level Repair...
  • Page 3 Product Specifications: Video • Signal system: PAL / NTSC Note • HDMI output: 480i/576i, 480p/576p, 720p, 1080i, 1080p, 1080p24 • Specifi cations and design are subject to change without notice. Audio • S/PDIF Digital audio input: Region codes • Coaxial: IEC 60958-3 •...
  • Page 4 Speakers Center speaker: • Output power: 100 W RMS (30% THD) • Speaker impedance: 4 ohm • Speaker drivers: 1 x 63.5 mm (2.5") woofer • Dimensions (WxHxD): 160 x 85 x 95 mm • Weight: 0.37 kg Front/Rear speaker: •...
  • Page 5 Safety instruction, Warning & Notes Safety instruction 1. General safety 2.Laser safety Safety regulations require that during a repair: This unit employs a laser. Only qualified service personnel . Connect the unit to the mains via an isolation transformer. may remove the cover, or attempt to service this device .
  • Page 6 Warning 1.General 2. Laser . All ICs and many other semiconductors are susceptible to . The use of optical instruments with this product, will electrostatic discharges (ESD). Careless handing during increase eye hazard. . Only qualified service personnel may remove the cover repair can reduce life drastically.
