Bush Hog APP48 Operator's Manual

Bush Hog APP48 Operator's Manual

All purpose plow
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Published 09/20
This Operator's Manual is an integral part of the safe operation of this machine and must
be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety
and Operation Instructions contained in this manual before operating the equipment. C01-
Cover
®
BUSH HOG
2501 Griffin Ave.
Selma, AL 36703
334-874-2700
www.bushhog.com
OPERATOR'S MANUAL
© 2020 Alamo Group Inc.
APP48/60/
ALL PURPOSE PLOW
66/85
Part No. 50071483
$0.00

Advertisement

Table of Contents
loading

Related Manuals for Bush Hog APP48

Summary of Contents for Bush Hog APP48

  • Page 1 APP48/60/ 66/85 ALL PURPOSE PLOW Published 09/20 Part No. 50071483 OPERATOR’S MANUAL This Operator's Manual is an integral part of the safe operation of this machine and must be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment.
  • Page 2 BEFORE YOU START! Read the safety messages on the implement and shown in your manual. Observe the rules of safety and common sense! For future reference, record your Bush Hog product model number and serial number. Dealer Telephone Model Number...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SAFETY SECTION ......................1-1 General Safety Instructions and Practices ......................1-2 PARTS INFORMATION ............................. 1-8 Decal Location ..............................1-9 Decal Description ............................. 1-10 FEDERAL LAWS AND REGULATIONS ......................1-11 INTRODUCTION SECTION ....................2-1 ASSEMBLY SECTION ......................3-1 OPERATION SECTION .......................

  • Page 5: Safety Section

    SAFETY SECTION Safety Section 1-1...

  • Page 6: General Safety Instructions And Practices

    Safety Messages. Always use good common sense to avoid hazards. (SG-2) Si no lee ingles, pida ayuda a alguien que si lo lea para que le traduzca las medidas de seguridad. (SG-3) APP48/60/66/85 09/20 Safety Section 1-2 © 2020 Alamo Group Inc.
  • Page 7 Operate the Tractor controls from the tractor seat only. (SG-9) Never allow children or other persons to ride on the Tractor or Implement. Falling off can result in serious injury or death. (SG-10) APP48/60/66/85 09/20 Safety Section 1-3 © 2020 Alamo Group Inc.
  • Page 8 The operator and all support personnel should wear hard hats, safety shoes, safety glasses, and proper hearing protection at all times for protection from injury including injury from items that may be thrown by the equipment. (SG-16) APP48/60/66/85 09/20 Safety Section 1-4 © 2020 Alamo Group Inc.
  • Page 9 (SG-19) Never attempt to lubricate, adjust, or remove material from the Implement while it is in motion or while tractor engine is running. (SG-20) APP48/60/66/85 09/20 Safety Section 1-5 © 2020 Alamo Group Inc.
  • Page 10 Operate the Tractor and/or Implement controls only while properly seated in the Tractor seat with the seat belt securely fastened around you. Inadvertent movement of the Tractor or Implement may cause serious injury or death. (SG-29) APP48/60/66/85 09/20 Safety Section 1-6 © 2020 Alamo Group Inc.
  • Page 11 Never leave plow unattended in the lifted position. Accidental operation may cause sudden drop of unit with subsequent injury or death by crushing. Lower Plow carefully to the ground. Do not put hands or feet under lifted components. (SPL-2) APP48/60/66/85 09/20 Safety Section 1-7 © 2020 Alamo Group Inc.

  • Page 12: Parts Information

    These parts are made and tested to Bush Hog specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit” parts may reduce equipment performance, void warranties, and present a safety hazard. Use genuine Bush Hog parts for economy and safety.

  • Page 13: Decal Location

    SAFETY Decal Location NOTE: Bush Hog supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Bush Hog cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).

  • Page 14: Decal Description

    SAFETY Decal Description APP48/60/66/85 09/20 Safety Section 1-10 © 2020 Alamo Group Inc.

  • Page 15: Federal Laws And Regulations

    Some regulations specify that no one under the age of 16 may operate power machinery. It is your responsibility to know what these regulations are in your own area or situation. (Refer to U.S. Dept. of Labor, Employment Standard Administration, Wage & Home Division, Child Labor Bulletin #102.) APP48/60/66/85 09/20 Safety Section 1-11 © 2020 Alamo Group Inc.

  • Page 17: Introduction Section

    INTRODUCTION SECTION Introduction Section 2-1...
  • Page 18 Indicates an imminently hazardous situation that, if not avoided, MAY result in MINOR INJURY. Identifies special instructions or procedures that, if not strictly observed, could result in damage to, or destruction of the machine, attachments or the environment. APP48/60/66/85 09/20 Introduction Section 2-2 © 2020 Alamo Group Inc.
  • Page 19 Front and rear, and left and right are determined by the normal direction of travel (the same as on your automobile). Carefully read the Operator’s Manual completely, understand the Safety Messages and instructions, and know how to operate correctly both the tractor and plow. APP48/60/66/85 09/20 Introduction Section 2-3 © 2020 Alamo Group Inc.
  • Page 20 NOTE: Warranties are honored only if completed “Owner Registration and Warranty” forms are received by Bush Hog within thirty days of delivery of the implement. 3. Record the Model and Serial Numbers on Warranty Page at the front of the Operator’s Manual. Keep this as part of the permanent maintenance file for the Implement.
  • Page 21 2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 3. If parts not made or supplied by Bush Hog have been used in connection with the unit, if, in the sole judgement of Bush Hog such use affects its performance, stability or reliability.

  • Page 23: Assembly Section

    ASSEMBLY SECTION Assembly Section 3-1...
  • Page 24 ASSEMBLY DEALER SET-UP INSTRUCTIONS This Plow is shipped completely assembled from the factory. Always use personal protection devices such as eye and ear protectors during assembly. APP48/60/66/85 09/20 Assembly Section 3-2 © 2020 Alamo Group Inc.

  • Page 25: Operation Section

    OPERATION SECTION Operation Section 4-1...

  • Page 26: Standard Equipment And Specifications

    2-1/2” x 2-1/2” x 3/8” -- (width x height x thickness) Hole Spacing 1” Hitch Cat. 1 Standard and Quick Hitch Teeth 5/16” x 2” x 10-1/8” 1080 High Carbon 38-44 Rockwell C. Reversible Suggested Min. PTO HP APP48/60/66/85 09/20 Operation Section 4-2 © 2020 Alamo Group Inc.

  • Page 27: Operator Requirements

    Serious injury or death to the operator or others could result if the operator is under the influence of drugs or alcohol. (SG-27) APP48/60/66/85 09/20 Operation Section 4-3 © 2020 Alamo Group Inc.

  • Page 28: Tractor Requirements

    Operating these implements with a tractor that does not have adequate power may damage the tractor engine. Exceeding the recommended horsepower may cause plow damage by overpowering the unit in heavy operating conditions. APP48/60/66/85 09/20 Operation Section 4-4 © 2020 Alamo Group Inc.

  • Page 29: Tractor 3-Point Hitch

    3.3 Tractor 3-Point Hitch For the Plow, the tractor 3-point hitch must be rated to lift at least 206 lbs. for the APP48-3, 228 lbs. for the APP60-5, 284 lbs for the APP66-5, 367 lbs for the APP66-7, 386 lbs for the APP85-7 and 455 lbs for the APP85-9.

  • Page 30: Dismounting The Tractor

    Place the tractor shift lever into a low range or parking gear to prevent the tractor from rolling. Never dismount a Tractor that is moving or while the engine is running. Operate the Tractor controls from the tractor seat only. (SG-9) APP48/60/66/85 09/20 Operation Section 4-6 © 2020 Alamo Group Inc.

  • Page 31: Starting The Tractor

    Always shut the Tractor completely down, place the transmission in park, and set the parking brake before you or anyone else attempts to connect or disconnect the Implement and Tractor hitches. (S3PT-15) APP48/60/66/85 09/20 Operation Section 4-7 © 2020 Alamo Group Inc.

  • Page 32: Connecting The Plow

    IMPORTANT: Scan this QR Code with your smart phone to link to the PAMI Safe Implement Hitching Manual for more information on correctly connecting agricultural tractors to implements. Or type in your internet browser the following web address: www.algqr.com/hme Ops-0008-MISC APP48/60/66/85 09/20 Operation Section 4-8 © 2020 Alamo Group Inc.

  • Page 33: Pre-Operation Inspection And Service

    Engine coolant level and condition • Power brake fluid level • Power steering fluid level • Fuel condition and level • Sufficient lubrication at all lube points • Air filter condition OPS-U-0030 APP48/60/66/85 09/20 Operation Section 4-9 © 2020 Alamo Group Inc.

  • Page 34: Plow Pre-Operation Inspection/Service

    Ensure the manual canister is secured to the equipment with the operator’s manual inside. • Ensure all safety signs are in place and legible. Replace missing, damaged, and illegible decals. OPS-U- 0011 APP48/60/66/85 09/20 Operation Section 4-10 © 2020 Alamo Group Inc.
  • Page 35 The engine coolant fluid level is full The radiator is free of debris The air filter is in good condition Operator’s Signature:___________________________________________________ DO NOT OPERATE an UNSAFE TRACTOR or IMPLEMENT APP48/60/66/85 09/20 Operation Section 4-11 © 2020 Alamo Group Inc.
  • Page 36 The plow pins are properly lubricated and retained. Springs are attached. The shanks are properly retained. Remove debris from plow points. Operator’s Signature:_____________________________________________________ DO NOT OPERATE an UNSAFE TRACTOR or IMPLEMENT APP48/60/66/85 09/20 Operation Section 4-12 © 2020 Alamo Group Inc.

  • Page 37: Driving The Tractor And Implement

    When operating in traffic always use the Tractor’s flashing warning lights and reduce your speed. Be aware of traffic around you and watch out for the other guy. (SG-19) APP48/60/66/85 09/20 Operation Section 4-13 © 2020 Alamo Group Inc.

  • Page 38: Starting The Tractor

    When operating in traffic, always use the Tractor’s flashing warning lights and reduce your speed. Be aware of traffic around you and watch out for the other guy. APP48/60/66/85 09/20 Operation Section 4-14 © 2020 Alamo Group Inc.

  • Page 39: Operating The Tractor And Implement

    Park the tractor on a level surface, place the transmission in park or neutral and apply the parking brake, lower the attached implement to the ground, shut down the engine, remove the key, before exiting the tractor. APP48/60/66/85 09/20 Operation Section 4-15 © 2020 Alamo Group Inc.

  • Page 40: Disconnecting The Plow From The Tractor

    By using good judgement and following safe transport procedures, the possibility of accidents while moving between locations can be substantially minimized. OPS-U- 0017 APP48/60/66/85 09/20 Operation Section 4-16 © 2020 Alamo Group Inc.
  • Page 41 (SG-19) Never allow children or other persons to ride on the Tractor or Implement. Falling off can result in serious injury or death. (SG-10) APP48/60/66/85 09/20 Operation Section 4-17 © 2020 Alamo Group Inc.

  • Page 42: Transporting On Public Roadways

    Make certain that the “Slow Moving Vehicle” (SMV) sign is installed in such a way as to be clearly visible and legible. When transporting the Equipment use the Tractor flashing warning lights and follow all local traffic regulations. (SG-6) APP48/60/66/85 09/20 Operation Section 4-18 © 2020 Alamo Group Inc.
  • Page 43 Reduce speed before turning or applying the brakes. Ensure that both brake pedals are locked together when operating on public roads. OPS-U- 0023 APP48/60/66/85 09/20 Operation Section 4-19 © 2020 Alamo Group Inc.

  • Page 44: Hauling The Tractor And Implement

    If during transport a hard braking, sharp turning, or swerving action was performed, stop at the next safe location to inspect the security of the load. OPS-U- 0026 APP48/60/66/85 09/20 Operation Section 4-20 © 2020 Alamo Group Inc.

  • Page 45: Troubleshooting Guide

    Use Plow Point to loosen soil A-Frame bent Hitting hidden objects Use slow speed when in unknown soil conditions Unable to hold level ground Tractor Draft Control lifting Plow Set Tractor Draft Control APP48/60/66/85 09/20 Operation Section 4-21 © 2020 Alamo Group Inc.

  • Page 47: Maintenance Section

    MAINTENANCE SECTION Maintenance Section 5-1...

  • Page 48: Replacing Plow Points

    NOTE: These values apply to fasteners as received from supplier, dry or when lubricated with normal engine oil. They do not apply if special graphited or molydisulphide greases or other extreme pressure lubricants are used. This applies to both UNF fine and UNC coarse threads. APP48/60/66/85 09/20 Maintenance Section 5-2 © 2020 Alamo Group Inc.
  • Page 49 MAINTENANCE APP48/60/66/85 09/20 Maintenance Section 5-3 © 2020 Alamo Group Inc.
  • Page 51 TO THE OWNER/OPERATOR/DEALER To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this Manual. The Table of Contents clearly identifies each section where you can easily find the information you need. The OCCUPATIONAL SAFETY AND HEALTH ACT (1928.51 Subpart C) makes these minimum safety...
  • Page 52 APP48/60/66/85 Plow APP48/60/66/85 09/20 P/N 50071483 Printed U.S.A...
