Introduction Thank you for purchasing this television set. This handbook has been designed to help you install and operate your TV set. We strongly recommend that you read it thoroughly. Table of Contents Safety Information ............. . 2 Preparation / Getting started .
Safety Information 10 cm 10 cm Leave at least 10 cm around each side of the TV set to allow for proper ventilation. Place the set on a stable, level surface. Never cover the ventilation slots of the TV with a cloth or other material.
Preparation / Getting started Connections • Insert the aerial plug into the 75Ω : socket at the bottom of the set. • Insert the mains plug into a wall socket (220-240V / 50/60Hz). Using the Remote Control Pull out the plastic insulation sheet from the battery to enable the remote control to operate.
Television keys and connectors CAUTION : This a Class 1 apparatus. It must be connected to a MAINS socket out with a protective earthing connection. Plasma TV HDMI 1 HDMI 2 AC in ~ (AUDIO IN) HDMI 1 HDMI 2 MAINS ~ (AUDIO IN) Headphone...
Page 7
Fernsehtasten und Anschlüsse Television keys and connectors AC in ~ POWER . : to switch the TV on and off. Note: The power remains on even when the Power switch is turned off. VOLUME –/+: to adjust sound level. MENU : to access or close menus. The PROGRAM /CHANNEL –/+ keys can be used to select a menu item and the VOLUME –/+ keys to enter into the selected...
Remote Control keys Standby To set the TV to standby mode. To switch the TV set on again, press P – / + or key. AV / Teletext – In TV/AV mode, it displays the Source List to select TV or peripheral equipment connected to EXT 1, EXT 2/SVHS2, EXT 3/SVHS3, EXT 4, HDMI 1 or HDMI 2.
Remote Control keys (Other functions) The remote control also allows you to control the main functions of some Philips DVD models. key to select the required mode : DVD. Press the The remote control indicator lights up to display the selected mode. It switches off automatically after 20 seconds if left idle.
Program Sort & Press the key. The TV Menu is displayed on the screen. TV Menu Install Picture Sound Language Features Country Install Auto Store Manual Store Name é Use the ï key, select the Install menu and the Æ / key to enter the Install menu.
Manual Store This menu is used to store the programmes one at a time. & Press the key. é With the ï key, select Install and the Æ / key to enter the Install menu. “ Use the ï key to select Manual Store and the Æ...
Picture and Sound Settings & Press the key. é Use the Î ï keys to select Picture or Sound. “ Use the Í Æ / Picture or Sound menu. TV Menu Picture Sound Brightness Features Colour Install Contrast Sharpness Colour Temp. TV Menu Sound Picture...
Using the Contrast+ and NR (Noise Reduction) features & Press the key. é With the ï key, select Features and the Æ / key to enter the Features menu. “ Use the Î ï keys to select Contrast+ or NR (Noise Reduction) and the Í Æ keys to select an On or Off option.
Using the PIP (Picture-in-Picture) feature The PIP (Picture-in-Picture) feature allows you to call up a PIP screen of the PC (Personal Computer) or HD (High Defintion) device while watching a TV programme. IMPORTANT To call up a PIP screen of the PC equipment, the following step must be taken : HDMI 1 or HDMI 2 input MUST be connected to the DVI output of the PC equipment.
Screen Formats The pictures you receive may be transmitted in 16:9 format (wide screen) or 4:3 format (conventional screen). 4:3 pictures sometimes have a black band at the left and right of the screen. This function allows you to optimise the picture display on screen. Press the key (or Í...
Using the Smart Picture and Sound features Smart Picture feature offers you a choice of 5 picture settings namely : Rich, Natural, Soft, Multimedia and Personal. Press the button repeatedly to cycle through the settings to select your desired mode. Rich Smart Sound feature offers you a choice of 4 sound settings namely : Theatre, Music, Voice,...
Teletext Teletext is an information system broadcast by certain channels which can be consulted like a newspaper. It also offers access to subtitles for viewers with hearing problems or who are not familiar with the transmission language (cable networks, satellite channels, etc.). &...
Using the TV as a PC Monitor Your TV can be used as a computer monitor. IMPORTANT For the TV to function as PC monitor, the following steps must be taken : & HDMI 1 or HDMI 2 input MUST be connected to the DVI output of the PC.
Picture and Sound settings (see page 10). Your Philips TV is HDMI compliant. If you do not get a good picture, please change the video format on your device (DVD player, cable set-top box, etc.) to a standard format. For example, for DVD player, select 480p, 576p, 720p or 1080i.
Troubleshooting Tips Below is a list of symptoms you may encounter with your TV. Before you call for service, make these simple checks. Symptom No display on screen Poor reception (snowish picture and noise No picture No sound on certain channels No sound Sound interference Unable to understand •...
Troubleshooting Tips Symptom Possible Causes Cannot access Install • In AV, EXTERNAL or menu HD mode PC modes do not • Wrong connections work • Wrong source selected. • Wrong display resolution • Wrong setting of PC graphic card S-Video colour •...
Specifications Panel screen size Audio output TV System Video playback Sound System Connectivity Rear Side Power consumption Standby power consumption Set dimensions (with stand) Width Depth Height Nett Weight (with stand) Reference table of Countries available for selection Abbreviation Country Austria Belgium Switzerland...
