Wireless HDMI
Article number: VTRA3470AT
Nedis BV
De Tweeling 28, 5215 MC 's-Hertogenbosch, The Netherlands 07/22
Preface
Thank you for purchasing the Nedis VTRA3470AT.
This document is the user manual and contains all the information for correct, e cient and
safe use of the product.
This user manual is addressed to the end user. Read this information carefully before
installing or using the product.
Always store this information with the product for use in the future.
Product description
Intended use
The Nedis VTRA3470AT is a wireless HDMI extender that transfers HDMI signals from
source device(s) to display and/or audio device(s).
In SW mode the product is a switch: multiple senders (up to 4 - not included) can be
connected.
In SP mode the product is a splitter: multiple receivers (up to 4 - not included) can be
connected.
The included infrared transmitters and receivers transfer infrared signals between the
transmitter and receiver.
This allows you to use the remote control of your source device while in range of the
receiver.
This product is intended for indoor use only.
The product is not intended for professional use.
https://cdn.nedis.com/manuals/html/VTRA3470AT/?_gl=1*ht51nm*_ga*MTMxODgxNTg4MC4xNjkyNTk1OTI0*_ga_49LWESJ80M*MTY5MzI4Nzk... 1/9
User manual
TM
User manual
Extender
EN
