- Page 1 Installation Guide Intelligent Solar Power Supply System...
-
Page 2: Table Of Contents
Contents Chapter 1 Appearance ——————————— 3 Chapter 2 Installation ——————————— 6 Package Contents ..........6 Safety Precautions ..........6 Installation ...............7 Chapter 3 Configuration —————————— 12 Appendix FAQ ——————————————— 13... -
Page 3: Chapter 1 Appearance
Chapter 1 Appearance The TP-Link VIGI intelligent solar power supply system consists of three parts: horizontal mount, solar panel, and vertical mount. The TP-Link VIGI intelligent solar power supply system can provide stable and reliable voltage output for various electronic devices (such as security surveillance cameras, outdoor wireless APs, wireless bridges, 4G routers, etc.). - Page 4 • Controller LED Indication On: The system is working and the load is enabled Flashing: The system is working and the load is disabled. Off: The system is not working. On: The RJ45 interface is connected. Flashing: Data is being transferred. Off: The RJ45 interface is not connected.
- Page 5 • Specifications Items VIGI SP6020/VIGI SP6030 VIGI SP9030 Size 690mm×516mm×30mm 998mm×516mm×30mm Output Power/ 60W/18V 90W/18V Voltage Material Monocrystalline Silicon Vertical Mount ■ The mount is shown as the following figure. Vertical Mount PTZ Camera Connector Items VIGI SP6020/VIGI SP6030/VIGI SP9030 Size 191mm×40mm×82mm Operating Temperature...
-
Page 6: Chapter 2 Installation
Chapter 2 Installation Package Contents Make sure that the package contains the following items. Please contact your distributor, if any of the listed items are damaged or missing. The figures are for demonstration only. The actual items may differ in appearance and quantity from what is depicted. -
Page 7: Installation
• All modular battery load interfaces should take strict waterproof measures to avoid short circuit, leakage, and other problems. Installation Step 1. Determine the installation location Choose a location where the solar panel receives the most sunlight throughout the year. Position the solar panel south-facing in the Northern Hemisphere or north-facing in the Southern Hemisphere. - Page 8 Recommended solar panel inclination angles (the following inclination angles correspond to the holes on the mount): Latitude Range Recommended Inclination 0-5° 5° 5-15° 15° 15-25° 25° 25-35° 35° 35-45° 45° >45° 55° 2. Install the solar panel using the solar panel matching screws. Step 4.
- Page 9 2. Install devices on the vertical mount. Different types of mounts have varying access methods, and the corresponding type of bracket should be selected for installation according to the actual situation of the device. The installation hole diagram of the load at the end of the vertical mount is as follows:...
- Page 10 1 Install the PTZ camera connector 2 Install the PTZ camera Note: If the product is used in a windy area, it is recommended to tie VIGI 5-Series cameras directly to the pole to reduce the impact of strong wind on the image quality of the camera.
- Page 11 3. Af ter connecting the camera to the load inter face, wrap the connection with over two layers of waterproof tape (not included), as shown below. Note: When using waterproof tape, wrap the first layer, then cut. Apply a second layer, ensuring no gaps between the connection and tape for secure waterproofing.
-
Page 12: Chapter 3 Configuration
Step 2. Follow the instructions to finish Quick Setup. 1. Download and install the latest TP-Link VIGI app. 2. Open the app and log in with your TP-Link ID. If you don’t have an account, sign up first. 3. Tap the + button on the top right and follow the app instructions to add the solar panel. - Page 13 Appendix FAQ Q1. The controller LED status is abnormal. • SYS LED is off: It may be out of power or the system board is damaged. • LAN LED is off: There is no connection. Check whether the RJ45 interface is firmly connected to the network device.
- Page 14 EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/...
- Page 16 To ask questions, find answers, and communicate with TP-Link users or engineers, please visit https://community.tp-link.com to join the TP-Link Community. For technical support, user guides and other information, please visit https://www.tp-link.com/support, or simply scan the QR code. © 2023 TP-Link 7106510490 REV1.0.1...
