Milwaukee RBA-2 Manual

IMPORTANT SAFETY
INSTRUCTIONS
To reduce the risk of serious injury,
WARNING
read all safety warnings, instructions,
illustrations and specifications provided by the
router and guide rail manufacturer before beginning
work.
SYMBOLOGY
Read operator's manual
Do not dispose of electric tools together
with household waste material. Electric
tools and electronic equipment that have
reached the end of their life must be
collected separately and returned to an
environmentally
facility.
SPECIFICATIONS
Cat. No. .............................................................. RBA-2
Maximum offset......................................... 50.8 mm (2")
Compatibility ....................... MILWAUKEE
FUNCTIONAL DESCRIPTION
1. Offset scale rod
2. Connection rods
3. T h u m b c s e r w s o t a r
4. Handle
5. Anti-tip knob
6. Rail adjustment knob
7. Rod thumb screw
ASSEMBLY
Always remove battery from tool
WARNING
before
accessories. Only use accessories specifically
recommended for this tool. Others may be
hazardous.
compatible
Guide Rails
®
Bar (for M18 FR12,
8.
RBA-1)
9. 5 mm hex wrench
g e
10. Gauge block
11. M18 FTR conversion
parts
12. Guide rail channel
changing or
1/2" ROUTER TRACK ADAPTER
Cat. no.: RBA-2
Assemble the track adapter, as shown.
recycling
1. Remove battery pack.
2. Remove the U-ring from the base, if present.
3. Slide the connection rods equally into the accessory
holes of the base until the bar is flush against the
router base.
4.
Move the two thumb screws from storage into the
threads of the router base to secure the rods to the
router base.
1. Remove battery pack.
Place the track adapter onto the guide rail, aligning
2.
the channel on the track adapter with the guide rail
channel.
3. Loosen the rail adjustment knobs.
removing
Check for play between the track adapter and guide
4.
rail.
5. Adjust both rail adjustment knobs to remove play
between track adapter and guide rail
while still allowing the track adapter
to slide smoothly along the guide rail.
For best results, the guideclearance
of the router must be very small.
6. Engage
pressing the button in and rotating
the anti-tip knobs.
1
Assembling
Attaching to Router Base
(M18 FR12, RBA-1)
Attaching to a Guide Rail
the anti-tip feature by
