- Page 1 DRILL STAND MODEL NO: CDS1 PART NO: 6500220 USER INSTRUCTIONS ORIGINAL INSTRUCTIONS DL1223 - Rev1...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE product. Before attempting to use this product, please read these instructions carefully. In doing so you will ensure your safety and you can look forward to your purchase giving you long and satisfactory service.
- Page 3 SAFETY PRECAUTIONS CAUTION: NEVER USE WITH A DRILL IN ‘HAMMER’ MODE. ALWAYS take care that your hands or clothing DO NOT come into contact with the chuck of the drill. Beware of wearing loose clothing & ensure cuffs are secured. ALWAYS learn the applications, limitations and potential hazards relating to the tool you are using.
- Page 4 6. To adjust the collar ‘G’ to the required height on the steel column, slacken the knob ‘C’ and move collar and then re-tighten knob ‘C’ to secure. 7. The drill stand is ready to use. Insert your drill in the collar and tighten knob ‘F’.
