SERVICE MANUAL
P1030 / P1040 / P1050 / P1060
Air Cart
Part number 84329246
3
edition English
rd
March 2014
Replaces part number 87478740

Advertisement

Table of Contents
loading

Summary of Contents for New Holland P1030

  • Page 1 SERVICE MANUAL P1030 / P1040 / P1050 / P1060 Air Cart Part number 84329246 edition English March 2014 Replaces part number 87478740...
  • Page 2 Contents INTRODUCTION Rear axle system................ 27 [27.550] Non-powered rear axle ............. 27.1 Hydraulic systems...............
  • Page 3 [61.904] Product metering ..............61.3 Seeding..................
  • Page 4 84329246 19/02/2014 Find manuals at https://best-manuals.com...
  • Page 5 INTRODUCTION 84329246 19/02/2014 Find manuals at https://best-manuals.com...
  • Page 6: Table Of Contents

    Contents INTRODUCTION Foreword (*) ..................3 Safety rules and signal word definitions (*) .
  • Page 7: Foreword

    INTRODUCTION Foreword P Series Air Carts Technical information This information in this manual has been structured using a unique coding environment. This is the way in which technical information is created, stored, and retrieved in the Technical Information Database. The coding has aligned locations with the warranty system.
  • Page 8: Safety Rules And Signal Word Definitions

    INTRODUCTION Safety rules and signal word definitions P Series Air Carts Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual and on machine decals, you will find the signal words Danger, Warning, and Caution followed by special instructions.
  • Page 9: Safety Rules

    INTRODUCTION Safety rules Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual you will find the signal words DANGER, WARNING, and CAUTION followed by special in- structions.
  • Page 10: Safety Rules

    INTRODUCTION Safety rules Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual and on machine decals, you will find the signal words DANGER, WARNING, and CAUTION followed by special instructions.
  • Page 11: Safety Rules

    INTRODUCTION Safety rules P Series Air Carts WARNING Chemical hazard! Wear protective clothing and a face shield when working with chemicals. Do not allow chemicals to contact skin or eyes. Always follow the chemical manufacturer's instructions. Failure to comply could result in death or serious injury. W0052A WARNING Unexpected machine movement!
  • Page 12 INTRODUCTION DO NOT attempt to remove material from any part of the machine while it is being operated or components are in motion. Make sure all guards, shields and handrails are in good condition and properly installed before operating machine. Never operate the machine with shields removed.
  • Page 13 INTRODUCTION When welding follow the instructions in the manual. Always disconnect battery before welding on machine. Always wash your hands after handling battery components. Wheels and tires Make sure tires are correctly inflated. Do not exceed recommended load or pressure. Follow instruction in the manual for proper tire inflation.
  • Page 14 INTRODUCTION Make sure the fire extinguisher(s) is maintained and serviced according to the manufacturer’s instructions. At least once each day and at the end of the day remove all trash and debris from the machine especially around hot components such as engine, transmission, exhaust, battery, etc. More frequent cleaning of your machine may be necessary depending on the operating environment and conditions.
  • Page 15 INTRODUCTION Hazardous chemicals If you are exposed to or come in contact with hazardous chemicals you can be seriously injured. The fluids, lubricants, paints, adhesives, coolant, etc. required for the function of your machine can be hazardous. They may be attractive and harmful to domestic animals as well as humans.
  • Page 16 INTRODUCTION Maintain a three‐point contact with steps, ladders and handholds. Never mount or dismount from a moving machine. Working at heights When the normal use and maintenance of the machine requires working at heights: Correctly use installed steps, ladders and railings. Never use ladders, steps or railings while the machine is moving. Do not stand on surfaces which are not designed as steps or platforms.
  • Page 17: Safety Signs

    When a safety sign displays this symbol, refer to the appropriate page of the operator’s manual. NOTE: New decals are available from your NEW HOLLAND dealer. 84329246 19/02/2014...
  • Page 18 INTRODUCTION Tow behind air cart - two tank SAIL14SE00065HA Safety decal locations - Tow behind air cart - right side 84329246 19/02/2014...
  • Page 19 INTRODUCTION SAIL14SE00066HA Safety decal locations - Tow behind air cart - left side 84329246 19/02/2014...
  • Page 20 INTRODUCTION Tow behind air cart - three tank SAIL14SE00067HA Safety decal locations - Tow behind air cart - right side 84329246 19/02/2014...
  • Page 21 INTRODUCTION SAIL14SE00068HA Safety decal locations - tow behind air cart - left side 84329246 19/02/2014...
  • Page 22 INTRODUCTION Tow between air cart - two tank SAIL14SE00069HA Safety decal locations - tow between air cart - right side 84329246 19/02/2014...
  • Page 23 INTRODUCTION SAIL14SE00070HA Safety decal locations - tow between air cart - left side 84329246 19/02/2014...
  • Page 24 INTRODUCTION Tow between air cart - three tank SAIL14SE00071HA Safety decal locations - tow between air cart - right side 84329246 19/02/2014...
  • Page 25 INTRODUCTION SAIL14SE00072HA Safety decal locations - Tow between air cart - left side 84329246 19/02/2014...
  • Page 26 INTRODUCTION (1) located on fan shield DANGER 1. Stop engine and remove key before removing fan shield. 2. Do not operate fan with shield removed. Failure to comply will result in death or serious injury. Quantity: 1 English: GD-500.73 Russian: GD-500.73RU French Canadian: 425205A1 GD50073 On fan shield (1) (variable drive shown).
  • Page 27 INTRODUCTION (3) located on decal plate at the top of the ladder and on each tank lid. WARNING Stop fan before opening lid. Avoid exposure to airborne chemicals. Dust and fumes will be exhausted if tank lid is opened while tank is pressurized. Chemicals may cause eye, skin, or breathing problems.
  • Page 28 INTRODUCTION (4) located on each tank lid. CAUTION Lid raises automatically when unlatched. Failure to comply could result in minor or moderate injury. Quantity: 2 (two tank carts) / 3 (three tank carts) English: GL-700.20 Russian: GL-700.20RU French Canadian: 425235A1 GL70020 On each tank lid (4).
  • Page 29 INTRODUCTION (5) located on each tank lid and on the decal plate at the top of the ladder. WARNING 1. Do not ride on machine. 2. Do not stand on tank. Failure to comply could result in death or serious injury.
  • Page 30 INTRODUCTION (6) located on the auger flighting. DANGER 1. Stay away from intake end. Keep others away. 2. Keep all shields in place. 3. Keep hands, feet, hair and clothing away from flighting. Failure to comply will result in death or serious injury.
  • Page 31 INTRODUCTION (7) located on left and right sides of the center manifold. CAUTION Keep hands clear while raising/lowering center manifold. Failure to comply could result in minor or moderate injury. Quantity: 2 English: GL-700.21 Russian: GL-700.21RU GL70021 French Canadian: 425236A1 Right side of center manifold (7).
  • Page 32 INTRODUCTION (8) located near mechanical drive on air cart frame. WARNING Rotating parts hazard 1. Keep all shields in place when operating. 2. Stop tractor engine, place all controls in neutral, set park brake, remove ignition key and wait for all moving parts to stop before servicing, adjusting, maintaining or unplugging.
  • Page 33 INTRODUCTION (9) located on the left side of the air cart frame towards the front. CAUTION 1. Before operating machine, read operator's manual for complete instructions and safety information. 2. Make certain everyone is clear of machine and equipment before starting operation. 3.
  • Page 34 INTRODUCTION (10) located on left and right sides of air cart frame. CAUTION Escaping fluid hazard Escaping hydraulic fluid under pressure can penetrate the skin causing serious injury. Relieve pressure before disconnecting hydraulic lines. Check / Tighten all connections BEFORE applying pressure.
  • Page 35 INTRODUCTION (11) located on left and right sides of air cart frame. WARNING ELECTROCUTION HAZARD BE ALERT FOR OVERHEAD ELECTRICAL LINES 1. Proceed cautiously under electrical lines and around utility poles. 2. Electrocution can occur without direct contact with overhead electrical lines. FAILURE TO FOLLOW THESE INSTRUCTIONS WILL RESULT IN SERIOUS INJURY OR DEATH BY GL70019...
  • Page 36 INTRODUCTION WARNING ELECTROCUTION HAZARD BE ALERT FOR OVERHEAD ELECTRICAL LINES 1. Proceed cautiously under electrical lines and around utility poles. 2. Electrocution can occur without direct contact with overhead electrical lines. FAILURE TO FOLLOW THESE INSTRUCTIONS WILL RESULT IN SERIOUS INJURY OR DEATH BY GL70019 ELECTROCUTION.
  • Page 37 INTRODUCTION (25) located near the auger motor (deluxe auger only) DANGER CRUSH HAZARD Quantity: 1 English: 419481A1 419481A1 Near auger motor (25). SAIL12SE00684AA 84329246 19/02/2014...
  • Page 38: Hand Signals (*)

    INTRODUCTION Hand signals P Series Air Carts It is often necessary to communicate using hand signals in agricultural operations when noise or distance inhibit communication by voice. The ASAE S351 standard illustrates these hand signals, which provide an easy means of communication, particularly in the interest of safety.
  • Page 39 INTRODUCTION LOWER EQUIPMENT - STOP THE ENGINE - Draw RAISE EQUIPMENT - Make circular motion with right hand, palm down, Make circular motion with either hand pointing to the across the neck in a "throat either hand at head level. ground.
  • Page 40: Safety Rules - Ecology And The Environment

    • Do not open the air-conditioning system yourself. It contains gases that should not be released into the atmosphere. Your NEW HOLLAND dealer or air conditioning specialist has a special extractor for this purpose and will have to recharge the system properly.
  • Page 41: Torque (*)

    INTRODUCTION Torque P Series Air Carts P1030 P1040 P1050 P1060 BOLT TORQUE INFORMATION 1. Fasteners should be replaced with the same or higher grade fasteners. If higher grade fasteners are used, these should only be tightened to the strength of the original.
  • Page 42 INTRODUCTION GRADE 2* GRADE 5, 5.1 or 5.2 GRADE 8 or 8.2 GRADE L9 (Alloy) SIZE Dry ** Lubricated ** Dry** Lubricated ** Dry** Lubricated ** Head 9/16 UNC 108 Nm 81 Nm 163 Nm 122 Nm 231 Nm 176 Nm 183 Nm 203 Nm 80 lb ft...
  • Page 43: Torque - Hydraulic Tubes And Fittings

    INTRODUCTION Torque – Hydraulic Tubes and Fittings NOTICE: The torque values given are for DRY TORQUES Standard Torque Data for Hydraulic Tubes and Fittings Hoses / Tubes to Steel Fittings 37° Flared Fittings Size Tubing OD Thread Size LB FT Inches 5/16-24 3/16...
  • Page 44: Basic Instructions - Measuring Voltages (*)

    INTRODUCTION Basic instructions – Measuring voltages P Series Air Carts Tools for electronics system troubleshooting For diagnosing problems with the electronics system you may use one or all of these tools. 1. The monitor diagnostic screens show sensor and system voltages. 2.
  • Page 45 INTRODUCTION reading. If the meter reading minus the probe resistance is less than 0.1 ohms, the two points have electrical continuity. RESISTANCE To measure the resistance between two points. 1. Set your meter to measure resistance (usually labeled with the ohm symbol). 2.
  • Page 46: Basic Instructions - Electrical Testing - Connector Inspection

    INTRODUCTION Basic instructions - Electrical testing - Connector inspection During troubleshooting, always inspect the condition of the pins and cavities on the mating male and female connectors: • Check for moisture in the connectors. • Check for corrosion on the pins and in the cavities. •...
  • Page 47 INTRODUCTION Corroded pins or cavities Inspect the pins and cavities for corrosion which can cause a weak electrical connection between the mating connectors. If corrosion is present, replace the affected pins and cavities. RCIL06PTR105BAA Bent pin Inspect the pins on the male connector. If a pin is bent and will not properly mate with its cavity in the female connector, replace the pin.
  • Page 48 INTRODUCTION Touching pins Inspect the pins on the male connector. If a pin is bent to the point where it is shorted to another pin within the connector, replace the pin. RCIL06PTR104BAA Recessed pin Inspect the male connector for recessed pins, where the pin is pushed back into the connector body, providing min- imal contact when the two connectors are joined.
  • Page 49 INTRODUCTION Broken pin Inspect the male connector for broken pins, where the pin remains with its female cavity, providing minimal contact when the two connectors are joined. RCIL06PTR108BAA 84329246 19/02/2014...
  • Page 50: Basic Instructions - Electrical Testing - Measuring Voltage

    INTRODUCTION Basic instructions - Electrical testing - Measuring voltage RCIL06PTR019CAA 1. Select the DC voltage function on the multimeter. 2. Turn system power ON. 3. Touch the positive (+) lead of the multimeter to the pin or cavity that is being tested. Touch the negative (-) lead to a reliable source of tractor battery ground.
