Toshiba Tecra S3-S411TD Specifications

Tecra S3 Series Detailed Product Specification
Model Name Description
S3-S411TD Microsoft® Windows® XP Professional, Intel Pentium® M processor 740, 256MB DDR2,
40GB 5400rpm SATA, CDRW/DVD-ROM, 15.0"XGA, nVIDIA GeForce™ Go 6600 with
64MB, Intel PRO/Wireless 2200BG, 6-cell Li-Ion battery, 1-Year limited warranty
2
Operating System
• Microsoft® Windows® XP Professional
3
Processor and Chipset
Intel® Centrino™ Mobile Technology featuring:
• Choice of processors:
o Intel Pentium® M Processor 740
1.73GHz, 2MB L2, 533MHz FSB
o Intel Pentium® M Processor 750
1.86GHz, 2MB L2, 533MHz FSB
o Intel Pentium® M Processor 760
2.00GHz, 2MB L2, 533MHz FSB
o Intel Pentium® M Processor 770
2.13GHz, 2MB L2, 533MHz FSB
o Intel Pentium® M Processor 780
2.26GHz, 2MB L2, 533MHz FSB
• Chipset
o Mobile Intel 915GM Express Chipset
• Integrated Wi-Fi™ compliant wireless LAN
o Intel PRO/Wireless 2200BG (802.11b/g),
o Intel PRO/Wireless 2915ABG (802.11a/b/g)
4
Memory
• Configured with 256MB DDR2 SDRAM (using one memory module,
one memory expansion slot open)
• 256MB(min)/2048MB (max), 2 memory slots using 256MB, 512MB,
or 1024MB PC4200 DDR2 533MHz SDRAM, dual-channel
support requires two memory modules of same capacity and
clockspeed
5
Hard Disk Drive
• Choice of: 40GB (5400 RPM), 60GB (5400 RPM), 80GB
(5400RPM), or 100GB (5400RPM); Serial-ATA (SATA) hard disk
drive; 9.5mm height; user removable
Ultra SlimBay Optical Disk Drive
• CD-RW/DVD-ROM drive maximum speed and compatibility:
o CD-ROM (24x:read), CD-R (24x:write), CD-RW
(24x:write), DVD-ROM (8x:read)
• DVD SuperMulti (+R double layer) drive supporting 10 formats
maximum speed and compatibility:
o CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read), DVD-R (4x:write),
DVD-RW (2x:write), DVD+R (Single Layer, 4x: write),
DVD+R (Double Layer, 2.4x:write), DVD+RW
(2.4x:write), DVD-RAM (2x:write)
6
Display
• 15.0" diagonal TFT active-matrix LCD display at 1024x768 native
resolution (XGA)
• 15.0" diagonal TFT active-matrix LCD display at 1400x1050 native
resolution (SXGA+)
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra S3 BTO Rev. 1.02 2006-03-30 KK T20050726 CB1.40
1
7
Graphics
• PCI-Express™ x16 graphics system
• NVIDIA GeForce™ Go 6600 with 64MB or 128MB DDR discrete
graphics memory
Sound
• Sigmatel STAC9200 16-bit stereo software sound
o Direct 3D Sound, DirectSound, Direct Music, MIDI
• Built-in microphone
• Sound Volume Control Dial
• Built-in stereo speakers
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• Toshiba Accupoint™ and TouchPad™ dual pointing device
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
• Control Buttons:
o Toshiba Assist button to launch Toshiba Assist control
• Presentation button to quickly connect to projectors
Communications
• Toshiba V.92 software modem
• Marvell Yukon Network Connection - 10/100/1000 Base-TX
Ethernet
• Choice of Wireless-LAN:
o Integrated Intel Pro/Wireless Network Connection
o Integrated Intel Pro/Wireless Network Connection
• Bluetooth® version 2.0 plus Enhanced Data Range (EDR) with
Toshiba Bluetooth driver software
Expandability
• 2 main memory slots. Both slots may be occupied.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
• ExpressCard slot supporting ExpressCard/34 and ExpressCard/54
• Secure Digital slot (supports SDIO)
Ports
• RGB (monitor) port
• TV-out (S-Video)
• i.LINK(tm) IEEE-1394
• 3 Universal Serial Bus (USB) ports (v2.0)
• External Microphone jack
• Headphone jack
• RJ-45 LAN port
• RJ-11 modem port
• Parallel port
• Serial port
Part Number
PTS30U-00S00E
(playback)
panel
8
9
2200BG (802.11b/g)
2915ABG (802.11a/b/g)
UPC
032017412644
