Washing Machine
User manual
WW8*R42****

Advertisement

Table of Contents
loading

Related Manuals for Samsung WW8 R42 Series

Summary of Contents for Samsung WW8 R42 Series

  • Page 1 Washing Machine User manual WW8*R42****...

  • Page 2: Table Of Contents

    Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions Critical installation warnings Installation cautions Critical usage warnings Usage cautions Critical cleaning warnings Instructions about the WEEE Installation What’s included Installation requirements Step-by-step installation Before you start Initial settings...
  • Page 3 Troubleshooting Checkpoints Information codes Specifications Fabric care chart Protecting the environment Specification sheet Information of main washing programmes English 3...

  • Page 4: Safety Information

    Safety information Congratulations on your new Samsung washing machine. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your washing machine’s many benefits and features.

  • Page 5: Important Safety Precautions

    These warning signs are here to prevent injury to yourself and others. Please follow them explicitly. After reading this manual, store it in a safe place for future reference. Read all instructions before using the appliance. As with any equipment that uses electricity and moving parts, potential hazards exist. To safely operate this appliance, familiarize yourself with its operation and exercise care when using it.

  • Page 6: Critical Installation Warnings

    Safety information 4. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. 5. The new hose-sets supplied with the appliance are to be used and old hose-sets should not be reused.
  • Page 7 The appliance is heavy, therefore take care when lifting it. Plug the power cord into a wall socket that meets local electrical specifications. Use the socket for this appliance only, and do not use an extension cord. • Sharing a wall socket with other appliances using a power strip or extending the power cord may result in electric shock or fire.

  • Page 8: Installation Cautions

    Safety information • This may result in electric shock or fire. Do not pull or excessively bend the power cord. Do not twist or tie the power cord. Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance.
  • Page 9 • Do not use a ventilating fan. • A spark may result in an explosion or fire. Do not let children play in or on the washing machine. In addition, when disposing of the appliance, remove the washing machine door lever. •...

  • Page 10: Usage Cautions

    • Failure to do so may result in electric shock or fire. If any foreign substance enters into the appliance, unplug the power plug and contact your nearest Samsung Customer Service. • This may result in electric shock or fire.
  • Page 11 Using the product for business purposes qualifies as a product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
  • Page 12 Safety information • Do not wash thick or hard mats even if the washing machine mark is on the care label. This may result in injury or damage to the washing machine, walls, floor, or clothing due to abnormal vibrations. •...

  • Page 13: Critical Cleaning Warnings

    • This may result in spontaneous combustion or ignition due to the heat from the oxidation of the oil. Do not use water from water cooling/heating devices. • This may result in problems with the washing machine. Do not use natural hand-washing soap for the washing machine. •...

  • Page 14: Instructions About The Weee

    This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product regulatory obligations, e.g. REACH, WEEE or Batteries, visit our sustainability page available via www.samsung.com...

  • Page 15: Installation

    What’s included Make sure all the parts are included in the product package. If you have a problem with the washing machine or the parts, contact a local Samsung customer centre or the retailer. 01 Release lever 02 Detergent drawer...
  • Page 16 Installation Spanner Bolt caps Hose guide Cold water hose Hot water hose Cap fixer NOTE • Bolt caps: The provided number (3 to 6) of bolt caps depends on the model. • Hot water hose: Applicable models only. • Liquid detergent guide: Applicable models only. •...

  • Page 17: Installation Requirements

    Drain • Improperly connected grounding Samsung recommends a standpipe in conductors may cause electric shock. height of 60-90 cm. The drain hose must be connected through the hose clip to the standpipe, and the standpipe must fully cover the drain hose.
  • Page 18 Installation Flooring Alcove installation For best performance, the washing Minimum clearance for stable operation: machine must be installed on a solid floor. Sides 25 mm Wood floors may need to be reinforced 25 mm to minimize vibration and/or unbalanced Rear 50 mm loads.

  • Page 19: Step-By-Step Installation

    Step-by-step installation STEP 1 Select a location Location requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for ventilation and wiring • The ambient temperature is always higher than the freezing point (0 °C) •...
  • Page 20 Installation STEP 3 Adjust the levelling feet 1. Gently slide the washing machine into position. Excessive force may damage the levelling feet. 2. Level the washing machine by manually adjusting the levelling feet. 3. When levelling is complete, tighten the nuts using the spanner.
  • Page 21 If there is a water leak, stop operating the washing machine and disconnect from the electrical supply. Then, contact a local Samsung service centre in case of a leak from the water hose, or contact a plumbing technician in case of a leak from the water tap.
  • Page 22 Installation 3. Hold the adaptor and turn part (C) in the arrow direction to loosen it by 5 mm (*). 4. Insert the adaptor onto the water tap, and then tighten the screws while lifting the adaptor. 5. Turn part (C) in the arrow direction to tighten it.
  • Page 23 For models with an additional hot water inlet: 1. Connect the red end of the hot water hose to the hot water inlet on the back of the machine. 2. Connect the other end of the hot water hose to the hot water tap. Aqua stop hose (applicable models only) The aqua stop hose alerts users of a risk of water leaks.
  • Page 24 Installation STEP 5 Position the drain hose The drain hose can be positioned in three ways: Over the edge of a wash basin The drain hose must be placed at a height of between 60 cm and 90 cm (*) from the floor.
  • Page 25 In a sink drain pipe branch The drain pipe branch mush be above the sink siphone so that the end of the hose is at least 24 in. (60 cm) above the ground. (*) : 24 in. (60 cm) STEP 6 Power on Plug the power cord into a wall socket featuring an AC 220-240 V / 50 Hz approved electrical outlet protected by a fuse or circuit breaker.

  • Page 26: Before You Start

    Before you start Initial settings Run Calibration (recommended) Calibration ensures accurate weight detection by the washing machine. Make sure the drum is empty before running Calibration. 1. Power off, and then power on the washing machine. 2. Hold down Temp. and Delay End simultaneously for 3 seconds to enter Calibration mode.
  • Page 27 STEP 2 Empty pockets Empty all the pockets of your laundry items • Metal objects such as coins, pins, and buckles on clothing may damage other laundry items as well as the drum. Turn clothing with buttons and embroideries inside out •...
  • Page 28 Before you start STEP 6 Apply a proper detergent type The type of detergent depends on the type of fabric (cotton, synthetic, delicate items, wool), colour, wash temperature, and degree of soiling. Make sure to use the laundry detergent that is designed for automatic washing machines. NOTE •...

  • Page 29: Detergent Drawer Guidelines

    CAUTION For cycles using cold water or cycles that complete in less than one hour, it is recommended to use a liquid detergent. Otherwise, the capsule may not dissolve completely. Detergent drawer guidelines The washing machine provides a three-compartment dispenser: the left compartment for the main wash, the front-right for fabric softeners, and the rear-right for the preliminary wash.
  • Page 30 Before you start To apply washing agents to the detergent drawer 1. Slide open the detergent drawer. 2. Apply laundry detergent to the main-wash compartment as instructed or recommended by the manufacturer. 3. Apply fabric softener to the softener compartment. Do not exceed the max line (A).
  • Page 31 CAUTION • Do not apply powder detergent to the liquid detergent guide. • Concentrated fabric softener must be diluted with water before applied. • Do not apply main-wash detergent to softener compartment. English 31...

  • Page 32: Operations

    Operations Control panel 01 Cycle Selector Turn the dial to select a cycle. The display shows current cycle information and estimated time 02 Display remaining, or an information code when a problem occurs. 03 Temp. Press to change the water temperature for the current cycle. Press to change the spinning speed for the current cycle.
  • Page 33 Press to activate/deactivate the Bubble Soak function. This function helps remove a wide variety of stubborn stains. 07 Bubble Soak • Bubble Soak is available with and adds up to 30 minutes to 5 cycles: COTTON, SYNTHETICS, DAILY WASH, BEDDING, and HYGIENE STEAM.

  • Page 34: Simple Steps To Start

    Operations Simple steps to start 1. Press Power to turn on the washing machine. 2. Turn the Cycle Selector to select a cycle. 3. Change the cycle settings (Temp., and Spin) as necessary. 4. To add an option, press Options. Use the button again to choose a preferred item. 5.

  • Page 35: Cycle Overview

    Cycle overview Standard cycles Cycle Description Max load (kg) • For cottons, bed linens, table linens, underwear, towels, or shirts. The washing time and COTTON the rinse count are automatically adjusted according to the load. • Optimal performance with lower energy for cotton fabrics, bed linens, table linens, COTTON underwear, towels, or shirts.
  • Page 36 Operations Cycle Description Max load (kg) • Specific for machine-washable wool and delicates fabrics such as sheer fabrics, bras, lingerie (silk), and other handwash-only fabrics. • The WOOL/DELICATES cycle features gentle WOOL/DELICATES cradling and soaking to protect fibres from shrinkage/distortion. •...
  • Page 37 Options Option Description • Super Rinse+ lets you enjoy a better rinsing performance. It uses extra water and a powerful spin to leave less detergent Super Rinse+ residue, so your clothes are cleaner and safer to wear if you have sensitive skin. •...
  • Page 38 Operations Delay End You can set the washing machine to finish your wash automatically at a later time, choosing a delay of between 1 to 24 hours (in 1 hour increments). The hour displayed indicates the time the wash will finish. 1.

  • Page 39: Settings

    Settings Child Lock Sound On/Off To prevent accidents by children, Child You can turn on or off the sound from the washing machine. Your setting will be kept Lock locks all buttons except for Power. even after restarting the machine. •...

  • Page 40: Maintenance

    Maintenance Keep the washing machine clean to prevent deteriorated performance and to preserve its life cycle. Eco drum clean Perform this cycle regularly to clean the drum and to remove bacteria from it. 1. Press Power to turn on the washing machine. 2.

  • Page 41: Smart Check

    Smart Check To enable this function, you must first download the Samsung Smart Washer app at the Play Store or the App Store, and install it on a mobile device featuring a camera function. The Smart Check function has been optimized for Galaxy & iPhone series (applicable models only).

  • Page 42: Emergency Drain

    Maintenance Emergency drain In case of a power failure, drain the water inside the drum before taking out the laundry. 1. Power off and unplug the washing machine from the electrical outlet. 2. Gently press the top area of the filter cover (A) to open.

  • Page 43: Cleaning

    Cleaning Surface of the washing machine Use a soft cloth with a nonabrasive household detergent. Do not spray water onto the washing machine. Mesh filter Clean the mesh filter of the water hose once or twice a year. 1. Turn off the washing machine, and unplug the power cord.
  • Page 44 Maintenance Pump filter It is advisable to clean the pump filter 5 or 6 times a year to prevent its clogging. A clogged pump filter may reduce the bubble effect. 1. Turn off the washing machine, and unplug the power cord. 2.
  • Page 45 Detergent drawer 1. While holding down the release lever (B) inside the drawer, slide open the drawer. 2. Remove the release lever and the liquid detergent guide from the drawer. 3. Clean the drawer components in flowing water using a soft brush. 4.

  • Page 46: Recovery From Freezing

    Maintenance Recovery from freezing The washing machine may freeze when it drops below 0 °C. 1. Turn off the washing machine, and unplug the power cord. 2. Pour warm water over the water tap to loosen the water hose. 3. Disconnect the water hose, and soak it in warm water. 4.

  • Page 47: Troubleshooting

    Troubleshooting Checkpoints If you encounter a problem with the washing machine, first check the table below and try the suggestions. Problem Action • Make sure the washing machine is plugged in. • Make sure the door is properly closed. • Make sure the water taps are open. •...
  • Page 48 Troubleshooting Problem Action • Make sure the drain hose is straightened all the way to the drain system. If you encounter a drain restriction, call for service. • Make sure the debris filter is not clogged. • Close the door and press Start/Pause. For your safety, the washing machine will not tumble or spin unless the door is Does not drain and/ closed.
  • Page 49 Problem Action • Plug the power cord into a live electrical outlet. • Check the fuse or reset the circuit breaker. • Close the door and press Start/Pause to start the washing machine. For your safety, the washing machine will not tumble or spin unless the door is closed.
  • Page 50 • Dry the washing machine interior after a cycle has finished. No bubbles are seen • Overloading may screen bubbles. (Bubbleshot models • Severely contaminated laundry may not generate bubbles. only). If a problem persists, contact a local Samsung service centre. English...

  • Page 51: Information Codes

    Water has overflowed. • Restart after spinning. • If the information code remains on the display, contact a local Samsung service centre. Check the drain hose. • Make sure the end of the drain hose is placed on the floor.
  • Page 52 • Depending on the state, the machine may automatically returns to normal operation. • Turn the machine off, and restart the cycle. • If the information code remains, contact a local Samsung service centre. The Main Door lock/unlock is not working properly.
  • Page 53 • The machine operates normally without running the ECO DRUM CLEAN cycle. However, it is recommended to run the cycle for hygienic purposes. If any information code keeps appearing on the screen, contact a local Samsung service centre. English 53...

  • Page 54: Specifications

    Specifications Fabric care chart The following symbols provide garment care directions. The care labels include four symbols in this order: washing, bleaching, drying and ironing (and dry cleaning when necessary). The use of symbols ensures consistency among garment manufacturers of domestic and imported items.

  • Page 55: Protecting The Environment

    Protecting the environment • This appliance is manufactured from recyclable materials. If you decide to dispose of this appliance, please observe local waste disposal regulations. Cut off the power cord so that the appliance cannot be connected to a power source. Remove the door so that animals and small children cannot get trapped inside the appliance.

  • Page 56: Specification Sheet

    Specifications Specification sheet “*” Asterisk(s) means variant model and can be varied (0-9) or (A-Z). Type Front loading washing machine Model name WW8*R42**** A (Width) 600 mm B (Height) 850 mm Dimensions C (Depth) 450 mm 525 mm 963 mm Water pressure 50-800 kPa Net weight...
  • Page 57 According to Regulation (EU) No. 1061/2010 “*” Asterisk(s) means variant model and can be varied (0-9) or (A-Z). Samsung Model Name WW8*R42**** Capacity Energy Efficiency A+++ Annual energy consumption is based on 220 standard washing cycles for standard cotton course at 60 °C and 40 °C at full and partial load, and the consumption of...

  • Page 58: Information Of Main Washing Programmes

    Specifications Information of main washing programmes Program Residual Water Energy Capacity Model Course Temp (°C) Time Moisture Consumption Consumption (kg) (min) Content (%) (L/cycle) (kWh/Cycle) COTTON 0.30 0.57 WW8*R42**** 0.68 COTTON 0.79 0.50 SYNTHETICS The values on the table have been measured under the conditions specified in Standard IEC60456/EN60456.
  • Page 59 Memo...
  • Page 60 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT ITALIA 800-SAMSUNG (800.7267864) www.samsung.com/it/support DC68-03752M-00...
