Toshiba Tecra A5-S516 Specifications

Tecra A5-S516 Detailed Product Specification
Model Name Description
Tecra A5-S516 Microsoft® Windows® XP Professional, Intel Pentium® M Processor 740, 512MB DDR,
60GB 5400rpm PATA, CD-RW/DVD-ROM, 14.0" widescreen high-brightness WXGA,
Intel Graphics Media Accelerator 900, Intel PRO/Wireless 2200BG (802.11b/g), 10/100
LAN, 6-cell, 1394, 5-in-1 Bridge Media Adapter, 1-year standard limited warranty
2
Operating System
• Microsoft® Windows® XP Professional
3
Processor and Chipset
Intel® Centrino™ Mobile Technology featuring:
• Intel Pentium® M Processor 740
o 1.73GHz, 2MB L2, 533MHz FSB
• Chipset
o Mobile Intel 915GM Express Chipset
• Integrated Wi-Fi™ compliant wireless LAN
o Intel PRO/Wireless 2200BG (802.11b/g),
4
Memory
• Configured with 512MB PC2700 DDR 333MHz SDRAM (using one
memory module, one memory expansion slot open)
• 512MB (Min)/2048MB (Max), 512MB in service-accessible memory
slot plus one available user-accessible memory slot for 256MB,
512MB, or 1024MB PC2700 DDR 333MHz SDRAM 2.5V
SODIMM memory modules
5
Hard Disk Drive
• 60GB (5400 RPM) Enhanced IDE (ATA-6) hard disk drive; 9.5mm
height; user removable
Fixed Optical Disk Drive
• CD-RW/DVD-ROM drive maximum speed and compatibility:
o CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read)
6
Display
• 14.0" diagonal widescreen high-brightness TFT active-matrix LCD
display at 1280x768 native resolution (WXGA)
7
Graphics
• Intel Graphics Media Accelerator 900 with 8MB-128MB dynamically
allocated shared graphics memory
Sound
• Realtek ALC250 16-bit stereo software sound
o Supports 3D Sound, Direct 3D Sound, DirectSound,
Direct Music, MIDI (playback)
• Built-in microphone
• Sound Volume Control Dial
• Built-in stereo speakers
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra A5-S516 BTS Rev. 1.03 2005-08-16 KK T20050810 CB1.10
1
• Control Buttons:
o Toshiba Assist button to launch Toshiba Assist control
o Presentation button to quickly connect to projectors
Communications
• Toshiba V.92 software modem
• Marcell 88E8036 - 10/100 Base-TX Ethernet
• Integrated Intel Pro/Wireless Network Connection 2200BG
(802.11b/g)
Expandability
• 2 main memory slots. Both slots may be occupied.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
• 5-in-1 Bridge Media Adapter (Secure Digital, Memory Stick™,
Memory Stick PRO™, Multi Media Card, xD Picture Card [shared
slots])
Ports
• RGB (monitor) port
• TV-out (S-Video)
• i.LINK(tm) IEEE-1394
• 4 Universal Serial Bus (USB) ports (v2.0)
• External Microphone jack
• Headphone jack
• RJ-45 LAN port
• RJ-11 modem port
• Fast Infrared (4Mbps) port For FIR
• 240-pin docking connector
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 13.5" (343.0mm) x 9.53"
(242.0mm) x 1.17" (29.8mm)[F]/1.50" (38.0mm)[R] without feet
• Weight: Starting at 5.00 lbs (2.26 kg) depending upon
configuration
• Indicators: DC-IN, Primary HDD Access, CD-RW/DVD-ROM
Access, Caps Lock, Arrow Mode, Numeric Mode, Battery
Charging Status, System Sleep/Suspend Status, Wireless
Communication, Bridge Media Reader
• Chassis Description
o Case material: Polycarbonate ABS
o LCD Cover Color: Premium Silver
• Physical Security
o Slot for cable lock;
o Items protected by a screw: Memory, Hard Disk Drive
• Software Security
o Passwords: User power-on password, supervisor
o Hotkey locks: Screen Blank
Power Supply
• 75W (15V x 5A) Auto sensing external AC Adapter, 100-240V / 50-
60Hz frequency (Universal) input.
• Dimensions (WxDxH): 5.35" (136.0mm) x 1.18" (30.0mm) x 2.09"
(53.0mm)
• Weight: starting at 0.88 lbs (400 g)
Part Number
PTA50U-02300Y
panel
8
9
10
password
UPC
032017375581
