Toshiba Satellite P505D-S8935 Specifications

Satellite P505D Detailed Product Specification
Model Name P505D-S8935
:
C1 2
Operating System
• Genuine Windows Vista
®
Home Premium (SP1,64-bit version)
Processor and Chipset
• AMD Turion™ X2 Dual-Core Mobile Processor RM-74
2.2GHz, 1MB L2 Cache, 3.6GT/s
o
• AMD M780G Chipset
4
Memory
• Configured with 4GB DDR2 800MHz (max 8GB)
5
Storage Drive
• 400GB (5400 RPM) Serial ATA hard disk drive
Fixed Optical Disk Drive
• DVD SuperMulti drive with Labelflash
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (24x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (6x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (6x)), DVD+RW (8x), DVD-
RAM (5x)
®
o Use Labelflash media to burn high quality labels directly to disc
7
Display
• 18.4" diagonal widescreen TruBrite
native resolution (HD+)
o Native support for 720p content
8
Graphics
• ATI Radeon™ HD 3200 Graphics with 256MB-1662MB dynamically
allocated shared graphics memory
Sound
• Built-in harman/kardon
®
stereo speakers
• Built-in microphone
Input Devices
• 104 key US keyboard with 10-key
• TouchPad™ pointing device with multi touch control
• TouchPad™ Enable/Disable
• Media Control Buttons:
o eco (Energy-saving mode)
o Mute
o Media
o CD/DVD control buttons
o Volume up, volume down
Communications
• Webcam and microphone
• Modem
9
• 10/100 Ethernet
• Realtek ®
802.11b/g/n wireless LAN
Expandability
• 2 main memory slots. Both slots may be occupied.
• ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)
• Memory Card Reader
Secure Digital, Secure Digital High Capacity, Memory Stick™,
o
Memory Stick PRO™, Multi Media Card ,xD Picture card[shared
slot]
Ports
• Video
RGB (monitor) output port
o
• Audio
Microphone input port
o
Headphone output port
o
• Data
i.LINK™ IEEE-1394
o
4 USB v2.0 ports
o
Part Number: PSPF0U-004003
3
6
®
supporting 11 formats
®
TFT LCD display at 1680x945
10
© Copyright 2009 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
1
o 3 x USB v2.0 ports
o 1 x eSATA/USB combo port with USB Sleep and Charge
RJ-45 LAN port
o
RJ-11 modem port
o
• Security
Slot for Security Lock
o
Physical Description
• Fusion Finish™ with Sonic Pattern in Black Onyx
• Dimensions (W x D x H ): 17.4" x 11.6" x 1.68"/1.63"
• Weight: Starting at 9.7 lbs., depending upon configuration
13
Battery
• 4000 mAh (6 cell) Lithium Ion battery pack
• Battery Life (measured by MobileMark™ 2007)
Included 6-cell battery: 2 hours, 0 minutes
o
Power Supply
• 90W (19V x 4.74A) Auto-sensing ,100-240V/50-60Hz AC Adapter
• Dimensions (W x D x H): 5.2" x 2.3" x 1.2"
• Weight: starting at .81 lbs.
C1
Software
• Toshiba Software and Utilities
Electronic User's Guide
o
Bluetooth Stack for Windows by Toshiba
o
TOSHIBA Resources page
o
TOSHIBA Recovery Disc Creator
o
TOSHIBA ConfigFree
o
TOSHIBA Disc Creator
o
TOSHIBA DVD Player
o
TOSHIBA Face Recognition
o
TOSHIBA Power Saving ECO utility
o
TOSHIBA PC Health Monitor
o
TOSHIBA Hard Drive Impact Sensor(3D sensor)
o
Hard Disc Drive (HDD) Recovery
o
• Third-party Software
Microsoft
o
Microsoft
o
Google™ Toolbar
o
Google™ Picasa™
o
®
Sun Java™ 2 Runtime Environment
o
Adobe
o
®
Corel
o
PowerCinema for TOSHIBA
o
WildTangent
o
• Trial Software
Norton Internet Security™ 2009, 30-day trial
o
Microsoft
o
• Special Offers
Amazon.com - Online Shopping
o
NetZero
o
Skype
o
Intuit Quickbooks Financial Center 2009
o
Environmental Specifications
• This product is RoHS
17
Temperature
Relative Humidity
(non-condensing)
Thermal Gradient
Altitude
(relative to sea level)
Shock
Vibration
Satellite P505D-S8935
UPC: 883974252640
15
®
®
Windows Media Player
®
Works 9
® ®
Acrobat Reader
®
DVD MovieFactory for TOSHIBA
®
Orb™ Game Console
®
Office Home and Student 2007 Edition, 60-day trial
®
Internet Service
®
16
compatible
Operating
5° to 35° C
20% to 80%
15° C per hour (max)
0 to 3,000 meters
10G
0.5G
11
12
14
Non-operating
-20° to 60° C
10% to 95%
20° C per hour (max)
0 to 10,000 meters
60G
1.0G
Page 1 of 4
