V-025 Series User Guide v1.0_V-025 30/09/2011 12:46 Page 1
Vax Careline: (UK) 0844 412 8455
(ROI) 1-800 928 308
Carpet washer
Classic
Vax model number:
V-025 series
Version 1.0
Please read carefully before using this carpet
vax.co.uk
washer. Always fully extend the mains cable
before use. Retain for future reference.

Advertisement

loading

Related Manuals for Vax Rapide Classic V-025 Series

Summary of Contents for Vax Rapide Classic V-025 Series

  • Page 1 V-025 Series User Guide v1.0_V-025 30/09/2011 12:46 Page 1 Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308 Carpet washer Classic Vax model number: V-025 series Version 1.0 Please read carefully before using this carpet vax.co.uk washer. Always fully extend the mains cable...
  • Page 2 1. Diagram V-025 SOLUTION Fig.1/1 1 Handle 10 Dirty water tank lid 19 Vax carpet cleaning solution 2 Handle screw 11 Rotating brushbar 20 Float chamber filter 3 On/off switch 12 Solution release trigger (installed under dirty water 4 Brushbar on/off switch...

  • Page 3: Safety Information

    V-025 Series User Guide v1.0_V-025 30/09/2011 12:46 Page 3 Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308 2. Safety Information 20. Using improper voltage may result in damage to the motor and possible injury to the user. The correct voltage is listed on the rating label.
  • Page 4 V-025 Series User Guide v1.0_V-025 30/09/2011 12:46 Page 4 vax.co.uk 3. Assembly Attach upper handle Stand the base in the upright position. Assemble the mid section onto the base, taking care not to trap internal mains wire. (Fig.3/1). Fig.3/1 Insert the two nuts into the recesses located on the left and right sides of the base.

  • Page 5: Operation

    V-025 Series User Guide v1.0_V-025 30/09/2011 12:46 Page 5 Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308 4. Operation NOTE: Use only Vax carpet cleaning solution, as other cleaning solutions may cause excessive foaming. This may IMPORTANT: Turn off when emptying and filling the cause the float to shut off the cleaner prematurely.
  • Page 6 Release the trigger and pull For best results use only Vax carpet cleaning solution. the cleaner backwards over the same path to remove the dirty water and solution from the carpet. Repeat if Hold the top of the dirty water tank handle and press the necessary (Fig.4/6).
  • Page 7 V-025 Series User Guide v1.0_V-025 30/09/2011 12:46 Page 7 Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308 To empty the water tank grasp the handle with one hand dirty water tank is resting on the base. and the nozzle with the other and empty into the The dirty water tank has three tabs on the underside sink (Fig.4/11).

  • Page 8: Maintenance

    V-025 Series User Guide v1.0_V-025 30/09/2011 12:46 Page 8 vax.co.uk 5. Maintenance Lift brushbar while pulling it out (Fig.5/4). Belt or Brush Removal and Replacement Crosshead screwdriver required IMPORTANT: Plug must be removed from socket outlet before cleaning or maintaining the appliance.

  • Page 9: Troubleshooting

    V-025 Series User Guide v1.0_V-025 30/09/2011 12:46 Page 9 Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308 Separate the foam filter from the float (Fig.5/7). 6. Troubleshooting WARNING: To reduce the risk of personal injury, unplug the carpet washer before performing maintenance or troubleshooting checks.
  • Page 10 8.30am to 6.30pm Weight: Saturday-Sunday 9.00am to 5.00pm If you have queries or concerns about using your Vax, call Subject to technical change without notice. the Vax Careline. Calls are charged at the UK local rate. Please make a note of the serial number and model number of the vacuum cleaner before calling.
  • Page 11 V-025 Series User Guide v1.0_V-025 30/09/2011 12:46 Page 11 Vax Careline: (UK) 0844 412 8455 (ROI) 1-800 928 308 This page has been left intentionally blank. maintenance / troubleshooting...
  • Page 12 V-025 Series User Guide v1.0_V-025 30/09/2011 12:46 Page 12 EEC STATEMENT OF COMPLIANCE Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the Vax V-025 series carpet washer is manufactured in compliance with the following Directives: Safety: 2006/95/EC Low Voltage Directive EMC: 2004/108/EC Electromagnetic Compatibility Directive Waste electrical products should not be disposed of with household waste.
