30" (76.2 CM) DOUBLE OVEN GAS RANGES
INSTRUCTIONS POUR L'INSTALLATION
DES CUISINIÈRES À GAZ À DOUBLE FOUR
RANGE SAFETY .............................................................................2
INSTALLATION REQUIREMENTS .................................................4
Tools and Parts .............................................................................4
Location Requirements ................................................................4
Electrical Requirements ...............................................................6
Gas Supply Requirements ...........................................................6
INSTALLATION INSTRUCTIONS ...................................................7
Unpack Range..............................................................................7
Adjust Leveling Legs ....................................................................7
Install Anti-Tip Bracket .................................................................8
Make Gas Connection .................................................................8
Verify Anti-Tip Bracket Is Installed and Engaged ........................9
Level Range ................................................................................10
Electronic Ignition System .........................................................10
Complete Installation .................................................................11
GAS CONVERSIONS ....................................................................12
LP Gas Conversion ....................................................................12
Natural Gas Conversion .............................................................15
IMPORTANT:
Save for local electrical inspector's use.
Installer: Leave installation instructions with the homeowner.
Homeowner: Keep installation instructions for future reference.
IMPORTANT :
À conserver pour consultation par l'inspecteur local des installations électriques.
Installateur : Remettre les instructions d'installation au propriétaire.
Propriétaire : Conserver les instructions d'installation pour référence ultérieure.
W10575961C
INSTALLATION INSTRUCTIONS
DE 30" (76,2 CM)
Table of Contents/Table des matières
SÉCURITÉ DE LA CUISINIÈRE ...................................................19
EXIGENCES D'INSTALLATION ...................................................20
Outils et pièces ...........................................................................20
Exigences d'emplacement .........................................................21
Spécifications électriques ..........................................................22
Spécifications de l'alimentation en gaz .....................................23
INSTRUCTIONS D'INSTALLATION .............................................24
Déballage de la cuisinière ..........................................................24
Réglage des pieds de nivellement .............................................24
Installation de la bride antibasculement ....................................25
Raccordement au gaz ................................................................25
Vérifier que la bride antibasculement
est bien installée et engagée .....................................................26
Réglage de l'aplomb de la cuisinière .........................................27
Système d'allumage électronique..............................................27
Achever l'installation ..................................................................28
CONVERSIONS POUR CHANGEMENT DE GAZ ......................29
Conversion pour l'alimentation au propane ..............................29
Conversion pour l'alimentation au gaz naturel ..........................33
Advertisement
Table of Contents
Related Manuals for Whirlpool WGG755S0BS04
Summary of Contents for Whirlpool WGG755S0BS04
-
Page 1: Table Of Contents
INSTALLATION INSTRUCTIONS 30" (76.2 CM) DOUBLE OVEN GAS RANGES INSTRUCTIONS POUR L’INSTALLATION DES CUISINIÈRES À GAZ À DOUBLE FOUR DE 30" (76,2 CM) Table of Contents/Table des matières RANGE SAFETY ................2 SÉCURITÉ DE LA CUISINIÈRE ...........19 INSTALLATION REQUIREMENTS ..........4 EXIGENCES D’INSTALLATION ...........20 Tools and Parts ................4 Outils et pièces ................20 Location Requirements ..............4... -
Page 2: Range Safety
RANGE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... - Page 3 In the State of Massachusetts, the following installation instructions apply: Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by the State of Massachusetts. If using a ball valve, it shall be a T-handle type. A flexible gas connector, when used, must not exceed 3 feet.
-
Page 4: Installation Requirements
INSTALLATION REQUIREMENTS Tools and Parts Location Requirements Gather the required tools and parts before starting installation. IMPORTANT: Observe all governing codes and ordinances. Read and follow the instructions provided with any tools listed Do not obstruct flow of combustion and ventilation air. here. - Page 5 Product Dimensions Cabinet Dimensions Cabinet opening dimensions shown are for 25" (64.0 cm) countertop depth, 24" (61.0 cm) base cabinet depth and 36" (91.4 cm) countertop height. IMPORTANT: If installing a range hood or microwave hood combination above the range, follow the range hood or microwave hood combination installation instructions for dimensional clearances above the cooktop surface.
-
Page 6: Electrical Requirements
Electrical Requirements Gas Supply Requirements WARNING WARNING Electrical Shock Hazard Explosion Hazard Plug into a grounded 3 prong outlet. Use a new CSA International approved gas supply line. Install a shut-off valve. Do not remove ground prong. Securely tighten all gas connections. Do not use an adapter. -
Page 7: Installation Instructions
Flexible metal appliance connector: Gas Pressure Regulator If local codes permit, a new CSA design-certified, 4 to ■ 5 ft (122 to 152.4 cm) long, ½" (1.3 cm) or ¾" (1.9 cm) The gas pressure regulator supplied with this range must be I.D., flexible metal appliance connector may be used used. -
Page 8: Install Anti-Tip Bracket
4. Drill two " (3.0 mm) holes that correspond to the bracket Install Anti-Tip Bracket holes of the determined mounting method. See the following illustrations. WARNING Floor Mounting Wall Mounting Tip Over Hazard A child or adult can tip the range and be killed. Install anti-tip bracket to floor or wall per installation instructions. -
Page 9: Verify Anti-Tip Bracket Is Installed And Engaged
3. Use a " combination wrench and an adjustable wrench 2. Test all connections by brushing on an approved to attach the flexible connector to the adapters. Check that noncorrosive leak-detection solution. If bubbles appear, connector is not kinked. a leak is indicated. Correct any leak found. IMPORTANT: All connections must be wrench-tightened. -
Page 10: Level Range
3. If the rear of the range lifts more than ½" (1.3 cm) off the floor Check Operation of Cooktop Burners without resistance, stop tilting the range, and lower it gently back to the floor. The range foot is not engaged in the anti- Standard Surface Burners tip bracket. -
Page 11: Complete Installation
Check Operation of Both Oven Bake Burners Complete Installation 1. Press BAKE for the desired oven. 1. Check that all parts are now installed. If there is an extra part, go back through the steps to see which step was skipped. “BAKE”... -
Page 12: Gas Conversions
GAS CONVERSIONS Gas conversions from Natural gas to LP gas or from LP gas LP Gas Conversion to Natural gas must be done by a qualified installer. WARNING WARNING Explosion Hazard Use a new CSA International approved gas supply line. Tip Over Hazard Install a shut-off valve. - Page 13 2. Unscrew the regulator cap and remove the plastic cover. 5. Unscrew wing nut and remove oven baffle. A. Plastic cover B. Regulator cap A. Oven baffle 3. Flip the regulator cap over and replace the plastic cover. B. Wing nut 6.
- Page 14 9. Turn the Number 0.070 Natural gas orifice hood To Convert Oven Broil Burner (Natural Gas to LP) counterclockwise to remove. 1. Remove broil burner screw and set aside. 2. Remove the broil burner from the broil burner orifice hood. The broil burner will hang in the back of the oven while changing the orifice hood.
-
Page 15: Natural Gas Conversion
5. Place the broil burner on the broil burner orifice hood. Insert LP Gas Orifice Spud Chart the broil burner locator pin in the hole in the oven back. Burner Rating Color Number 6. Position the broil burner against the roof of the oven cavity and attach with screw. - Page 16 To Convert Gas Pressure Regulator To Convert Oven Bake Burners (LP to Natural Gas) (LP to Natural Gas) To Convert Lower Oven Bake Burner: 1. Locate gas pressure regulator at the rear of the range. 1. Remove oven racks from inside the oven cavity. 2.
- Page 17 8. Unscrew and remove the cover over the orifice. 11. Position the oven bake burner over the orifice hood and reinstall using screw. A. Orifice cover A. Bake burner orifice hood B. Oven bake burner 9. Turn the Number 0.044 LP gas orifice hood counterclockwise C.
- Page 18 3. Turn the green Number 0.037 LP gas broil burner orifice 3. Using a Phillips or TORX screwdriver, remove the burner base. ® hood counterclockwise to remove. A. Burner cap B. Gas tube opening C. Burner base screws D. Burner base A.
