Washing Machine
WF8802RP-02600R_EN.indd 1
WF8804JP(A/F/G/H/S/V/W/Z)
WF8802JP(A/F/G/H/S/V/W/Z)
WF8800JP(A/F/G/H/S/V/W/Z)
WF8704JP(A/F/G/H/S/V/W/Z)
WF8702JP(A/F/G/H/S/V/W/Z)
WF8700JP(A/F/G/H/S/V/W/Z)
user manual
imagine
the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/global/register
WF8804EP(A/F/G/H/S/V/W/Z)
WF8802EP(A/F/G/H/S/V/W/Z)
WF8800EP(A/F/G/H/S/V/W/Z)
WF8704EP(A/F/G/H/S/V/W/Z)
WF8702EP(A/F/G/H/S/V/W/Z)
WF8700EP(A/F/G/H/S/V/W/Z
WF8804RP(A/F/G/H/S/V/W/Z)
WF8802RP(A/F/G/H/S/V/W/Z)
WF8800RP(A/F/G/H/S/V/W/Z)
WF8704RP(A/F/G/H/S/V/W/Z)
WF8702RP(A/F/G/H/S/V/W/Z)
WF8700RP(A/F/G/H/S/V/W/Z)
2008-06-13 ¿ÀÀü 10:07:13
Advertisement
Table of Contents
Related Manuals for Samsung WF8804JP Series
Summary of Contents for Samsung WF8804JP Series
- Page 1 WF8702JP(A/F/G/H/S/V/W/Z) WF8702EP(A/F/G/H/S/V/W/Z) WF8700JP(A/F/G/H/S/V/W/Z) WF8700EP(A/F/G/H/S/V/W/Z WF8804RP(A/F/G/H/S/V/W/Z) WF8802RP(A/F/G/H/S/V/W/Z) WF8800RP(A/F/G/H/S/V/W/Z) WF8704RP(A/F/G/H/S/V/W/Z) WF8702RP(A/F/G/H/S/V/W/Z) WF8700RP(A/F/G/H/S/V/W/Z) Washing Machine user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/global/register WF8802RP-02600R_EN.indd 1 2008-06-13 ¿ÀÀü 10:07:13...
- Page 2 • Baby Care System Your Samsung washing machine includes wash programs that adds protection to the clothing of children with sensitive skin. These programs reduce skin irritation in children by minimizing detergent residue. In addition,...
- Page 3 This manual contains important information on the installation, use, and care of your new Samsung washing machine. Refer to it for descriptions of the control panel, instructions on how to use the washing machine, and tips for making the most of its state-of-the-art features and functions.
- Page 4 It’s your responsibility to use common sense, caution, and care when installing, maintaining, and operating your washing machine. Samsung is not liable for damages resulting from improper use. IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS...
- Page 5 To reduce the risk of fire or explosion: • Do not wash items that have been washed, soaked, or treated with gasoline, dry CAUTION cleaning solvents, or other flammable or explosive substances. They give off vapors that could ignite or explode. Rinse by hand any material that has been exposed to cleaning solvent or other flammable liquids or solids before putting in your washing machine.
- Page 6 safety information The appliance is designed for home use only. Make sure that water and electrical connections are made by qualified technicians, observing the user manual (see “Installing your washing machine”) and local safety WARNING regulations. Before cleaning or carrying out maintenance, unplug the appliance from the electrical outlet. Always unplug the appliance and turn off the water after use.
- Page 7 A stainless washing tub does not usually rust. However if some metal such as a hair pin is left in the tub for an extended time, the tub could rust. • Do not leave water or bleach containing chlorine in the tub for an extended period of time.
-
Page 8: Table Of Contents
contents SETTING UP YOUR WASHING Checking the parts MACHINE Meeting installation requirements Electrical supply and grounding Water Supply Drain Flooring Surrounding temperature Alcove or closet installation Installing your washing machine WASHING A LOAD OF LAUNDRY Washing for the first time Basic instructions Using the control panel Child lock... -
Page 9: Setting Up Your Washing Machine
Carefully unpack your washing machine, and make sure you’ve received all of the parts shown below. If your washing machine was damaged during shipping, or if you do not have all of the parts, contact Samsung Customer Service or your Samsung dealer. Release lever... -
Page 10: Meeting Installation Requirements
setting up your washing machine MEETING INSTALLATION REQUIREMENTS Electrical supply and grounding To prevent unnecessary risk of fire, electrical shock, or personal injury, all wiring and grounding must be done in accordance with the National Electrical Code ANSI/FNPA, No. 70 Latest Revision and local codes and ordinances. -
Page 11: Drain
Drain Samsung recommends a standpipe height of 18 in (46 cm). The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached at the factory. - Page 12 setting up your washing machine STEP 2 Removing the shipping bolts Before installing the washing machine, you must remove the five shipping bolts from the back of the unit. 1. Loosen all the bolts with the supplied wrench. 2. Hold the bolt with the spanner and pull it through the wide section of the hole.
- Page 13 STEP 3 Adjusting the levelling feet When installing your washing machine, ensure that the power plug, the water supply and the drain are easily accessible. 1. Slide the washing machine into position. 2. Level your washing machine by turning the leveling feet in and out as necessary by hand.
- Page 14 setting up your washing machine Connecting the water supply hose (selected models) 1. Remove the adaptor from the water supply hose. Adaptor Water supply hose 2. First, using a ‘+’ type screwdriver, loosen the four screws on the adaptor. Next, take the adaptor and turn part (2) following the arrow until there is a 5 mm gap.
- Page 15 6. Turn on the water supply and ensure that no water leaks ✗ from the water valve, tap or adaptor. If there is a water leaks, repeat the previous steps. Do not use your washing machine if there is a water leak. This may cause electric shock or injury.
- Page 16 setting up your washing machine Connecting the drain hose The end of the drain hose can be positioned in three ways: 1. Over the edge of a wash basin: The drain hose must be placed at a height of between 60 and 90 cm.
-
Page 17: Washing A Load Of Laundry
With your new Samsung washing machine, the hardest part of doing laundry will be deciding which load to wash first. WASHING FOR THE FIRST TIME Before washing laundry for the first time, you must run a complete empty cycle (i.e. no laundry). -
Page 18: Using The Control Panel
washing a load of laundry USING THE CONTROL PANEL DIGITAL GRAPHIC Displays the remaining wash cycle time, all cycle information, and error DISPLAY messages. Select the tumble pattern and spin speed for the cycle. For detailed information, refer to “Washing clothes using the cycle selector”... - Page 19 Press this button to select pre-wash. Pre-wash is only available with: PREWASH Cottons, Synthetics, Denim, Sports Wear, Baby Care, Dark Garment, SELECTION BUTTON Daily Wash. Press this button repeatedly to cycle through the available Delay Start DELAY END options (from 3 hours to 19 hours in one hour increments). SELECTION BUTTON The hour displayed indicates the time when the wash cycle will be finished.
-
Page 20: Child Lock
washing a load of laundry Child lock The Child Lock function allows you to lock the buttons so that the wash cycle you’ve chosen can’t be changed. Activating/Deactivating If you want to activate or deactivate the Child Lock function, press the Temp. and Rinse buttons at the same time for 3 seconds. -
Page 21: Air Wash
Air Wash Air Wash can refresh laundry without using water owing to its powerful airing system. Clothing that can be refreshed includes woolen coats, cotton or jumpers, sweaters and suits. (Two items or less (less than 1 kg)) 1. Open the door, place the laundry into the washing machine and close the door. 2. -
Page 22: Washing Clothes Using The Cycle Selector
Washing clothes using the cycle selector Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control” automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed. -
Page 23: Washing Clothes Manually
Washing clothes manually You can wash clothes manually without using the Cycle Selector. 1. Turn the water supply on. 2. Press the Power button on the washing machine. 3. Open the door. 4. Load the articles loosely into the drum one at a time, without overfilling it. 5. - Page 24 washing a load of laundry LAUNDRY GUIDELINES Follow these simple guidelines for the cleanest laundry and the most efficient wash. Always check the Care label on clothing before washing. Sort and wash your laundry according to the following criteria: • Care Label: Sort laundry into cottons, mixed fibres, synthetics, silks, wools and rayons.
-
Page 25: Detergent And Additives Information
Make sure to insert brassieres (water washable) into a laundry net (to be purchased additionally). • The metal parts of the brassieres may break through the material and damage the laundry. Therefore make sure to place them inside a fine laundry net. •... -
Page 26: Cleaning And Maintaining Your Washing Machine
cleaning and maintaining your washing machine Keeping your washing machine clean improves its performance, wards off unnecessary repairs, and lengthens its life. DRAINING THE WASHING MACHINE IN AN EMERGENCY 1. Unplug the washing machine from the power supply. 2. Open the filter cover using a coin or a key. Filter cover 3. -
Page 27: Cleaning The Detergent Drawer And Drawer Recess
CLEANING THE DETERGENT DRAWER AND DRAWER RECESS 1. Press the release lever on the inside of the Release lever detergent drawer and pull the drawer out. Liquid detergent divider 2. Remove the liquid detergent divider from the detergent drawer 3. Wash all parts under running water. 4. -
Page 28: Cleaning The Water Hose Mesh Filter
cleaning and maintaining your washing machine CLEANING THE WATER HOSE MESH FILTER You should clean the water hose mesh filter at least once a year, or when the error message of “4E” is displayed: 1. Turn off the water supply to the washing machine. 2. -
Page 29: Troubleshooting And Information Codes
Door is locked shut or will The door will not open until 3 minutes after the machine stops or the not open. power turns off. If the problem persists, contact your local Samsung Customer Service. troubleshooting and information codes _29 WF8802RP-02600R_EN.indd 29 2008-06-13 ¿ÀÀü 10:07:33... - Page 30 • Call the after-sales service. cE/3E For any codes not listed above, or if the suggested solution doesn’t fix the problem, call your Samsung Service Centre or local Samsung dealer. 30_ troubleshooting and information codes WF8802RP-02600R_EN.indd 30...
- Page 31 cycle chart CYCLE CHART user option) Max load(kg) DETERGENT Max Temp WF8804/ WF8704/ PROGRAM (˚C) WF8802/ WF8702/ Pre-wash wash Softener WF8800 WF8700 Cottons Synthetics Denim Sports Wear Delicates Wool Handwash Baby Care ...
-
Page 32: Appendix
appendix FABRIC CARE CHART The following symbols provide garment care directions. The care labels include four symbols in this order: washing, bleaching, drying and ironing, and dry cleaning when necessary. The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow the care label directions to maximize garment life and reduce laundering problems. - Page 33 SPECIFICATIONS TYPE FRONT LOADING WASHING MACHINE WF8804EP/WF8804RP/WF8804JP WF8704EP/WF8704RP/WF8704JP WF8802EP/WF8802RP/WF8802JP WF8702EP/WF8702RP/WF8702JP DIMENSIONS WF8800EP/WF8800RP/WF8800JP WF8700EP/WF8700RP/WF8700JP W598mm X D600mm X H844mm W598mm X D600mm X H844mm WATER PRESSURE 50 kPa ~ 800 kPa WATER VOLUME ℓ ℓ WF8804EP/ WF8802EP/ WF8800EP/ WF8704EP/ WF8702EP/ WF8700EP/ WF8804RP/ WF8802RP/ WF8800RP/...
- Page 34 memo WF8802RP-02600R_EN.indd 34 2008-06-13 ¿ÀÀü 10:07:38...
- Page 35 memo WF8802RP-02600R_EN.indd 35 2008-06-13 ¿ÀÀü 10:07:38...
- Page 36 QUESTIONS OR COMMENTS? Country CALL OR VISIT US ONLINE AT MALAYSIA 1800-88-9999 www.samsung.com/my Code No. DC68-02600R_EN WF8802RP-02600R_EN.indd 36 2008-06-13 ¿ÀÀü 10:07:38...
