Related Manuals for LG GR-N281HLQ
Summary of Contents for LG GR-N281HLQ
- Page 1 OWNER’S MANUAL FREEZER Please read this owner’s manual thoroughly before operating and keep it handy for reference at all times. GR - N254BLQ www.lg.com P/No. : MFL62525414...
-
Page 3: Table Of Contents
Table of Contents Introduction Registration Important Safety Instruction Identification of Parts Operation Temperature Control Display Panel For Temperature Control Power How to adjust the temperature in the freezer compartment Super Freezer Self Test Door Alarm Ice Making Defrosting Suggestion On About Ice Food storage How to store food properly... -
Page 4: Introduction
Introduction Registration Introduction The model and serial number are found on the rear of this unit. This number is unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. - Page 5 Introduction Important Safety Instruction WARNING To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety precautions should be followed, including the following. Read all instructions before using this appliance. 1. When connecting the power A dedicated outlet should be used.
- Page 6 Introduction Important Safety Instruction Do not extend or modify the length of the power plug. This may become the cause of fire or electric shock. Unplug the power plug when cleaning, handling or replacing the interior lamp of the fridge-freezer. It may cause electric shock or injury.
- Page 7 Introduction Important Safety Instruction Make sure of grounding. Consult a qualified electrician or service person if the grounding instructions are not completely Ground Wire understood, or if you have doubts More than Copper 30 inches Flat on whether the appliance is properly grounded.
- Page 8 Introduction Important Safety Instruction Prevent children from entering the product. It may endanger the life of a child if the child enters the refrigerator. Take care when opening and closing the refrigerator doors. Vigorous opening or closing may cause the contents to topple out resulting in injury or damage.
- Page 9 Introduction Important Safety Instruction Do not store medicine or academic materials in the fridge-freezer. If materials with strict temperature restrictions, such as medicines, are stored, they may deteriorate or react undesirably resulting in possible harm or risk. Do not use any combustible spray near the fridge- freezer.
- Page 10 Introduction Important Safety Instruction DO NOT use a water damaged unit until it has been certified safe by a licensed electrician or similarly qualified person. It may be the cause of an electric shock or fire. When gas is leaked, do not touch the fridge/freezer or the outlet and ventilate the room immediately.
- Page 11 Introduction Important Safety Instruction Do not allow any person except a qualified engineer to disassemble, repair or alter the fridge- freezer. It may cause injury, electric shock or fire. Do not use the fridge-freezer for non-domestic puposes (storing medicine or testing material, or use in a mobile application.) It may cause an unexpected risk such as fire, electric shock, deterioration of...
- Page 12 Introduction Important Safety Instruction Install the fridge-freezer on a solid and level floor. Installing it in an unstable place may cause death by the refrigerator falling down when opening or closing the door. Do not insert hands or a metal object into the exit of cool air, the cover, the bottom of the fridge- freezer, the heatproof grill (exhaust hole) at the back.
- Page 13 Introduction Important Safety Instruction Do not insert hands into the bottom of the fridge- freezer. The iron plate at the bottom may cause injury. Carry the fridge-freezer with the handles at the bottom of the front and the top of the rear. Otherwise, your hands may slip possibly resulting in injury or product damage.
- Page 14 Introduction Important Safety Instruction WARNING This fridge-freezer must be properly installed and Precaution • located in accordance with the Installation Instruction before it is used. Before you install this fridge-freezer refer to installation • manual. Never unplug your fridge-freezer by pulling on the •...
- Page 15 Introduction Important Safety Instruction Do not disassemble, repair or alter the appliance. It • may cause fire or abnormal operations, which may lead to injury. Pull the power plug out of the socket before replacing • the interior light in the refrigerator. Otherwise, there is a risk of electric shock.
- Page 16 Introduction Important Safety Instruction WARNING Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit.
- Page 17 Introduction Important Safety Instruction CAUTION If the wall socket is loose, do not insert the power • plug. It may cause an electric shock or fire. Never unplug your refrigerator by pulling on the • power cord. Always grip plug firmly and pull it straight out from the outlet.
-
Page 18: Identification Of Parts
Introduction Identification of Parts Freezer Shelf Ice Tray & Bank Freezer Compartment Leveling Screw... -
Page 19: Operation
Operation Temperature Control Your freezer has controls that let you regulate the temperature in the freezer compartments. Display Panel For Temperature Control Adjusting the temperatures and functions Display Panel POWER SUPER FRZ. FRZ.TEMP. 3SECS Super Freezer Power Temperature Adjustment Button for Freezer Compartment... -
Page 20: Power
Operation Power If you push button more than 3 seconds • you can switch on or off the Freezer. POWER 3SECS How to adjust the The initial Temperature of the Freezer Compartment is • -23°C and -15°C respectively. temperature in the You can now adjust the temperature of the freezer compartments as you want. -
Page 21: Super Freezer
Operation Super Feezer Please select this function for prompt freezer. • This function is used when you want to freeze the • foods quickly. Press the SUPER FRZ (Super Freezer) button once, and then the quick freeze operation starts with the lamp it. The Super Freeze operation takes about 3 hours. -
Page 22: Ice Making
Operation Ice Making Fill water in ice making tray. Only fill • with enough water to maintain individual blocks, if over filled blocks will not separate properly and water may spill into ice bin clumping ice together. Ice will be dropped into the ice •... -
Page 23: Suggestion On Food Storage
Suggestions on food storage About Ice 1. Fill water up to the level line of the ice-making tray. The level line - It is hard to remove ice if water is full. - When you want to freeze ice quickly, select "Quick freezing". -
Page 24: Storing Food
Suggestions on food storage Storing Food CAUTION Do not store food which goes bad easily at low • temperature, such as banana, and melon. Allow hot food to cool prior to storing. Placing hot • food in the freezer could spoil other food, and lead to higher electric bills. -
Page 25: Care And Maintenance
Care and Maintenance General Information Power Failure 1~2 hour power failure does no harm to the foods • stored. Try to avoid opening and closing the door too frequently. If You Move Take out foods from the freezer and firmly fix the loose •... -
Page 26: How To Disassemble Each Component
Care and Maintenance How to disassemble each component It can be possible to disassemble only when the door is opened by 90° or wider. Disassembling should be done by the reverse order of assembling. Lift up the shelf cover, and then slightly lift Upper shelf up and pull out the front of the shelf to remove. -
Page 27: Cleaning
Care and Maintenance Cleaning Before Cleaning Be sure to unplug the power or shutdown the main switch in your house. Exterior Clean the outside of the freezer with a hot damp cloth with or without cleaning detergent. If you use a detergent, be sure to wipe it with a clean wet cloth. -
Page 28: Trouble Shooting
Trouble Shooting Before calling for service, check this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Possible Causes Problem Freezer does not Power plug may be unplugged from the electric •... - Page 29 Trouble Shooting Problem Possible Causes Moisture collects Door opened too frequently or for to long a period. • inside In humid weather, air carries moisture into freezer • when doors are opened. Foods with strong odors should be tightly covered or Freezer has odor •...
- Page 30 Memo...
- Page 31 Memo...
- Page 32 LG Twin Tower, 20, Yoido-Dong, Youngdungpo-Gu, Seoul, 150-721, Korea. Printed in Korea...
