Whirlpool UW6 F2Y WBI F 2 Quick Start Manual

Read the Instructions for Use carefully before using
the appliance.
2
1
3
4
11
5
6
7
8
12
9
10
1. External Indicators of Power On and alarms
2. Control panel
3. LED's lighting*
4. Ice packs*
5. Ice Mate* or Ice tray*
6. Drawer divider*
7. Bottle rack*
8. Glass shelves
9. Rating plate with commercial name
10. Door reversibility kit
11.
12. Area for storing frozen foods
13. Door seal
* Available on selected models
HOW TO START THE APPLIANCE
After plugging the appliance to the mains, it starts the
operation automatically. After starting the appliance,
wait at least 4-6 hours before placing food into the
appliance. When the appliance is connected to the
power supply, the display lights up and all the icons
appear on the display for approximately 1 second.
The default (factory) values of the freezer compartment
settings light-up.
HOW TO REVERSE THE DOOR SWING
- see enclosed Instructions for Use (Version_2)
Is recommended to reverse door swing by two persons.
There is not foreseen door reversibility for:
- models with integrated handle
- models with glass panel on the door.
model to model
POWER ON (EXTERNAL LED) indicator
An external green LED showing that the appliance is
switched ON. It automatically turns o when opening
the door.
PARTY MODE indicator
FAST FREEZE indicator
ON/STANDBY button
To put the product in Stand-by, press and hold for
3 seconds. All the icons turn o except On/Standby
indicator . To reactivate the appliance press once
(brie y) this button.
13
FREEZE CONTROL indicator
PARTY MODE / FREEZE CONTROL button
Party Mode
Press to activate/deactivate the Party Mode function.
Use this function to chill drinks inside the freezer
compartment.
Important: do not leave the bottle inside the freezer
compartment longer than the function is active (30
minutes).
Freeze Control
Freeze Control is an advanced technology that
reduces temperature uctuations in the whole freezer
compartment to minimum. To activate/deactivate the
Freeze Control function simply press FREEZE CONTROL
button. If the function is engaged and the user modify
the freezer temperature out of the working range, the
function is automatically switched o . In case of Fast
freezing is engaged, the function "Freeze control" is
inhibited until the Fast Freezing function switched o
(see the Instructions for Use).
ALARM TYPE Signal
Door open alarm
The acoustical alarm is activated and the Alarm Indicator
Temperature alarm
The Temperature display blinks (°C) and the Alarm Indicator
Party Mode alarm
The Party Mode Indicator blinks and the acoustical alarm is activated.
The Black Out Alarm icon remains on, the Alarm indicator
Long black-out alarm
Malfunction The letter "F" blinks on the display (°C).
GB
FR NL ES PT BG ET EL
QUICK START GUIDE
6TH SENSE FREEZE CONTROL
6th Sense Freeze Control is an advanced technology that reduces
freeze burns and food preserves its original quality and color.
TEMPERATURE DISPLAY
TEMPERATURE button
Temperature Setting
temperature can be adjusted between -16°C and - 24°C, proceeding as follows:
•
pressure of the button: the value changes cyclically between -16°C and -24°C.
ALARMS TABLE
Cause
The door has remained open for more than 2 minutes.
blinks.
The inside temperature is not adequate.
remains on.
30 min. elapsed since Party Mode function has been activated. It is time to take out
the bottle from the freezer (see Instructions for Use for more details).
blinks and the Temperature display Prolonged power failure, able to cause the inside temperature to increase to 0°C.
Product malfunction.
LV LT PL AR
This red LED can blink to show the occurrence of an
alarm or a failure even when the door is closed. Please
open the door and check on the internal Control Panel
which alarm/failure is occurring.
ECO NIGHT indicator
BLACK OUT ALARM
Long Black-out Alarm indicator.
(see the Instructions for Use)
button
Press to activate/deactivate the Eco Night function.
The Eco Night function enables appliance energy
consumption to be concentrated in the reduced rate
ALARM indicator (see the below Alarms Table)
STOP ALARM/FAST FREEZE button
Stop Alarm
Press in case of alarm.
Fast Freeze
Press for 3 seconds to activate the Fast Freeze function
(see the Instructions for Use).
The function switches o automatically after about 50
hours.
Cure
Close the door or press the Stop Alarm to mute the acoustical alarm.
Press the Stop Alarm button ; the acoustical alarm stops, the Temperature Display (°C)
blinks and the Alarm Indicator remains on until a temperature < -10°C is reached.
Press the Party Mode button or alternatively Stop Alarm button to deactivate the Party Mode
alarm - and remove the bottle from the freezer.
Press the Stop Alarm button ; the acoustical alarm stops, the Temperature Display (°C)
blinks and the Alarm Indicator remains on until a temperature < -10°C is reached.
Contact the After-sales Service.
