Toshiba Satellite A505-S6999 Specifications

Satellite A505 Detailed Product Specification
Model Name A505-S6999
:
C1 2
Operating System
 Genuine Windows
®
7 Home Premium 64-bit
3
Processor and Graphics
 Intel
®
Core™ 2 Duo processor P7450
2.13GHz, 3MB L2 Cache, 1066MHz FSB
o
 Mobile Intel
®
GM45 Express Chipset
 NVIDIA
® ®
GeForce GT 230M with 1GB GDDR3 discrete graphics
memory plus up to 2814MB dynamically allocated shared graphics
®
memory using NVIDIA TurboCache™ technology.
Total Available Graphics memory 3838MB
o
5
Memory
 Configured with 6GB DDR3 1066MHz (max 8GB)
6
Storage Drive
 64GB Serial ATA solid state drive
 500GB (5400 RPM) Serial ATA hard disk drive
Fixed Optical Disk Drive
 Blu-ray Disc™ ROM and DVD SuperMulti drive with Labelflash
supporting 16 formats
Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
o
CD-RW (24x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (8x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (6x)), DVD+RW (8x), DVD-
RAM (5x), BD-ROM (6x), BD-R (6x), BD-R (Double Layer, (4x)),
BD-RE (4x), BD-RE (Double Layer, (4x))
®
o Use Labelflash media to burn high quality labels directly to disc
8
Display
 16.0" diagonal widescreen TruBrite
native resolution (HD)
o Native support for 720p content
o Edge-to-Edge display
Sound
 Built-in harman/kardon
®
stereo speakers
Input Devices
 104 key US LED backlit keyboard with 10-key
 TouchPad™ pointing device with multi-touch control
 TouchPad™ Enable/Disable button
 Media Control Buttons:
o eco utility button (Energy-saving mode)
o Mute
o Media
o CD/DVD control buttons
o Volume up, volume down
Communications
 Webcam and microphone
 Modem
9
 10/100 Ethernet
 Realtek ®
802.11b/g/n wireless LAN
 Bluetooth ®
version 2.1 plus Enhanced Data Rate (EDR)
Expandability
 2 main memory slots. Both slots may be occupied.
 ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)
 Memory Card Reader
Secure Digital, Secure Digital High Capacity, Memory Stick™,
o
Memory Stick PRO™, Multi Media Card, xD Picture Card
[shared slot]
Ports
 Video
RGB (monitor) output port
o
HDMI-CEC
o
Part Number: PSAT3U-00V002
4
7
®
TFT LCD display at 1366x768
10
© Copyright 2009 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
1
 Audio
S/P DIF output port (shared with headphone port)
o
Microphone input port
o
Headphone output port
o
 Data
i.LINK™ IEEE-1394
o
4 USB v2.0 ports
o
RJ-45 LAN port
o
RJ-11 modem port
o
 Security
Slot for Security Lock
o
Physical Description
 Fusion™ Finish with Sonic Pattern in Black Onyx
 Dimensions (W x D x H ): 15.1" x 10.2" x 1.51"/1.69"
 Weight: Starting at 7.17 lbs., depending upon configuration
13
®
Battery
 9000 mAh (12 cell) Lithium Ion battery pack
Power Supply
 90W (19V x 4.74A) Auto-sensing ,100-240V/50-60Hz AC Adapter
 Dimensions (W x D x H): 5.2" x 2.3" x 1.2"
 Weight: starting at .81 lbs.
C1
Software
 Toshiba Software and Utilities
Electronic User's Guide
o
Bluetooth Stack for Windows by Toshiba
o
TOSHIBA Recovery Media Creator
o
TOSHIBA ConfigFree
o
TOSHIBA Disc Creator
o
TOSHIBA DVD Player
o
TOSHIBA Power-saving eco utility
o
TOSHIBA Hard Drive Impact Sensor (3D sensor)
o
TOSHIBA Face Recognition
o
TOSHIBA PC Health Monitor
o
Hard Disc Drive (HDD) Recovery
o
 Third-party Software
Microsoft
o
Microsoft
o
Internet Explorer 8
o
Adobe
o
Google™ Toolbar
o
Dolby
o
Corel
o
®
Sun
o
WildTangent
o
 Trial Software
Norton Internet Security™ 2009, 30-day trial
o
Microsoft
o
 Special Offers
Toshiba Online Backup
o
NetZero
o
Skype
o
Intuit
o
Environmental Specifications
 This product is RoHS
 Energy Star 5.0 Qualified
 EPEAT™ Gold Compliant
Satellite A505-S6999
UPC: 883974309801
o 3 x USB v2.0 ports
o 1 x eSATA/USB combo port with USB Sleep and
11
Charge
14
®
®
Windows Media Player
®
Works 9
® ®
Acrobat Reader
® ®
Sound Room
® ®
DVD MovieFactory for TOSHIBA
Java™ 2 Runtime Environment
®
Orb™ Game Console
®
Office Home and Student 2007 Edition, 60-day trial
®
Internet Service
®
® ®
Quickbooks Financial Center
15
compatible
12
Page 1 of 4
