Toshiba Satellite A45-S250 Specifications

TOSHIBA
Satellite® A45 Series
Feature Model(s):
Satellite A45-S250
P4 2800, 15.0" XGA, 512MB, 60GB, DVD+-R/+-RW, Mdm, LAN, Wi-Fi, WinXP Home
Satellite A45-S2501
P4 2800, 15.0" XGA, 512MB, 60GB, DVD+-R/+-RW, Mdm, LAN, Wi-Fi, WinXP Pro

Product Highlights

Performance
•
Mobile Intel® Pentium® 4 processor 2.80GHz
•
512MB of Main Memory (Expandable to 2048MB)
Great Features
•
60GB* hard disk drives
•
DVD+-R/+-RW drive
•
15.0" TFT active-matrix screen display
Get On-Line
•
Integrated V.92/56K modem
•
Integrated 10/100 Ethernet LAN
•
Integrated Wireless LAN (802.11g)
System Characteristics
CPU (See CPU Performance Disclaimer)**
•
Mobile Intel® Pentium® 4 processor 2.80GHz**
L2 Cache
•
512KB Level 2 cache memory integrated on die
•
533MHz Processor System Bus Clock Speed
Memory
•
512MB (2 DIMM) expandable to 2048MB (Both slots may be
occupied)
•
Expansion memory: 128MB/256MB/512/1028MB, SODIMM,
PC2100 DDR266
•
Data/Address Bus Width: 64bit/32bit
•
Intel® 852GME Chipset
Mass Storage/Optical Drive
•
Primary Hard Disk Drive: 60GB* hard disk drive, Enhanced IDE
(ATA-5) interface, 4200rpm drive rotation; 9.5mm height, 0.2lbs,
Service Removable
•
DVD+-R/+-RW Drive: Enhanced IDE (ATAPI) Interface;
Maximum speed: DVD-R (2x), DVD-RW (2x),
DVD+RW (2.4x), CD-R (16x), CD-RW (10x), CD-ROM (24x), DVD-
ROM (8x) Compatibility: CD-R (read/write), CD-RW (read/re-
write),CD+R (read/write), CD+RW (read/re-write), CD-
DVD-ROM, DVD-R (read/write), DVD-RW (read/write), DVD+R
(read/write), DVD+RW (read/write), Service removable
•
Software Decoder: InterVideo (Win-DVD 4®) w/SRS Technology
Graphics/Video
•
15.0" TFT active-matrix display****; internal display supports up to
16M colors at 1024 x 768
•
Intel® 852GME Integrated graphics controller; 32MB external DDR
SDRAM (UMA)
•
Direct 3D support and DirectVideo
•
External Color Support/Refresh rate:
•
640 x 480: 60/75/85/100Hz Non-Interlaced @16M colors
800 x 600; 60/75/85/100Hz Non-Interlaced @16M colors
1024 x 768; 60/75/85/100Hz Non-Interlaced @16M colors
1280 x 1024; 60/75/85/100Hz Non-Interlaced @16M colors
1600 x 1200; 60/75/85Hz Non-Interlaced @16M colors
1920 x 1440; 60/Hz Non-Interlaced @16M colors
Input Devices
•
Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key
stroke, 6mm height; Dedicated Windows® keys support; HotKey
function; TouchPad pointing device
•
CD Control Function: Play/Pause, Stop/Eject, Previous,
Skip/Next (Only works when system is turned on)
Expandability
•
2 Memory slots – Both slots may be occupied
•
1 PC Card slot support 1 Type II PC Card
Communications
•
Integrated V.92/56K modem; Data and fax support
Due to FCC limitations, speeds of 53kbps are the maximum permissible
transmission rates during Download. Actual data transmission speeds will
vary depending on line conditions.
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without
notice. Copyright 2003 TAIS satellite_A45-S250 v.1.3 060704 Created on 6/7/2004 3:57 PM
•
•
Ports
•
•
•
•
•
•
•
•
Physical Description
•
•
•
Sound
•
•
•
Power Supply
•
•
•
DVD+R (2.4x),
•
•
ROM,
•
Security
•
Bios
•
Operating System
•
•
Additional Software
•
•
•
•
•
•
•
•
Part Numbers
PSA40U-0C1ZRV
PSA40U-0C1ZR6
Integrated 10/100 Ethernet LAN
Integrated Wireless LAN (Atheros 802.11g)
ECP parallel printer port
RGB (monitor) port
4 Universal Serial Bus ports (USB)
TV-Out Port
RJ-45 LAN Port
RJ-11 modem port
SD (Secure Digital) Port
i.Link (IEEE 1394) Port
Dimensions (LxWxH): 13.2" x 11.7" x 1.9"
Weight: 7.7lbs
LED Indicators: Power, Power Save Mode, HDD, CD/DVD-ROM,
DC-IN, Caps Lock, Arrow, Numeric, Main Battery Charging Status,
System Sleep / Suspend status, Wireless Communication switch
Analog Devices AD1981B Codec Chip; Software Sound
Built-in stereo speakers; Sound Volume (by dial), Direct 3D Sound
(supported by driver), DirectSound (supported by driver) and
DirectMusic (supported by driver); MIDI Support; Sound Volume
(by Dial); Full Duplex Support
Ports: External Microphone port, headphone port
AC Adapter: 120W external AC Adapter, 100-240V / 50-60Hz
frequency (Universal) input voltage,
Dimensions (LxWxH): 5.7" x 1.7" x 2.1"
Weight: 1.4lbs
Battery Pack: 12-cell, rechargeable, removable Lithium Ion (Li-
Ion) battery, 8400mAh
Dimensions (LxWxH): 8.1" x 3.6" x 0.9"
Battery Saver (in Windows XP): Stand by, HDD Auto Off, Display
Auto Off, Throttling, Hibernation
Battery life (main batt): 4.2H***
Recharge time (main off/on): Approx 7-20H(on)/ 3.5H(off)
Battery life may vary depending on applications, power
management settings and features utilized. Recharge time varies
depending on usage. Battery may not charge while computer is
consuming full power. After a period of time, the battery will lose
its ability to perform at maximum capacity and will need to be
replaced. This is normal for all batteries. To purchase a new
battery pack or see information on accessories shipping with your
computer, visit the Toshiba website at
www.accessories.toshiba.com
Slot for computer lock, HDD (3 screws) and memory (3 screws),
User Power-on password, Setup Security (by help of SVPW
utility),HDD Password (By help of HDD password setup utility),
Keyboard Lock (by HotKey), Screen Blank (by Hotkey), Screen
Saver (by software)
TSETUP, APM, ACPI, PnP, VESA, DPMS, DDC, SM BIOS, PC
BIOS support
Microsoft® Windows XP Home pre-installed (A45-S250)
Microsoft® Windows XP Pro pre-installed (A45-S2501)
Microsoft® Works
Microsoft® Office OneNote™ 2003
ArcSoft ShowBiz® DVD Ver 1.3
InterVideo® Win-DVD Creator 2 Platinum
Drag'n Drop CD+DVD Software
Toshiba Notebook Maximizer
Intuit® Quicken® New User Edition 2003
Norton® AntiVirus™ 2003 – w/3-Month Subscription
Rev. 1.2 Page 1 of 3
15V x 8V Output.
