Toshiba Satellite A20-S207 Specifications

TOSHIBA
Satellite® A20 Series
Mobile Desktop Performance at a Value Price
Feature Model(s):
Satellite A20-S207
P4 2660/15.0"TFT/512MB/40GB/DVD-CDRW/Mdm/LAN/WiFi/WinXP Pro
Satellite A20-S208
P4 2660/15.0"TFT/512MB/40GB/DVD-CDRW/Mdm/LAN/WiFi/WinXP Home
Satellite A20 Small Business Series
P4 2660/15.0"TFT/512MB/40GB/DVD-CDRW/Mdm/LAN/WiFi/WinXP Pro/Office XP Professional
P4 2660/15.0"TFT/512MB/40GB/DVD-CDRW/Mdm/LAN/WiFi/WinXP Pro/Office XP Small Business

Product Highlights

Performance
•
Intel® Pentium® 4 2.66GHz processor
•
512MB of Main Memory
•
40GB* hard disk drive
Great Features
•
15.0" XGA TFT screen
•
DVD-ROM/CDRW multi-function drive
Get On-Line
•
Integrated V.92/56K modem
•
Integrated 10/100 Ethernet LAN
•
Integrated Wireless (802.11b) LAN
System Characteristics
CPU (See CPU Performance Disclaimer)**
•
Intel® Pentium® 4 2.66GHz processor**
•
Integrated co-processor
L2 Cache
•
512KB Level 2 Cache integrated on die
•
533MHz Processor System Bus Clock Speed
Memory
•
512MB (2 DIMM) DDR SDRAM (Expandable to 1024MB) (Both
slots may be occupied)
•
Expansion memory: 128MB/256MB/512/1024MB PC2100 DDR,
SODIMM, 2.5V
•
Data/Address Bus Width; 64-bit/32-bit
•
Ali M1672 + M1535 Chipset
Mass Storage
•
Primary Hard Disk Drive: 40GB* hard disk drive, Enhanced IDE
(ATA-5), 4200rpm, 9.7mm height, 0.2lbs, Service Removable
•
DVD-ROM/CDRW Multi-function drive: Max Speed: CD-
R(24x), CD-RW(10x), CD-ROM(24x), DVD-ROM(8x);
Compatibility: CD-ROM, CD-R(read/write), CD-RW(read/re-
write), DVD-ROM, DVD-R (read), DVD-RW(read); Service
removable
•
Software Decoder: InterVideo® (WinDVD™)
Graphics/Video
•
15.0" XGA TFT active-matrix display; internal display supports up
to 16M colors at 1024 x 768
•
Trident CyberBlade XP2 graphics processor; 32MB shared
video memory
External Color Support/Refresh rate:
640 x 480 60/75/85/100Hz Non-Interlaced@16M Colors
800 x 600 60/75/85/100Hz Non-Interlaced@16M Colors
1024 x 768 60/75/85/100Hz Non-Interlaced@16M Colors
1280 x 1024 60/75/85/100Hz Non-Interlaced@16M Colors
1600x 1200 60/75/85/100Hz Non-Interlaced@16M Colors
1920 x 1440
2048 x 1536
Input Devices
•
Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key
stroke, 6mm height; Dedicated Windows® & Application keys
support; HotKey function; TouchPad pointing device
•
CD Control Function: Play/Pause, Stop, Previous, Next, Mode
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without
notice. Copyright 2003 TAIS satellite_A20-S207.doc Created on 5/28/2003 1:08 PM
60/75Hz Non-Interlaced@16M Colors
60Hz Non-Interlaced@16M Colors
Part Numbers
PSA20U-02HKL7
PSA20U-02HKL3
PSA20U-02HLK7X
PSA20U-02HKL7W
Control Switch (CD/DVD)
Expandability
•
2 Memory slots (Both slots may be occupied)
•
PC Card slot supports 1 Type II (5mm)
Communications
•
Integrated V.92/56K modem; Data and fax support
Due to FCC limitations, speeds of 53kbps are the maximum permissible
transmission rates during Download. Actual data transmission speeds will
vary depending on line conditions.
•
Integrated 10/100 Ethernet LAN
•
Integrated Wireless (802.11b) LAN (Agere)
Ports
•
RGB (monitor) port
•
Parallel port
•
3 Universal Serial Bus port (2.0)
•
TV-Out (S-Video)
•
RJ-45 LAN port
•
RJ-11 modem port
•
Secure Digital® (SD) slot
Physical Description
•
Dimensions (LxWxH): 13.4" x 11.6" x 1.9"
•
Weight: 7.9lbs
•
LED Indicators: HDD, CD/DVD, DC-IN, Caps Lock, Arrow,
Numeric, Main Battery Charging Status, System Sleep / Suspend
status, Wireless Communication switch (left side), SD Card (right
side)
Sound
•
Analog Devices AD1981B Codec Chip, Software sound; 16-bit
stereo; Stereo Speakers
•
Direct 3D Sound (supported by sound driver); DirectSound and
DirectMusic (supported by sound driver); Full Duplex and MIDI
(play back) support, 32 voices
•
Sound Volume (by dial)
•
Ports: External Microphone port, headphone port, Line-in port
Power Supply
•
AC Adapter: 120W AC Adapter, 100-240V / 50-60Hz frequency
(Universal) input voltage, 15V x 8A Output.
Dimensions (LxWxH): 5.7" x 2.1" x 1.7"
Weight: 1.4lbs
•
Battery Pack: 12-cell, rechargeable, removable Lithium Ion
(Graphite) battery, 10.8V x 8400mAh
Dimension (LxWxH): 8.1" x 3.6" x 0.9"
Weight: 1.4lbs
•
Battery Saver (in Windows): Stand by, HDD Auto Off, Display
Auto Off, Hibernation
•
Battery life 3h18m***; Recharge time(Off/On): Approx
3.5H/3.5~12.5H+
Battery life may vary depending on applications, power management
settings and features utilized. Recharge time varies depending on
usage. Battery may not charge while computer is consuming full
power. After a period of time, the battery will lose its ability to perform
at maximum capacity and will need to be replaced. This is normal for
all batteries. To purchase a new battery pack, see your accessories
information that shipped with your computer or visit the Toshiba
website at www.accessories.toshiba.com
Rev. 1.4 Page 1 of 3
