Toshiba Satellite A15-S1292 Specifications

TOSHIBA
Satellite® A15 Series
Feature Model(s):
Satellite A15-S1292
Cel2400/14.1"XGA/256MB/30GB/DVD-CDRW/Mdm/LAN/WinXP Home

Product Highlights

Performance
•
Intel® Celeron® Processor at 2.40GHz
•
256MB of Main Memory (Expandable to 1024MB)
Great Features
•
30GB* hard disk drives
•
DVD-ROM/CDRW multi-function drive
•
14.1" TFT active-matrix screen display
Get On-Line
•
Integrated V.92/56K modem
•
Integrated 10/100 Ethernet LAN
System Characteristics
CPU (See CPU Performance Disclaimer)**
•
Intel® Celeron® processor at 2.40GHz**
L2 Cache
•
256KB Level 2 cache memory integrated on die
•
400MHz Processor System Bus Clock Speed
Memory
•
256MB (1 DIMM) expandable to 1024MB (Both slots may be
occupied)
•
Expansion memory: 128MB/256MB/512MB, SODIMM, PC2100
DDR SDRAM
•
Data/Address Bus Width: 64bit/32bit
•
Intel® 852GM Chipset
Mass Storage/Optical Drive
•
Primary Hard Disk Drive: 30GB* hard disk drives, Enhanced IDE
(ATA-5) interface, 4200rpm drive rotation; 9.5mm height, 0.2lbs,
Service Removable
•
DVD-ROM/CDRW Multi-function Drive: Enhanced IDE (ATAPI)
Interface; Maximum speed: CD-R(24x), CD-RW(10x), CD-
ROM(24x), DVD-ROM(8x); Compatibility: CD-ROM, CD-R
(read/write), CD-RW (read/re-write), DVD-ROM, DVD-R (read
only), DVD-RW (read only); Service removable
•
Software Decoder: InterVideo (WinDVD®)
Graphics/Video
•
14.1" TFT active-matrix display****; internal display supports up to
16M colors at 1024 x 768
•
Intel® 852GM Integrated graphics controller; 32MB internal shared
video memory
•
Direct 3D support and DirectVideo
•
External Color Support/Refresh rate:
•
640 x 480: 60/75/85/100Hz Non-Interlaced @16M
800 x 600; 60/75/85/100Hz Non-Interlaced @16M
1024 x 768; 60/75/85/100Hz Non-Interlaced @16M
1280 x 1024; 60/75/85/100Hz Non-Interlaced @16M
1600 x 1200; 60/75/85Hz Non-Interlaced @16M
1920 x 1440; 60/Hz Non-Interlaced @16M
Input Devices
Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key stroke,
6mm height; Dedicated Windows® keys support; HotKey function;
TouchPad pointing device
Expandability
•
2 Memory slots – Both slots may be occupied
•
1 PC Card slot support 1 Type II PC Card
Communications
•
Integrated V.92/56K modem; Data and fax support
Due to FCC limitations, speeds of 53kbps are the maximum permissible
transmission rates during Download. Actual data transmission speeds will
vary depending on line conditions.
•
Integrated 10/100 Ethernet LAN
Ports
•
ECP parallel printer port
•
RGB (monitor) port
•
2 Universal Serial Bus ports (USB)
•
RJ-45 LAN Port
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without
notice. Copyright 2003 TAIS satellite_A15-S1292.doc Created on 12/1/2003 9:42 AM
Part Numbers
•
RJ-11 modem port
Physical Description
•
Dimensions (LxWxH): 13.0" x 11.5" x 1.5"
•
Weight: 6.3lbs
•
LED Indicators: Power, Power Save Mode, HDD, CD/DVD-ROM,
DC-IN, Caps Lock, Arrow, Numeric, Main Battery Charging
Status, System Sleep / Suspend status, Wireless Communication
switch
Sound
•
Analog Devices AD1981 Codec Chip; Software Sound; Sound
Blaster Pro compatibility
•
Built-in stereo speakers; Direct 3D Sound, DirectSound (supported
by driver) and DirectMusic; MIDI Support; Sound Volume (by
Dial);
Ports: External Microphone port, headphone port
Power Supply
•
AC Adapter: 75W external AC Adapter, 100-240V / 50-60Hz
frequency (Universal) input voltage,
Dimensions (LxWxH): 5.3" x 2.0" x 1.1
Weight: 0.8lbs
•
Battery Pack: 6-cell, rechargeable, removable Lithium Ion (Li-Ion)
battery, 3600mAh
•
Battery Saver (in Windows XP): Stand by, HDD Auto Off, Display
Auto Off, Throttling, Hibernation
•
Battery life (main batt): 3:32H ***
•
Recharge time (main off/on): 2.6H/4-11H+
Battery life may vary depending on applications, power management
settings and features utilized. Recharge time varies depending on usage.
Battery may not charge while computer is consuming full power. After a
period of time, the battery will lose its ability to perform at maximum
capacity and will need to be replaced. This is normal for all batteries. To
purchase a new battery pack or see information on accessories shipping
with your computer, visit the Toshiba website at
www.accessories.toshiba.com
Security
•
Slot for computer lock, Main Battery Pack (sliding lock), HDD
(three screws) and memory (by screw only), User Power-on
password, Setup Security (by help of SVPW utility), CPU serial
No. security (By help of SVPW utility), Keyboard Lock (by
HotKey), Screen Blank (by Hotkey), Screen Saver (by software)
Bios
•
TSETUP, APM, ACPI, PnP, VESA, DPMS, DDC, SM BIOS, PC
BIOS support
Operating System
•
Microsoft® Windows XP Home pre-installed
•
Windows 2000 component drivers on the web
Additional Software
•
Microsoft® Works
•
Toshiba Notebook Maximizer
•
Intuit® Quicken® New User Edition 2003
•
Norton® AntiVirus™ 2003 – w/3 Month Subscription
•
AOL® (3 –Month offer)
AOL OFFER DETAILS: Availability may be limited, especially during peak
times. TO AVOID BEING CHARGED A MONTHLY
SIMPLY CANCEL BEFORE THE THREE-MONTH PROMOTIONAL
PERIOD ENDS. Premium services carry surcharges and communication
surcharges may apply, including AK, even during promotional period.
Members may incur telephone charges on their phone bill, depending on
their location and calling plan, even during promotional period. Available to
new AOL members in the United States, age 18 or older; a major credit card
or checking account is required.
•
Adobe® Acrobat Reader
•
AT&T® Worldnet® Service – 1 Month FREE
Telephone access and other charges and other terms and conditions may
apply. Offer available to new customers only. Offer
•
Microsoft Internet Explorer
•
Toshiba Custom Utilities
•
Toshiba Great Software
software titles. The software selection includes titles from the follow
Rev. 1.0a
15V x 4A Output.
MEMBERSHIP FEE,
expires 4/30/04.
Offer: Receive your choice of two
Page 1 of 3
