Toshiba Satellite A105-S2121 Specifications

Satellite A105-S2121 Detailed Product Specification
Model Name Description
A105-S2121 Microsoft® Windows® XP Home, Intel® Celeron® M Processor 410, 512MB DDR2,
60GB 5400rpm SATA, CD-RW/DVD-ROM, 15.4" TrueBrite™ (WXGA), ATI RADEON®
XPRESS 200M, Atheros® 802.11 b/g wireless-LAN, CD control buttons, 1 year limited
Warranty
2
Operating System
• Microsoft® Windows® XP Home Edition
• TOSHIBA Express Media Player
o Quick access for CD and DVD watching
3
Processor and Chipset
• Intel® Celeron® M Processor 410
o 1.46GHz, 1MB L2, 533MHz FSB
• ATI Radeon® Xpress 200M Chipset
4
Memory
• Configured with 512MB DDR2 SDRAM (both memory slots may be
occupied)
• 512MB(min)/2048MB (max), 2 memory slots using 256MB, 512MB
PC4200 DDR2 533MHz SDRAM, dual-channel support requires
two memory modules of same capacity and clockspeed
5
Hard Disk Drive
• 60GB (5400 RPM); Serial-ATA (SATA) hard disk drive; 9.5mm
height; user removable
6
Fixed Optical Disk Drive
• CD-RW/DVD-ROM
o Maximum speed and compatibility: CD-ROM (24x:read),
CD-R (24x:write), CD-RW (4x:write), DVD-ROM
(8x:read)
7
Display
• 15.4" diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1280x800 native resolution (WXGA)
8
Graphics
• ATI Radeon® Xpress 200M 64MB-128MB dynamically allocated
shared graphics memory
Sound
• Built-in stereo speakers
• SRS Labs audio enhancements
o SRS TruSurround XT® virtual surround sound
• Sound Volume Control Dial
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• Control Buttons:
o Internet button to launch default browser
o Express Media Player CD/DVD launch button
o CD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
This product specification is variable and subject to change prior to product launch.
9
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A105-S2121 BTO Rev. 1.0 2006-05-16 MCL T20060118 CB1.40
1
Communications
• Toshiba V.92 software modem
• 10BASE-T/100-TX Ethernet
• Atheros® 802.11b/g wireless-LAN
Expandability
• 2 main memory slots. Both slots may be occupied.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
o Universal Serial Bus (USB v2.0) – 4 ports
o RJ-45 LAN port
o RJ-11 modem port
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 14.2" (360.0mm) x 10.5"
(267mm) x 1.17" (29.8mm)[F]/1.45" (36.8mm)[R] without feet
• Weight: Starting at 6.0 lbs (2.72 kg) depending upon
12
configuration
• Indicators: Power, DC-IN, HDD, CD/DVD, CapsLock, ArrowMode,
NumericMode, Battery, Sleep/Suspend, Wireless
• Chassis Description
o Case material: PC+ASB Plastic
o LCD Cover Color: Mist Gray
• Physical Security
o Slot for cable lock; Yes
o Items protected by a screw: Memory, Main HDD, Built in
Modem/Lan
• Software Security
o Passwords: User power-on password, supervisor
password
o Hotkey locks: Screen Blank
Power Supply
• 65W (19V 3.42A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
• Dimensions (WxDxH): 4.25" (108mm) x 1.85" (47mm) x 1.34"
(34.0mm)
• Weight: starting at .55 lbs (250 g)
13
Battery
• 4-cell (2000mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
• Dimensions (WxDxH): 8.15" (207mm) x 0.91" (23mm) x 2.13"
(54mm)
• Weight: starting at 0.60 lbs (270 g)
• Battery Life (measured by MobileMark™)
o Included 4-cell battery: 1 hours, 43 minutes
Part Number UPC
PSAA5U-01900P 032017598980
