- Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL FZ8-S FZ8-SA 42P-28199-E4...
- Page 2 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold. YAMAHA MOTOR ELECTRONICS CO., LTD. 1450-6, Mori, Mori-machi, Shuchi-gun, Shizuoka-ken, 437-0292 Japan DECLARATION of CONFORMITY Company: YAMAHA MOTOR ELECTRONICS CO., LTD. Address: 1450-6, Mori, Mori-Machi, Shuchi-gun, Shizuoka-Ken, 437-0292 Japan Hereby declare that the product: Kind of equipment: IMMOBILIZER...
- Page 3 EAU10103 Welcome to the Yamaha world of motorcycling! As the owner of the FZ8-S/FZ8-SA, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
- Page 4 IMPORTANT MANUAL INFORMATION EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
- Page 5 IMPORTANT MANUAL INFORMATION EAU10201 FZ8-S/FZ8-SA OWNER’S MANUAL ©2014 by Yamaha Motor Co., Ltd. 1st edition, July 2014 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.
-
Page 6: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION ....1-1 Luggage strap holders ....3-24 Checking the throttle grip free Sidestand ........3-24 play..........6-19 DESCRIPTION ........2-1 Ignition circuit cut-off system ..3-25 Valve clearance......6-19 Left view ......... 2-1 Tires ..........6-20 Right view........2-3 FOR YOUR SAFETY –... - Page 7 TABLE OF CONTENTS Replacing the fuses.......6-34 Replacing a headlight bulb....6-37 Replacing an auxiliary light bulb..6-38 Replacing the tail/brake light bulb ..........6-38 Replacing a turn signal light bulb ..........6-39 Replacing the license plate light bulb ..........6-39 Supporting the motorcycle....6-40 Front wheel (for non-ABS models)....6-41 Rear wheel (for non-ABS models)....6-42...
-
Page 8: Safety Information
SAFETY INFORMATION Never operate a motorcycle with- pears to be very effective in reduc- EAU1028B out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor. - Page 9 SAFETY INFORMATION Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- ...
- Page 10 SAFETY INFORMATION Do not run engine outdoors where Avoid Carbon Monoxide Poisoning When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind: Cargo and accessory weight monoxide, a deadly gas.
- Page 11 Yamaha accessories, which are avail- performed to your vehicle that change lightweight as possible and able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...
- Page 12 SAFETY INFORMATION Check that the fuel cock (if operator and may limit control ability, therefore, such accesso- equipped) is in the “OFF” position ries are not recommended. and that there are no fuel leaks. Use caution when adding electri- ...
-
Page 13: Description
DESCRIPTION EAU32221 Left view (FZ8-S) 11 10 9 1. Front fork spring preload adjusting bolt (page 3-20) 8. Shock absorber assembly spring preload adjusting ring (page 3-22) 2. Air filter element (page 6-16) 9. Shock absorber assembly rebound damping force adjusting screw (page 3-22) 3. - Page 14 DESCRIPTION (FZ8-SA) 11 10 9 1. Front fork spring preload adjusting bolt (page 3-20) 10.Shift pedal (page 3-13) 2. Air filter element (page 6-16) 11.Idle adjusting screw (page 6-18) 3. Seat lock (page 3-18) 12.Engine oil drain bolt (page 6-11) 4.
-
Page 15: Right View
DESCRIPTION EAU32231 Right view (FZ8-S) 1. Luggage strap holder (page 3-24) 8. Front fork spring preload adjusting bolt (page 3-20) 2. Fuse box (page 6-34) 9. Front fork compression damping force adjusting screw (page 3-20) 3. Battery (page 6-33) 10.Engine oil level check window (page 6-11) 4. - Page 16 DESCRIPTION (FZ8-SA) 1. Luggage strap holder (page 3-24) 10.Brake pedal (page 3-14) 2. Fuse box (page 6-34) 11.Battery (page 6-33) 3. Rear brake fluid reservoir (page 6-25) 4. Coolant reservoir (page 6-14) 5. Engine oil filler cap (page 6-11) 6. Front fork rebound damping force adjusting screw (page 3-20) 7.
-
Page 17: Controls And Instruments
DESCRIPTION EAU10431 Controls and instruments 1. Clutch lever (page 3-13) 2. Left handlebar switches (page 3-11) 3. Main switch/steering lock (page 3-2) 4. Multi-function meter unit (page 3-8) 5. Front brake fluid reservoir (page 6-25) 6. Right handlebar switches (page 3-11) 7. -
Page 18: Instrument And Control Functions
Do not expose any key to exces- cess, take the vehicle along with all three keys to a Yamaha dealer to have sively high temperatures. Do not place any key close to them re-registered. Do not use the key with the red bow for driving. -
Page 19: Main Switch/Steering Lock
INSTRUMENT AND CONTROL FUNCTIONS Keep other immobilizer system EAU10473 EAU36871 Main switch/steering lock keys away from the main switch All electrical circuits are supplied with as they may cause signal inter- power, the meter lighting, taillight, li- ference. cense plate light and auxiliary lights come on, and the engine can be start- ed. - Page 20 INSTRUMENT AND CONTROL FUNCTIONS To unlock the steering EAU10685 ECA11021 LOCK NOTICE The steering is locked, and all electrical Do not use the parking position for systems are off. The key can be re- an extended length of time, other- moved.
-
Page 21: Indicator Lights And Warning Lights
2.5 seconds. If this occurs, 4. High beam indicator light “ ” to “ON”. The warning light should have a Yamaha dealer check the 5. Engine trouble warning light “ ” come on for a few seconds, and then vehicle. - Page 22 If the warning light does not come on initially when the key is turned to “ON”, or if the warning light remains on, have a Yamaha dealer check the electrical circuit. ECA10022 NOTICE Do not continue to operate the en- gine if it is overheating.
- Page 23 INSTRUMENT AND CONTROL FUNCTIONS Display Conditions What to do Under 40 °C Message “Lo” is displayed. OK. Go ahead with riding. (Under 104 °F) 40–116 °C Coolant temperature is dis- OK. Go ahead with riding. (104–242 °F) played. Reduce the load on the engine by riding Coolant temperature flash- at a moderate pace, at low rpm, until 117–134 °C...
- Page 24 If this oc- light will come on, but this is not a mal- The ABS may not work correctly. If any curs, have a Yamaha dealer check the function. of the above occurs, have a Yamaha self-diagnosis system.
-
Page 25: Multi-Function Meter Unit
INSTRUMENT AND CONTROL FUNCTIONS multi-function meter unit Speedometer EAU46767 Multi-function meter unit equipped with the following: The speedometer shows the vehicle’s a speedometer traveling speed. a tachometer an odometer Tachometer two tripmeters (which show the distance traveled since they were last set to zero) ... - Page 26 INSTRUMENT AND CONTROL FUNCTIONS Red zone: 11500 r/min and above 4. Push the “SELECT” button, and odometer display will automatically the minute digits will start flashing. change to the fuel reserve tripmeter 5. Push the “RESET” button to set mode “F-TRIP” and start counting the Clock the minutes.
- Page 27 INSTRUMENT AND CONTROL FUNCTIONS Fuel meter times, then go off for approximately 3 Self-diagnosis device seconds. If this occurs, have a Yamaha dealer check the electrical circuit. Coolant temperature display 1. Fuel meter 1. Error code display 2. Immobilizer system indicator light The fuel meter indicates the amount of 3.
-
Page 28: Handlebar Switches
If a problem is detected in the immobi- key and both standard keys to a EAU1234H Handlebar switches lizer system circuits, the immobilizer Yamaha dealer and have the stan- system indicator light will flash and the dard keys re-registered. Left display will indicate an error code. - Page 29 INSTRUMENT AND CONTROL FUNCTIONS Right ter position. To cancel the turn signal EAU12735 Hazard switch “ ” lights, push the switch in after it has re- With the key in the “ON” or “ ” posi- turned to the center position. tion, use this switch to turn on the haz- ard lights (simultaneous flashing of all EAU12501...
-
Page 30: Clutch Lever
INSTRUMENT AND CONTROL FUNCTIONS EAU12821 EAU12872 EAU26825 Clutch lever Shift pedal Brake lever The brake lever is located on the right side of the handlebar. To apply the front brake, pull the lever toward the throttle grip. 1. Clutch lever 1. -
Page 31: Brake Pedal
EAU51802 Brake pedal ABS (for ABS models) The ABS performs a self-diagno- The Yamaha ABS (Anti-lock Brake sis test each time the vehicle first System) features a dual electronic con- starts off after the key is turned to trol system, which acts on the front and “ON”... -
Page 32: Fuel Tank Cap
INSTRUMENT AND CONTROL FUNCTIONS wheel hubs may be damaged, re- EAU13075 Fuel tank cap sulting in improper performance of The fuel tank cap cannot be closed un- the ABS system. less the key is in the lock. In addition, the key cannot be removed if the cap is not properly closed and locked. -
Page 33: Fuel
WARNING pump nozzle into the fuel tank filler Gasoline is poisonous and can Your Yamaha engine has been de- hole. Stop filling when the fuel cause injury or death. Handle gaso- signed to use regular unleaded gaso- reaches the bottom of the filler line with care. -
Page 34: Fuel Tank Breather Hose And Overflow Hose
10% (E10). Gas- Do not park the vehicle near ohol containing methanol is possible fire hazards such as recommended by Yamaha because it grass or other materials that can cause damage to the fuel system easily burn. or vehicle performance problems. -
Page 35: Seats
INSTRUMENT AND CONTROL FUNCTIONS To install the passenger seat ECA10702 EAU49644 Seats NOTICE 1. Insert the projections on the front Use only unleaded gasoline. The use of the passenger seat into the seat Passenger seat of leaded gasoline will cause unre- holders as shown, and then push pairable damage to the catalytic the rear of the seat down to lock it... -
Page 36: Storage Compartment
INSTRUMENT AND CONTROL FUNCTIONS EAU14465 Storage compartment Make sure that the seats are properly secured before riding. 1. Bolt 1. Storage compartment To install the rider seat Insert the projection on the front of the The storage compartment is located rider seat into the seat holder as under the passenger seat. -
Page 37: Rear View Mirrors
INSTRUMENT AND CONTROL FUNCTIONS Do not exceed the maximum EAU39672 EAU55261 Rear view mirrors Adjusting the front fork load of FZ8-S 195 kg (430 lb) The rear view mirrors of this vehicle EWA14671 FZ8-SA 190 kg (419 lb) for the WARNING can be folded forward or backward for vehicle. - Page 38 INSTRUMENT AND CONTROL FUNCTIONS Spring preload setting: Rebound damping setting: Minimum (soft): Minimum (soft): Distance A = 14.0 mm (0.55 in) 11 click(s) in direction (b)* Standard: Standard: Distance A = 11.0 mm (0.43 in) 8 click(s) in direction (b)* Maximum (hard): Maximum (hard): Distance A = 4.0 mm (0.16 in)
-
Page 39: Adjusting The Shock Absorber Assembly
INSTRUMENT AND CONTROL FUNCTIONS justment, it would be advisable to EAU39346 Adjusting the shock absorber check the number of clicks of each assembly damping force adjusting mechanism This shock absorber assembly is and to modify the specifications as equipped with a spring preload adjust- necessary. - Page 40 INSTRUMENT AND CONTROL FUNCTIONS Rebound damping force To increase the rebound damping To obtain a precise adjustment, it is force and thereby harden the rebound advisable to check the actual total damping, turn the adjusting screw in number of clicks or turns of the damp- direction (a).
-
Page 41: Luggage Strap Holders
The sidestand is located on the left sembly yourself. Take the shock side of the frame. Raise the sidestand absorber assembly to a Yamaha or lower it with your foot while holding dealer for any service. the vehicle upright. -
Page 42: Ignition Circuit Cut-Off System
INSTRUMENT AND CONTROL FUNCTIONS this system regularly and have a EAU44893 Ignition circuit cut-off system Yamaha dealer repair it if it does not The ignition circuit cut-off system function properly. (comprising the sidestand switch, clutch switch and neutral switch) has the following functions. - Page 43 INSTRUMENT AND CONTROL FUNCTIONS WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.
-
Page 44: For Your Safety - Pre-Operation Checks
• If necessary, add recommended coolant to specified level. 6-14 Coolant • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary. 6-24, 6-25 •... - Page 45 • Make sure that operation is smooth. • Check throttle grip free play. 6-19, 6-29 Throttle grip • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 6-29 •...
- Page 46 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 3-24 • If system is not working correctly, have Yamaha dealer check vehicle.
-
Page 47: Operation And Important Riding Points
a lean angle sensor to stop the en- The transmission is in the neutral understand, ask your Yamaha dealer. gine in case of a turnover. In this EWA10272 position. -
Page 48: Shifting
The gear positions are shown in the il- neutral position. The neutral indi- lustration. cator light should come on. If not, ask a Yamaha dealer to check the To shift the transmission into the neu- electrical circuit. tral position, press the shift pedal down 3. -
Page 49: Tips For Reducing Fuel Consumption
OPERATION AND IMPORTANT RIDING POINTS ECA10261 EAU16811 EAU16842 Tips for reducing fuel con- Engine break-in NOTICE sumption There is never a more important period Even with the transmission in in the life of your engine than the period Fuel consumption depends largely on the neutral position, do not between 0 and 1600 km (1000 mi). -
Page 50: Parking
Yamaha dealer check the vehi- touch them and be burned. cle. Do not park on a slope or on soft... - Page 51 To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.
-
Page 52: Owner's Tool Kit
If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you. -
Page 53: Periodic Maintenance Chart For The Emission Control System
From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi). Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and tech- nical skills. -
Page 54: General Maintenance And Lubrication Chart
PERIODIC MAINTENANCE AND ADJUSTMENT EAU1770K General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ Air filter element •... - Page 55 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check chain slack, alignment and condition. Every 1000 km (600 mi) and after washing the motorcycle, riding in the rain or Drive chain •...
- Page 56 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Rear suspension re- lay arm and con- √...
- Page 57 PERIODIC MAINTENANCE AND ADJUSTMENT EAU18681 Air filter • This model’s air filter is equipped with a disposable oil-coated paper element, which must not be cleaned with com- pressed air to avoid damaging it. • The air filter element needs to be replaced more frequently when riding in unusually wet or dusty areas. ...
-
Page 58: Removing And Installing The Cowling And Panels
PERIODIC MAINTENANCE AND ADJUSTMENT EAU18724 Removing and installing the cowling and panels The cowling and panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time the cowling or a panel needs to be re- moved and installed. - Page 59 PERIODIC MAINTENANCE AND ADJUSTMENT Panel C EAU56160 To remove the panel Panels A and B Remove the bolt, and then pull the panel off as shown. To remove a panel Remove the quick fastener and the bolts, and then pull the panel off as shown.
-
Page 60: Checking The Spark Plugs
Before installing a spark plug, the checked periodically, preferably by a spark plug gap should be measured Yamaha dealer. Since heat and depos- with a wire thickness gauge and, if its will cause any spark plug to slowly necessary, adjusted to specification. -
Page 61: Engine Oil And Oil Filter Cartridge
PERIODIC MAINTENANCE AND ADJUSTMENT FZ8-S EAU49793 Engine oil and oil filter car- If a torque wrench is not available tridge when installing a spark plug, a good The engine oil level should be checked estimate of the correct torque is 1/4– before each ride. - Page 62 5. Remove the engine oil filler cap, the engine oil drain bolt and its gasket to drain the oil from the crankcase. 1. Oil filter wrench 2. Oil filter cartridge An oil filter wrench is available at a Yamaha dealer. 6-12...
- Page 63 PERIODIC MAINTENANCE AND ADJUSTMENT 7. Apply a thin coat of clean engine FZ8-S 9. Install the engine oil drain bolt and oil to the O-ring of the new oil filter its new gasket, and then tighten cartridge. the bolt to the specified torque. Tightening torque: Engine oil drain bolt: 43 Nm (4.3 m·kgf, 31 ft·lbf)
-
Page 64: Coolant
Do off and have a Yamaha dealer check and lubrication chart. not use oils with a diesel speci- the vehicle. fication of “CD” or oils of a high- 12. - Page 65 Have a be protected against frost and Yamaha dealer change the coolant. corrosion. If water has been WARNING! Never attempt to remove added to the coolant, have a...
-
Page 66: Replacing The Air Filter Element
PERIODIC MAINTENANCE AND ADJUSTMENT 4. Remove the fuel tank cowling EAU49852 Replacing the air filter ele- bolts on both sides after pulling ment out slightly on the edge of the side The air filter element should be re- cowlings to access the bolts. placed at the intervals specified in the periodic maintenance and lubrication chart. - Page 67 If any fuel hose is damaged, do not start the engine but have a Yamaha dealer replace the hose, other- wise fuel may leak, creating a fire hazard.
-
Page 68: Adjusting The Engine Idling Speed
PERIODIC MAINTENANCE AND ADJUSTMENT 15. Install the side cowling bolt on EAU34302 Adjusting the engine idling both sides. speed 16. Install the panels. The engine idling speed must be 17. Install the rider seat. checked and, if necessary, adjusted as follows at the intervals specified in the periodic maintenance and lubrication chart. -
Page 69: Checking The Throttle Grip Free Play
If the specified idling speed cannot be from occurring, the valve clearance obtained as described above, have a must be adjusted by a Yamaha dealer Yamaha dealer make the adjustment. at the intervals specified in the periodic maintenance and lubrication chart. -
Page 70: Tires
250 kPa (2.50 kgf/cm², 36 psi) or glass fragments in it, or if the side- Rear: Operation of this vehicle with im- wall is cracked, have a Yamaha dealer 290 kPa (2.90 kgf/cm², 42 psi) proper tire pressure may cause se- replace the tire immediately. - Page 71 Tire information characteristics of the motorcy- EWA10472 WARNING cle may be different, which Have a Yamaha dealer replace could lead to an accident. Always make sure that the valve excessively worn tires. Besides being illegal, operating the vehi-...
-
Page 72: Cast Wheels
If any damage is found, have high speeds. a Yamaha dealer replace the Brand-new tires can have a rel- wheel. Do not attempt even the atively poor grip on certain road smallest repair to the wheel. -
Page 73: Checking The Brake Lever Free Play
Yamaha dealer check the internal clutch mechanism. 1. No brake lever free play There should be no free play at the brake lever end. If there is free play, have a Yamaha dealer inspect the brake system. -
Page 74: Brake Light Switches
EAU36891 takes effect. If necessary, have a Front brake pads Yamaha dealer adjust the brake light switches. 1. Rear brake light switch 2. Rear brake light switch adjusting nut The brake light, which is activated by... -
Page 75: Checking The Brake Fluid Level
Rear brake (FZ8-S) EAU51713 Checking the brake fluid level Yamaha dealer replace the brake pads Before riding, check that the brake fluid as a set. is above the minimum level mark. Check the brake fluid level with the top... -
Page 76: Changing The Brake Fluid
Changing the brake fluid does not enter the brake fluid The rear brake fluid reservoir is located Have a Yamaha dealer change the reservoir when refilling. Water under the rider seat. (See page 3-18.) brake fluid at the intervals specified in... -
Page 77: Drive Chain Slack
2. Shift the transmission into the To adjust the drive chain slack rection (a). To loosen the drive neutral position. Consult a Yamaha dealer before ad- chain, turn the adjusting bolt on 3. Measure the drive chain slack as justing the drive chain slack. -
Page 78: Cleaning And Lubricating The Drive Chain
PERIODIC MAINTENANCE AND ADJUSTMENT 3. Tighten the axle nut, then the lock- EAU23026 Cleaning and lubricating the nuts to their specified torques. drive chain The drive chain must be cleaned and Tightening torques: Axle nut: lubricated at the intervals specified in 150 Nm (15 m·kgf, 108 ft·lbf) the periodic maintenance and lubrica- Locknut:... -
Page 79: Checking And Lubricating The Cables
Yamaha dealer at the intervals cated if necessary. If a cable is specified in the periodic maintenance damaged or does not move smoothly, chart. -
Page 80: Checking And Lubricating The Brake And Shift Pedals
PERIODIC MAINTENANCE AND ADJUSTMENT EAU44275 EAU23144 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease brake and shift pedals brake and clutch levers The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each ride, and the pedal pivots should be lu-... -
Page 81: Checking And Lubricating The Sidestand
WARNING push down hard on the handle- If the sidestand does not move up bars several times to check if the and down smoothly, have a Yamaha front fork compresses and re- dealer check or repair it. Otherwise, bounds smoothly. -
Page 82: Checking The Steering
If any damage is found or the front the vehicle so there is no danger fork does not operate smoothly, of it falling over. have a Yamaha dealer check or re- [EWA10752] 2. Hold the lower ends of the front pair it. -
Page 83: Checking The Wheel Bearings
EWA10761 WARNING To charge the battery Electrolyte is poisonous and Have a Yamaha dealer charge the bat- dangerous since it contains sul- tery as soon as possible if it seems to furic acid, which causes severe have discharged. Keep in mind that the... -
Page 84: Replacing The Fuses
PERIODIC MAINTENANCE AND ADJUSTMENT battery tends to discharge more quick- is turned to “OFF”, then connect EAU49825 Replacing the fuses ly if the vehicle is equipped with op- the positive lead before con- The main fuse, the fuel injection sys- tional electrical accessories. - Page 85 PERIODIC MAINTENANCE AND ADJUSTMENT FZ8-S FZ8-SA FZ8-SA 2 3 4 5 6 2 3 4 5 6 1. Ignition fuse 1. Fuse box 1. Ignition fuse 2. Signaling system fuse 2. Fuel injection system fuse 2. Signaling system fuse 3. Taillight fuse 3.
- Page 86 [EWA15132] 4. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 6-36...
-
Page 87: Replacing A Headlight Bulb
4. Install the headlight bulb cover, oughly clean off any dirt and fin- and then connect the coupler. gerprints on the headlight bulb 5. Have a Yamaha dealer adjust the using a cloth moistened with al- headlight beam if necessary. cohol or thinner. -
Page 88: Replacing An Auxiliary Light Bulb
PERIODIC MAINTENANCE AND ADJUSTMENT EAU32835 EAU24116 Replacing an auxiliary light Replacing the tail/brake light bulb bulb This model is equipped with two auxil- 1. Remove the passenger seat. (See iary lights. If an auxiliary light bulb page 3-18.) burns out, replace it as follows. 2. -
Page 89: Replacing A Turn Signal Light Bulb
PERIODIC MAINTENANCE AND ADJUSTMENT EAU24205 EAU24314 Replacing a turn signal light Replacing the license plate bulb light bulb 1. Remove the turn signal light lens 1. Remove the license plate light unit by removing the screw. by removing the screws. 1. -
Page 90: Supporting The Motorcycle
PERIODIC MAINTENANCE AND ADJUSTMENT a jack either under each side of the EAU24351 Supporting the motorcycle frame in front of the rear wheel or under Since this model is not equipped with a each side of the swingarm. centerstand, follow these precautions when removing the front and rear wheel or performing other mainte- nance requiring the motorcycle to... -
Page 91: Front Wheel (For Non-Abs Models)
PERIODIC MAINTENANCE AND ADJUSTMENT EAU44792 Front wheel (for non-ABS models) EWA14841 WARNING For the ABS model, have a Yamaha dealer remove and install the wheel. EAU56330 1. Front wheel axle pinch bolt 1. Brake hose holder 2. Wheel axle 2. Bolt and nut To remove the front wheel 3. -
Page 92: Rear Wheel (For Non-Abs Models)
EWA14841 ing the brake calipers onto the brake WARNING discs. For the ABS model, have a Yamaha dealer remove and install the wheel. 5. Install the brake hose holders by installing the bolt and nut. 6. Tighten the brake caliper bolts and... - Page 93 PERIODIC MAINTENANCE AND ADJUSTMENT 2. Lift the rear wheel off the ground To install the rear wheel according to the procedure on 1. Install the wheel and the brake cal- If the drive chain is difficult to re- page 6-40. iper bracket by inserting the wheel move, remove the wheel axle first, 3.
-
Page 94: Troubleshooting
Locknut: self. However, should your motorcycle 16 Nm (1.6 m·kgf, 12 ft·lbf) require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly. -
Page 95: Troubleshooting Charts
Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression. - Page 96 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.
-
Page 97: Motorcycle Care And Storage
Some models are equipped with matte colored finished parts. Be ble. Rust and corrosion can develop Cleaning sure to consult a Yamaha dealer for even if high-quality components are ECA10773 NOTICE used. A rusty exhaust pipe may go un-... - Page 98 For additional hoses and vents. during winter are extremely corrosive For motorcycles equipped with cleaning, use Yamaha Windshield in combination with water, carry out a windshield: Do not use strong Cleaner or another high-quality wind- the following steps after each ride in cleaners or hard sponges as shield cleaner.
- Page 99 MOTORCYCLE CARE AND STORAGE windshield which does not affect your EWA11132 WARNING visibility and which cannot be easily Consult a Yamaha dealer for ad- recognized. Contaminants on the brakes or tires vice on what products to use. can cause loss of control.
-
Page 100: Storage
MOTORCYCLE CARE AND STORAGE 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps EAU26183 Storage stabilizer (if available) to prevent from the spark plugs, and then the fuel tank from rusting and the install the spark plugs and the Short-term fuel from deteriorating. - Page 101 MOTORCYCLE CARE AND STORAGE Make any necessary repairs before storing the motorcycle.
-
Page 102: Specifications
SPECIFICATIONS Dimensions: Engine oil: Fuel: Overall length: Recommended brand: Recommended fuel: 2140 mm (84.3 in) YAMALUBE Regular unleaded gasoline (Gasohol (E10) Overall width: Type: acceptable) 770 mm (30.3 in) SAE 10W-30, 10W-40, 10W-50, 15W-40, Fuel tank capacity: Overall height: 20W-40 or 20W-50 17.0 L (4.49 US gal, 3.74 Imp.gal) 1225 mm (48.2 in) Fuel reserve amount:... - Page 103 SPECIFICATIONS 2nd: Loading: Rim size: 2.063 (33/16) 17M/C x MT5.50 Maximum load: 3rd: Front brake: FZ8-S 195 kg (430 lb) 1.762 (37/21) FZ8-SA 190 kg (419 lb) Type: 4th: (Total weight of rider, passenger, cargo Dual disc brake 1.522 (35/23) and accessories) Operation: 5th:...
- Page 104 SPECIFICATIONS Charging system: Turn signal indicator light: AC magneto Battery: Coolant temperature warning light: Model: Engine trouble warning light: YTZ10S Voltage, capacity: ABS warning light: 12 V, 8.6 Ah FZ8-SA LED Headlight: Immobilizer system indicator light: Bulb type: Halogen bulb Bulb voltage, wattage ×...
-
Page 105: Consumer Information
These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1. Engine serial number The vehicle identification number is stamped into the steering head pipe. - Page 106 1. Model label The model label is affixed to the frame under the rider seat. (See page 3-18.) Record the information on this label in the space provided. This information will be needed when ordering spare parts from a Yamaha dealer.
-
Page 107: Index
INDEX Engine oil and oil filter cartridge... 6-11 Matte color, caution........ 7-1 Engine serial number ......9-1 Model label ..........9-2 ABS (for ABS models) ......3-14 Engine stop switch....... 3-12 Multi-function meter unit ......3-8 ABS warning light (for ABS models) ..3-7 Engine trouble warning light .... - Page 108 INDEX Tires ............6-20 Tool kit ............6-2 Troubleshooting ........6-44 Troubleshooting charts......6-45 Turn signal indicator light .......3-4 Turn signal light bulb, replacing....6-39 Turn signal switch .........3-12 Valve clearance........6-19 Vehicle identification number ....9-1 Wheel bearings, checking.....6-33 Wheel, front (for non-ABS models) ..6-41 Wheel, rear (for non-ABS models) ..6-42 Wheels ..........6-22 10-2...
- Page 110 Original instructions PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2014.09-0.3×1 CR...
