Toshiba Portege R700-S1311 Specifications

Portege R700 Detailed Product Specification
Model Name: R700-S1311
C1 2
Operating System

Genuine Windows® 7 Professional 32-bit,
Professional 64-bit; includes Windows® XP Professional downgrade
3
Processor and Graphics
 Intel ®
Core™ i3-350M Processor
o 2.26 GHz, 3MB Cache
 Mobile Intel
®
HM55 Express Chipset
 Mobile Intel
®
HD Graphics with 64MB - 1696MB dynamically allocated
shared graphic memory (with Windows 7 Professional 64-bit)
5
Memory
 Configured with 4GB (2GB+2GB) DDR3 (max 8GB)
6
Storage Drive
 500GB (5400 RPM); Serial ATA hard disk drive
Fixed Optical Disk Drive
 DVD SuperMulti drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (10x), DVD-ROM (8x), DVD-R (8x), DVD-R DL (4X),
DVD-RW (4x), DVD+R (8x), DVD+R DL (4x), DVD+RW (4x),
DVD-RAM (3x)
8
Display
 13.3" diagonal widescreen HD TruBrite
native resolution
o Native support for 720p content
o 16:9 aspect ratio
o LED backlight
Sound
 Built-in stereo speakers
Input Devices
 Premium US keyboard (black)
 TouchPad™ pointing device with multi-touch control
 TouchPad™ Enable/Disable
 Control Buttons:
o TOSHIBA eco utility™ (Energy-saving mode)
o Touchpad on/off
o Presentation button
Communications
 Webcam and microphone
 Intel 82577LC Gigabit Network Connection (10/100/1000)
 Intel
®
Centrino® Advanced-N 6200 (802.11a/g/n)
 Bluetooth
®
version 2.1 plus Enhanced Data Rate (EDR)
Expandability
 2 main memory slots accessible from the bottom. Both slots occupied
 ExpressCard™/54 slot
 Memory Card Reader
o Secure Digital, Secure Digital High Capacity, Mini SD Card,
SDXC, Multi Media Card [shared slot may require adapter for
use]
Ports
 Video
RGB
o
HDMI
o
 Audio
o Microphone input port
o Headphone output port
 Data
o 3 USB v2.0 ports

2 x 1 USB v2.0

1 x eSATA/USB combo with USB Sleep and Charge
o RJ-45 LAN port
o Docking connector
 Security
1
Part Number: PT310U-01R01Q
Genuine Windows® 7
4
7
®
TFT LED display at 1366x768
9
© Copyright 2010 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
o Fingerprint Reader
o Slot for security lock
Physical Description
 Magnesium Finish in Black
 Dimensions (W x D x H Front/H Rear): 12.44" x 8.94" x 0.66"/1.01"
without feet
 Weight: Starting at 3.2 lbs. depending upon configuration
Power
 65W (19V 3.42A) 100-240V/50-60Hz AC Adapter.
o Dimensions (W x H x D): 4.25" x 1.81" x 1.16"
o Weight: starting at 0.49 lbs.
12
Battery
 6 cell/66Wh Lithium Ion battery pack
 Battery Life Rating (measured by MobileMark™ Productivity 2007)
Toshiba EasyGuard
 Protect & Fix
o Toshiba PC Health Monitor
o TOSHIBA HDD protection
o TOSHIBA Shock Protection System
o HALT Tested Design
o LCD Cover pressure Resistant Design
o Hinge Design Enhancement
o Polyurethane (PU) Coated Palm Rest
o Spill Resistant Keyboard
TOSHIBA PC Diagnostic Tool
o
 Secure
o Multiple-Level Password Utilities
o Fingerprint Reader (includes software for password and identity
management)
o AuthenTec EntréPad
o Infineon TPM Software Professional Package
o Trusted Platform Module v1.2
o TOSHIBA Secure Digital Token Utility
o Reinforced Security Cable Lock Slot
o Execute Disable Bit
 Connect
o Diversity Antenna
o TOSHIBA ConfigFree
o Voice-over-IP Ready Design
o TOSHIBA Bluetooth
o Wireless Communication On/Off Switch
 Optimize
o Toshiba Disc Creator
o TOSHIBA Device Access Control
o TOSHIBA Power Management Extension
o TOSHIBA Password Utilities
o TOSHIBA Recovery Media Creator
o TOSHIBA eco Utility
o TOSHIBA Assist
o TOSHIBA USB Sleep and Charge
o TOSHIBA Zooming Utility
FN Shortcut Keys
o
C1
Software
 Toshiba Software and Utilities
TOSHIBA Recovery Disc Creator
o
TOSHIBA Service Station
o
TOSHIBA Face Recognition
o
TOSHIBA HW Setup Utility
o
TOSHIBA Value Added Package
o
TOSHIBA Web Camera Application
o
10
TOSHIBA Disc Creator
o
TOSHIBA PC Health Monitor
o
TOSHIBA Eco Utility
o
TOSHIBA Supervisor Password Utility
o
Portege R700-S1311
UPC: 883974528097
Included 6 cell battery: 8 hours, 40 minutes
® 13
® ®
TrueSuite
®
®
Stack
14
11
Page 1 of 4
