JBL Harman Pulse 4 - Portable Bluetooth Speaker Quick Start Guide
WHAT'S IN THE BOX
Bluetooth pairing
Play
Party boost
Lightshow
APP
Shake to sync
Charging
WATER-PROOF IPX7
TECH SPEC
| Bluetooth version: | 4.2 |
| Support: | A2DP V1.3, AVRCP V1.6 |
| Transducer: | 2.25 inch |
| Rated power: | 20 W RMS |
| Frequency response: | 70 Hz - 20 kHz |
| Signal-to-noise ratio: | >80 dB |
| Battery type: | Lithium-ion polymer 26 Wh (Equivalent to 3.6 V, 7260 mAh) |
| Battery charge time: | 3.5 hours (5 V / 3 A) |
| Music playtime: | up to 12 hours (varies by brightness & volume level and audio content) |
| Bluetooth transmitter power: | ≤10 dBm |
| Bluetooth transmitter frequency range: | 2.402 – 2.480 GHz |
| 2.4GHz SRD FREQUENCY RANGE: | 2.407 – 2.475 GHz |
| Bluetooth transmitter modulation: | GFSK, π/4-DQPSK, 8DPSK |
| Dimension (W x D x H): | 96 X 96 x 207 mm |
| Weight: | 1260 g |
