Toa H-3WP Specification Sheet

I
NTERIOR
D S
ESIGN ERIES
H - 3 W
I D E
D
I S P E R S I O N
S
P E A K E R
THE H-3 WIDE-DISPERSION WALL-
is the newest addition
MOUNT SPEAKER
to the TOA Interior Design Series and continues
TOA's modern, innovative approach to
commercial speaker design.The H-3's unique
appearance and superb sound quality provide
a welcome alternative to conventional wall-
mount speakers for spaces where appearance
is a prime consideration.
Applications include speaker systems for hotels,
houses of worship,offices,museums,residential
spaces,restaurants,retail stores, and many
others.A weather-resistant version,model
H-3WP, is also available for outdoor
applications such as gardens,patios and
swimming pools.
The H-3's wide 140 degree horizontal
coverage pattern provides a solution for
eliminating deadspots inherent between wall-
mounted speakers. Also, the Minimum
Reflection design significantly reduces sound
wave reflections and the resulting sound
coloration that occurs with conventional
bracket-mounted "box" type speakers.
The H-3 is a two-way,sealed enclosure with high
quality components including a 1"dome
tweeter,dual 4" woofers, matching transformer,
and removable terminal block.The grille is
paintable for custom-matching to the room
decor.
An optional 900 Series Processor Module is
also available for convenient system
equalization using the industry-standard TOA
900 Series Mixer/Amplifiers.The H-3 also
carries a five year warranty.
H
I G H L I G H T S
Unique Appearance
blends well with modern
architecture for background/
foreground music and paging
systems.
Wide Variety of Applications
including hotels, houses of
worship, museums, offices,
residential spaces, restaurants,
and retail stores.
Wide Coverage Area:
140° horizontal x 70° vertical
dispersion
Weather-Resistant Version
Available, Model H-3WP,
for outdoor applications such
as gardens, patios and
swimming pools.
Minimum Reflection Design
reduces sound wave
reflections typical of
conventional bracket-
mounted "box" type speakers.
High Power Handling:
150 W (Continuous Program)
O A
P T I O N A L C C E S S O R I E S
E-06R
900 Series Processor Module for convenient system
equalization
FB-100
Subwoofer
HB-1
Flush-Mount Subwoofer
Two-Way, Sealed Enclosure with
High-Quality Components:
1" Dome Tweeter and Dual 4"
Woofers with Neodymium
Magnets
Built-In 70.7/100 V Matching
Transformer (30 W max.)
for distributed speaker
systems (8 and 16 ohm taps
also available).
Protection Circuit
prevents loudspeaker
damage from excessive input.
Built-In Crossover
with optimized filter slopes.
UL-Listed Fire-Resistant Material
Removable Terminal Block
with loop-through
terminations for distributed
speaker systems.
Paintable Grille
to custom-match to the
environment.
Five Year Warranty
