Toto WENZAL TX445SWCV3Z Manual

SPECIFICATIONS
To Spout
To Shower
150
72
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa.
2.
Ensure that water supply is clean ( No Sand, Dirt, Etc.).
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and fittings.
2. Flow Regulator should not be remove because it could
damage the system
As the product model is constantly updated, the actual product
3.
may not look the same as it shown in the diagram, but the
basic installation principles are the same.
The hot water supply side of the faucets is in a condition of
4.
high temperature. Do not allow skin to contact with the
hardware surface directly. Otherwise, scalding may occur.
S060320-3N
"WENZAL" CROSS HANDLE FLOOR STANDING
INSTALLATION
1
Make sure the flo or i s fla t
3
75.5
236
6 - Hole 8
5
60
G½
* Cover
Mortar
* Remove the cover after th e
mortar has dry
7
2
Base
Hot Water
4
Supply *
Cold Water
Supply *
Base
Sleeve
Drill
Anchor
* Pi pe sup plied by owne r
Maximum
6
Mortar
Minimum
Mortar
Shower
Packing
Cover
Packing
Nut*
PULL
Flexible
Hose
Flexible
Hose
* Tighten the nut
BATH & SHOWER SET
TROUBLESHOOTING
PROBLEM
Unsatisfactory spray
Water leaks around the handle
Flow Regulator Inside
(Don t remove)
1. NOZZLES
Screw
2. CERAMIC
HEAD WO RK
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm water. Wipe
entire surface completely dry with clean soft cloth. Many cleaners
PULL
may contain chemicals, such as ammonia, chlorine, toilet cleaner etc.
which could adversely affect the finish and are not recommended for
cleaning
TX445SWCV3Z
CHECK
SOLUTION
POINT
1 Clean
2 Tighten
R6
