Page 1: Parts List
PARTS LIST DE400D DE400D PARTS LIST NORCOLD 10/30/2002... - Page 2 CABINET ASSEMBLY - DE400D PART # DESCRIPTION 8000050124 SCREW 83400500010 WASHER-TEETH LOCK 160201440 TRAVEL PIN ASSY (USE 160207600) 160207600 TRAVEL PIN ASSY-0.75" 304100230 PLATE-HOLDS TRAVEL PIN 505502320 HINGE PIN (USE 61114600) 304105240 PLATE-HINGE 503001900 WASHER 412000800 CUSHION-RUBBER LEG 322301900 SUPPORT-BOTTOM RAIL 8010060401 SCREW 160905600...
- Page 3 THERMOSTAT & POWER SUPPLY - DE400D PART # DESCRIPTION 160107200 THERMOSTAT 160206700 KNOB-THERMOSTAT 545020740 MARK-THERMOSTAT COVER 16011396007 KIT-POWER SUPPLY 160107100 POWER SUPPLY (USE 16011396007) 196013100 TRANSFORMER ASSY (USE 16011396007) 163007800 OSCILLATOR ONLY (USE 16011396007) 80830441210 SCREW-TRUSS TAPPING/M4x12 834004000 WASHER-TEETH LOCK 8000040121 SCREW 80840430810...
- Page 4 COOLING UNIT AREA - DE400D PART # DESCRIPTION 80840430810 SCREW-TRUSS TAPPING/M4x8 433000800 BLIND COVER 439004000 HEAT INSULATOR 304300310 BLIND PLATE 80830441210 SCREW-TRUSS TAPPING/M4x12 161005510 COOLING UNIT 416004200 BUSHING-FOR BLIND PLATE 8073044121 SCREW-TAPPING/WITH TEETH LOCK WASHER 422305000 HOLDER-THERMISTER/AT EVAPORATOR 8080043082 SCREW-TAPPING 8073044121 SCREW-TAPPING/WITH TEETH LOCK WASHER 320101300...
- Page 5 DOOR ASSEMBLY - DE400D PART # DESCRIPTION 160031710 DOOR KIT ASSY-GRAY/REPLACES 160007740/160907110 160007740 DOOR ASSY-BLACK (USE 160031710) 242512260 BAR-BLACK 433100610 DOOR LINER 414801100 DOOR GASKET 160907110 DOOR FRAME ASSY-BLACK/3 SIDES (USE 160031710-DOOR ASSY) 404004700 HINGE BUSHING-POINTED 302304340 DOOR PANEL-BLACK 545008203 MARK-NORCOLD/BLACK 422302000 HOLDER-"I"/FOR BAR...
