Page 1: Parts List
PARTS LIST DE251E EV251E PART # 619751 NORCOLD 10/29/2002... - Page 2 CABINET ASSEMBLY - DE251E/EV251E DE251E/EV251E PARTS LIST - PAGE 2...
- Page 3 CABINET ASSEMBLY - DE251E/EV251E PART # DESCRIPTION 304300220 BLIND PLATE 439003700 HEAT INSULATOR-AT BLIND PLATE 430301900 PLATE-"I"/CABINET 416004200 BUSHING-FOR BLIND PLATE 80830441210 SCREW-TRUSS TAPPING/M4x12 645100510 FASTENER-PLASTIC RIVET 80500401040 SCREW-M4x10 83400400010 WASHER-TEETH LOCK 160201440 TRAVEL PIN ASSY (USE 160207600) 160207600 TRAVEL PIN ASSY-0.75" 160207610 TRAVEL PIN ASSY-WHITE 322118720...
-
Page 4: Thermostat & Power Supply - De/Ev 251E
THERMOSTAT & POWER SUPPLY - DE251E/EV251E PART # DESCRIPTION 160107210 THERMOSTAT 160206700 KNOB-THERMOSTAT 545020740 MARK-THERMOSTAT COVER 16011396007 KIT-POWER SUPPLY (NOT SHOWN) 16011393008 KIT-POWER SUPPLY (NOT SHOWN) 160107100 POWER SUPPLY (USE 16011396007) 160107000 POWER SUPPLY (USE 16011393008) 196013100 TRANSFORMER ASSY (USE 16011396007) 196013110 TRANSFORMER ASSY (USE 16011393008) 163007800... -
Page 5: Cooling Unit Area - De/Ev 251E
COOLING UNIT AREA - DE251E/EV251E PART # DESCRIPTION 161005010 COOLING UNIT-DE251E/DC254A/DE250G 161005040 COOLING UNIT-EV251E 403001700 WASHER-"I" 80800441620 SCREW-TAPPING/M4x16 422305000 HOLDER-THERMISTER/AT EVAPORATOR 8080043082 SCREW-TAPPING 500800400 SCREW-TAPPING 322132800 HOLDER-CONDENSER 322005310 HOLDER-CONDENSER WASHER 8320042003 WASHER-SPRING LOCK 8080043163 SCREW-TAPPING 80830431210 SCREW-TAPPING/M4x12 422000700 COLLAR-"I"/AT EVAPORATOR 8073044121 SCREW-TAPPING/WITH TEETH LOCK WASHER 605503201... - Page 6 DOOR ASSEMBLY - DE251E/EV251E PART # DESCRIPTION 160017600 DOOR ASSY-BLACK (USE 160031620) 160031620 DOOR KIT ASSY-GRAY 160017640 DOOR ASSY-WHITE (USE 160031620) 160031630 DOOR KIT ASSY-WHITE (USE 160031620) 302308310 DOOR PANEL-BLACK 302303260 DOOR PANEL-WHITE 160907510 DOOR FRAME ASSY-BLACK/3 SIDES (USE 160031620) 160907530 DOOR FRAME ASSY-WHITE/3 SIDES (USE 160031620) 404004700...
