AXIS Q60 Series
Configure your device
3. Create the zoomed-in preset position so that it covers the area in the image where you assume that the license plate
will appear.
Set up motion detection:
1. Go to Apps and start and open AXIS Object Analytics.
2. Create an object in area scenario for vehicles, with an include area that covers the entrance of the gate.
Create a rule:
1. Go to System > Events and add a rule.
2. Name the rule "Gatekeeper".
3. In the list of conditions, under Application, select the Object Analytics scenario.
4. In the list of actions, under Preset positions, select Go to preset position.
5. Select a Video channel.
6. Select the Preset position.
7. To make the camera wait a while before it returns to the home position, set a time for Home timeout.
8. Click Save.
Show a text overlay in the video stream when the device detects an object
This example explains how to display the text "Motion detected" when the device detects an object.
Make sure that AXIS Object Analytics is running:
1. Go to Apps > AXIS Object Analytics.
2. Start the application if it is not already running.
3. Make sure you have set up the application according to your needs.
Add the overlay text:
1. Go to Video > Overlays.
2. Under Overlays, select Text and click
3. Enter #D in the text field.
4. Choose text size and appearance.
5. To position the text overlay, click
Create a rule:
1. Go to System > Events and add a rule.
2. Type a name for the rule.
3. In the list of conditions, under Application, select Object Analytics.
4. In the list of actions, under Overlay text, select Use overlay text.
5. Select a video channel.
.
and select an option.
